Advance Metal Halide Ballast 50W M110 120/277V Magnetic HID Kit

Professional magnetic ballast for reliable metal halide lighting applications

The Advance Metal Halide Ballast delivers dependable performance for 50W metal halide lamps with M110 ANSI code compatibility. This magnetic HID ballast operates on dual voltage 120/277V at 60Hz with pulse start technology and Class P thermal protection, making it suitable for outdoor installations and various commercial lighting applications. UL Listed and CSA certified with RoHS compliance ensures professional-grade reliability.

Professional Features & Benefits

  • 50W Power Rating: Optimized for efficient operation of compatible metal halide lamps with consistent light output
  • 120/277V Dual Voltage: Versatile voltage compatibility reduces inventory requirements and simplifies installation planning
  • M110 ANSI Code: Ensures proper lamp compatibility and optimal ballast-to-lamp matching for reliable performance
  • Pulse Start Technology: Provides faster lamp ignition and improved lamp life compared to probe start systems
  • Class P Thermal Protection: Built-in thermal cutoff protects against overheating conditions for enhanced safety and longevity
  • 0.9 Power Factor: High power factor reduces reactive power consumption and improves electrical system efficiency
  • UL Listed & CSA Certified: Meets rigorous safety standards for professional installation and code compliance

Technical Specifications

  • Ansi Code: M110
  • Ballast Factor: 1
  • Country Of Origin: USA
  • Dimmable: No
  • Frequency Rating: 60 Hz
  • Lamp Type: METAL HALIDE
  • Microfarad: 6 MFD
  • Number Of Lamps: 1
  • Power Factor: 0.9
  • Power Rating: 50 WTT
  • Product Height: 2.8100 IN
  • Product Length: 3.9400 IN
  • Product Type: Magnetic HID
  • Product Wattage: 50 W
  • Product Weight: 4.880 Lbs
  • Product Width: 2.1000 IN
  • Standard: ULR;CSA certificate;RoHS Compliant
  • Start Type: PULSE
  • Thermal Protection: CLASS P
  • Voltage Rating: 120/277 V

Professional Applications

  • Commercial Building Lighting
  • Industrial Facility Illumination
  • Outdoor Area Lighting
  • Parking Structure Lighting
  • Warehouse and Storage Facilities
  • Retail and Office Buildings
  • Municipal and Public Lighting

Why Choose Advance Quality?

Advance ballasts provide proven reliability with UL Listed and CSA certification ensuring code compliance and professional installation standards. The robust magnetic HID design with Class P thermal protection and RoHS compliance delivers long-term performance you can trust for critical lighting applications.

Manufacturer Resources

Product Specs

Ansi Code:
M110
Ballast Factor:
1
Country Of Origin:
USA
Dimmable:
No
Frequency Rating:
60 Hz
Lamp Type:
METAL HALIDE
Microfarad:
6 MFD
Number Of Lamps:
1
Power Factor:
0.9
Power Rating:
50 WTT
Product Height:
2.8100 IN
Product Length:
3.9400 IN
Product Type:
Magnetic HID
Product Wattage:
50 W
Product Weight:
4.880 Lbs
Product Width:
2.1000 IN
Standard:
ULR;CSA certificate;RoHS Compliant
Start Type:
PULSE
Thermal Protection:
CLASS P
Voltage Rating:
120/277 V
Department:
Electrical

Advance 71A5181001D – Frequently Asked Questions

1) Will this Advance 50W ballast run my metal halide lamp, or do I need to match the ANSI code?
Match the ANSI code. The Advance 71A5181001D is built for 50W metal halide lamps carrying ANSI code M110, one lamp per ballast. If the lamp on the fixture label says anything other than M110, this is not the right ballast for it, even at the same 50 watts.
2) Can I use this ballast on both 120V and 277V circuits?
Yes. It is a dual voltage ballast rated 120/277V at 60 Hz, so the same part works on a 120V branch circuit in a retail space or a 277V circuit in a warehouse. You land the appropriate voltage lead per the ballast wiring diagram; the unused tap is capped off.
3) Is this a pulse start or probe start ballast?
Pulse start. The 50W M110 ballast uses an igniter to strike the lamp rather than a probe start electrode, which gives quicker ignition and longer lamp life. Probe start lamps will not operate correctly on it, so the lamp you install has to be a pulse start type matching M110.
4) Will this fit inside my existing fixture housing or pole base?
The core assembly measures 3.94 x 2.81 x 2.10 inches and weighs 4.88 lbs. Check the clear space in the ballast compartment against those numbers, and make sure the mounting bracket or tray can carry roughly five pounds before you reuse an old housing.
5) Will this ballast dim with a wall dimmer or a lighting control system?
No. This is a non-dimmable magnetic HID ballast, full output only, with a ballast factor of 1. For controlled areas, switch the circuit or use occupancy control on the whole fixture rather than trying to dim it.
6) Does the Advance 50W HID ballast kit come with the capacitor, or do I order that separately?
It is supplied as a kit built around a 6 MFD capacitor rating. When replacing only the capacitor on an existing install, that 6 MFD value is the one to match, along with the correct voltage rating for the cap.
7) Is this ballast rated for outdoor parking lot and area lighting?
It is intended for outdoor installations as well as indoor commercial work, including parking structures, area lighting and warehouse fixtures. The ballast itself is not a weatherproof enclosure, so it has to be mounted inside the fixture housing or pole base that provides the wet location protection.
8) Does a 0.9 power factor matter for my panel loading?
It does if you are sizing a branch circuit for a row of fixtures. At 0.9 power factor the ballast draws noticeably less current than a low power factor unit at the same 50W lamp load, so more fixtures fit per circuit and reactive load on the panel stays down.
