Juno Lighting 6-Inch Incandescent Recessed Housing 120V Remodel Installation

Juno Lighting 6-Inch Incandescent Recessed Housing 120V Remodel Installation

(No reviews yet) Write a Review

Model: IC22R
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$82.46
$31.69
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Juno Lighting 6-Inch Incandescent Recessed Housing 120V Remodel Installation

Professional remodel housing for versatile residential lighting applications

Juno Lighting delivers reliable 6-inch incandescent recessed housing designed for remodel installations in residential applications. This professional-grade housing operates on standard 120V power and features UL Listed construction with CSA certification to US and Canadian standards, including damp location rating for versatile placement throughout the home.

Professional Features & Benefits

  • 6-Inch Aperture: Accommodates a wide range of lamp types including A19, BR30, BR40, PAR16, PAR20, PAR30, PAR30L, PAR38, and R20 for maximum lighting flexibility
  • 120V Standard Voltage: Compatible with most residential electrical systems for straightforward installation and operation
  • UL Listed & CSA Certified: Meets rigorous safety standards for US and Canadian installations with damp location rating
  • Medium Base Porcelain Socket: Features nickel-plated copper screw shell with drop socket and spring for secure trim installation
  • Pre-Wired Junction Box: Includes (5) 1/2" and (1) 3/4" knockouts with (4) non-metallic sheathed cable connectors and ground wire
  • Remodel Construction: Specifically designed for retrofit installations in existing ceilings
  • 1-Year Limited Warranty: Backed by manufacturer warranty for reliable long-term performance

Technical Specifications

  • Aperture Size: 6 IN IN
  • Country Of Origin: Mexico
  • Lamp Type: Incandescent
  • Mounting Method: Recessed
  • Number Of Lamps: 1
  • Product Height: 7.125
  • Product Length: 13.75 IN
  • Product Type: Housing
  • Product Width: 7.125 IN

Professional Applications

  • Residential Remodel Projects
  • Kitchen and Bathroom Lighting
  • Living Room and Bedroom Illumination
  • Hallway and Corridor Lighting
  • Damp Location Installations
  • General Residential Downlighting

Why Choose Juno Lighting Quality?

Juno Lighting provides professional-grade recessed lighting solutions with UL Listed and CSA certified construction, damp location rating, and comprehensive 1-year limited warranty. The robust porcelain socket with nickel-plated copper components ensures reliable performance and long service life in residential applications.

Manufacturer Resources

Product Specs

Aperture Size:
6 IN IN
Country Of Origin:
Mexico
Lamp Type:
Incandescent
Mounting Method:
Recessed
Number Of Lamps:
1
Product Height:
7.125
Product Length:
13.75 IN
Product Type:
Housing
Product Width:
7.125 IN

Juno Lighting IC22R – Frequently Asked Questions

1) Can the Juno IC22R recessed housing be installed in an existing ceiling, or does it need open framing?
The IC22R is a remodel housing, built to go into an existing finished ceiling. You cut the opening from below and the housing goes up through the hole, so there is no need to open the drywall or get above the joists. If you are working new construction with the framing exposed, a new-construction housing that nails to the joists is the right choice instead.
2) How big a hole do I cut for a Juno 6-inch remodel housing, and how much space do I need above the ceiling?
The IC22R is a 6-inch aperture housing. The housing body measures 13.75 x 7.125 x 7.125 inches, so plan on roughly 7-1/8 inches of clearance above the ceiling plane and enough joist bay run to take the 13.75 inch dimension including the attached junction box. In a bay with shallow depth or blocking in the way, measure the cavity before you cut.
3) What bulbs will fit a Juno 6-inch incandescent recessed can?
The IC22R takes one medium base lamp and accepts A19, BR30, BR40, PAR16, PAR20, PAR30, PAR30L, PAR38 and R20. Because the socket is a standard medium screw base on a drop socket with spring, a screw-in LED retrofit of the same shape works too, so long as the trim you pick clears the lamp.
4) Does the Juno IC22R come with the trim, or do I order that separately?
The housing is just that, the can, socket and junction box. Trim is a separate order. The socket is a drop socket on a spring, which is how Juno 6-inch trims seat and hold, so pick the trim by the look you want (baffle, reflector cone, eyeball, shower lens) matched to a 6-inch aperture and to the lamp you plan to run. Lamps are not included either.
5) What voltage is the Juno IC22R and how does the wiring land at the can?
Standard 120V. The junction box is pre-wired and comes with (5) 1/2 inch and (1) 3/4 inch knockouts, (4) non-metallic sheathed cable connectors and a ground wire, so a Romex home run lands straight at the box with no extra connectors bought. Knockout count is what lets you feed through to the next can in a run.
6) I need to match recessed cans already installed across a building. What identifies this Juno housing?
Order by Juno model IC22R, a 6-inch incandescent remodel housing at 120V with a single medium base socket. If the existing cans in the building are 6-inch Juno, the trims already on hand will carry over to these, which is the usual reason a property manager standardizes on one aperture size across a property.
7) Is the Juno IC22R rated to be covered with insulation?
Treat the IC22R as an incandescent remodel housing and follow the marking on the housing itself for insulation contact before you bury it. The practical point for a remodel job: if the attic above is blown-in or batt insulated and you cannot get up there to hold it back, you need a housing marked IC and an airtight gasket. If the ceiling cavity is between floors with no insulation, it is a non-issue.
8) Can I use a Juno IC22R housing with LED bulbs and a dimmer?
The socket is a medium screw base, so a screw-in LED lamp drops right in and the can does not care what technology the lamp uses. Dimming behavior comes from the lamp and the dimmer, not the housing, so pair a dimmable LED with a dimmer rated for LED loads. If you want a dedicated LED downlight with an integral driver instead, that is a different housing and trim system, not this one.
How fast can I get the Juno Lighting IC22R delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Juno Lighting IC22R come with a warranty?
Absolutely. The Juno Lighting IC22R is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
