Advance 70W Metal Halide Magnetic Ballast M98/143 ANSI Quad Kit

Advance 70W Metal Halide Magnetic Ballast M98/143 ANSI Quad Kit

Professional magnetic ballast for reliable metal halide lighting applications

The Advance 70W Metal Halide Magnetic Ballast delivers dependable performance for professional lighting installations. This magnetic HID ballast operates single metal halide lamps with M98/143 ANSI compatibility and multi-voltage operation at 120/208/240/277V. Built with Class P thermal protection and pulse start technology, this UL Listed ballast provides reliable outdoor-suitable operation with 0.9 power factor efficiency.

Professional Features & Benefits

• 70W Power Rating: Optimized for standard metal halide lamp operation with consistent light output and energy efficiency.
• Multi-Voltage Operation (120/208/240/277V): Versatile installation compatibility across various electrical systems and applications.
• M98/143 ANSI Code: Ensures proper lamp compatibility and standardized performance specifications.
• Class P Thermal Protection: Automatic shutdown protection prevents overheating and extends ballast service life.
• Pulse Start Technology: Provides reliable lamp ignition and improved lamp life compared to probe start systems.
• UL Listed & CSA Certified: Meets rigorous safety standards for professional installation and code compliance.
• Outdoor Suitable Design: Weather-resistant construction for versatile indoor and outdoor lighting applications.

Technical Specifications

• Ansi Code: M98/143
• Ballast Factor: 1
• Country Of Origin: USA
• Dimmable: No
• Frequency Rating: 60 Hz
• Lamp Type: METAL HALIDE
• Microfarad: 8 MFD
• Number Of Lamps: 1
• Power Factor: 0.9
• Power Rating: 70 WTT
• Product Height: 2.8100 IN
• Product Length: 3.9400 IN
• Product Type: Magnetic HID
• Product Wattage: 70 W
• Product Weight: 5.700 Lbs
• Product Width: 2.8000 IN
• Standard: ULR;CSA certificate;RoHS Compliant
• Start Type: PULSE
• Thermal Protection: CLASS P
• Voltage Rating: 120/208/240/277 V

Installation & Operation

1. Mount the ballast in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Commercial Outdoor Lighting
• Industrial Facility Illumination
• Parking Structure Lighting
• Warehouse and Storage Areas
• Security and Area Lighting
• Retail and Office Buildings
• Municipal and Public Lighting

Why Choose Advance Quality?

Advance ballasts deliver proven reliability with UL Listed and CSA certified construction, RoHS compliant materials, and Class P thermal protection. Made in USA with rigorous quality standards, this magnetic ballast provides dependable metal halide lighting performance for demanding professional applications.
