Advance 70W Metal Halide Magnetic Ballast M98/143 120/277V Outdoor Rated

Advance 70W Metal Halide Magnetic Ballast M98/143 120/277V Outdoor Rated

(No reviews yet) Write a Review

Model: 72C5282NP001
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$456.09
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Advance 70W Metal Halide Magnetic Ballast M98/143 120/277V Outdoor Rated

Professional magnetic HID ballast for reliable metal halide lamp operation

The Advance 70W Metal Halide Magnetic Ballast delivers dependable performance for single metal halide lamp applications. Engineered with dual voltage capability at 120/277V and pulse start technology, this outdoor-rated ballast features robust metal housing construction and high power factor design for professional lighting installations requiring reliable HID lamp operation.

Professional Features & Benefits

  • 70W Power Rating: Optimized for single metal halide lamp operation with precise power delivery and ballast factor of 1 for consistent light output.
  • Dual Voltage 120/277V: Versatile voltage compatibility reduces inventory requirements and simplifies installation across various electrical systems.
  • Outdoor Rated Design: Weather-resistant construction with metal housing ensures reliable performance in exterior and harsh environment applications.
  • Pulse Start Technology: Advanced starting method provides faster lamp ignition, improved lamp life, and better lumen maintenance compared to probe start systems.
  • High Power Factor 0.9: Efficient electrical performance reduces reactive power draw and improves overall system efficiency.
  • UL & CSA Certified: Comprehensive safety listings ensure compliance with North American electrical standards for professional installations.
  • Compact Metal Housing: Durable construction measuring 11.75" x 3.19" x 2.63" provides reliable protection while fitting standard fixture enclosures.

Technical Specifications

  • Amperage Rating: 1.25/0.55 A
  • Ansi Code: M98/143
  • Ballast Factor: 1
  • Circuit Type: HX-HPF
  • Country Of Origin: USA
  • Frequency Rating: 60 Hz
  • Housing Material: Metal
  • Lamp Type: METAL HALIDE
  • Number Of Lamps: 1
  • Power Factor: 0.9
  • Power Rating: 70 Watt
  • Product Height: 2.6300 IN
  • Product Length: 11.7500 IN
  • Product Type: Magnetic HID
  • Product Wattage: 70 W
  • Product Weight: 9.200 Lbs
  • Product Width: 3.1900 IN
  • Standard: CSA certificate;UL certificate;RoHS Compliant
  • Start Type: PULSE
  • Voltage Rating: 120/277 V
  • Wire Length: 12 IN
  • Wire Type: Stranded

Professional Applications

  • Outdoor Area Lighting
  • Commercial Parking Lots
  • Industrial Facilities
  • Warehouse High Bay Lighting
  • Security and Perimeter Lighting
  • Sports and Recreation Facilities
  • Municipal Street Lighting

Why Choose Advance Quality?

Advance delivers proven reliability in HID ballast technology with comprehensive UL and CSA certifications, RoHS compliance, and robust metal housing construction. Made in USA with professional-grade components, this magnetic ballast provides dependable metal halide lamp operation for demanding commercial and industrial lighting applications.

Manufacturer Resources

Product Specs

Amperage Rating:
1.25/0.55 A
Ansi Code:
M98/143
Ballast Factor:
1
Circuit Type:
HX-HPF
Country Of Origin:
USA
Frequency Rating:
60 Hz
Housing Material:
Metal
Lamp Type:
METAL HALIDE
Number Of Lamps:
1
Power Factor:
0.9
Power Rating:
70 Watt
Product Height:
2.6300 IN
Product Length:
11.7500 IN
Product Type:
Magnetic HID
Product Wattage:
70 W
Product Weight:
9.200 Lbs
Product Width:
3.1900 IN
Standard:
CSA certificate;UL certificate;RoHS Compliant
Start Type:
PULSE
Voltage Rating:
120/277 V
Wire Length:
12 IN
Wire Type:
Stranded
Department:
Electrical

Advance 72C5282NP001 – Frequently Asked Questions

1) Will this Advance 70W ballast run my existing probe start metal halide lamp?
No. The Advance 72C5282NP001 is a pulse start ballast carrying ANSI code M98/143, so it needs a pulse start 70W metal halide lamp. A probe start 70W lamp (ANSI M98 is the pulse start designation) will not start and run correctly on it. If the fixture currently holds a probe start lamp, plan on changing the lamp along with the ballast.
2) Does the Advance M98/143 ballast run on 120V or 277V?
Both. It is a dual voltage 120/277V ballast at 60 Hz, so the same part works on a 120V branch circuit or a 277V commercial lighting circuit. Line current is 1.25A at 120V and 0.55A at 277V, which is what you size the circuit and fuse from. You select the voltage by which input lead you land, so read the lead markings before wiring.
3) Will this ballast fit inside my pole-mounted area light housing?
The core-and-coil measures 11.75 inches long by 3.19 inches wide by 2.63 inches high, so measure the clear space in the ballast tray before ordering. It also weighs 9.2 lbs, which matters if you are mounting it on a door-mounted tray or a remote ballast box. Leads are 12 inches of stranded wire, so the splice point needs to be within a foot of the ballast.
4) Can this 70W metal halide ballast be used outdoors or in an unheated parking structure?
Yes, it is an outdoor-rated magnetic HID ballast in a metal housing, which is why it shows up in parking lot, street lighting, and perimeter security retrofits. It still has to sit inside a suitable fixture enclosure or ballast box, not in open weather.
5) How many lamps will one of these ballasts run?
One. It is a single-lamp 70W metal halide ballast with a ballast factor of 1, meaning the lamp runs at its rated lumen output. A two-head fixture needs two ballasts.
6) Is this a high power factor ballast, and what circuit type is it?
It is an HX-HPF circuit with a 0.9 power factor. High power factor keeps line current low (1.25A at 120V), which is what lets facilities put more heads on a single branch circuit without tripping, and it keeps you clear of utility power factor penalties on larger lighting loads.
7) Is this ballast UL listed for a municipal or institutional job spec?
It holds both UL and CSA certificates and is RoHS compliant, and it is made in the USA. That covers the usual North American listing requirement on school, municipal, and healthcare lighting submittals, and the domestic origin helps on jobs with Buy American language.
8) Should I replace a failed 70W metal halide ballast or convert the fixture to LED?
If the fixture, lens, and reflector are sound and the lamps are already pulse start, swapping in a like-for-like magnetic ballast is the shorter job: one core-and-coil, 12-inch leads, no fixture rework. Magnetic HID is the right call when you are keeping a standardized lamp stock across a site or matching color and output to adjacent heads that are staying HID. A retrofit to LED makes more sense when you are relamping the whole site at once and want to drop the lamp maintenance entirely.
9) What exact part number do I order for the Advance 70W M98 pulse start ballast?
The manufacturer part number is 72C5282NP001 from Advance, a 70W metal halide magnetic ballast, ANSI M98/143, 120/277V, pulse start. Order by that MPN and cross-check the ANSI code stamped on the lamp you are feeding.
