Advance 200W Metal Halide Magnetic Ballast M136 ANSI Quad Kit

Advance 200W Metal Halide Magnetic Ballast M136 ANSI Quad Kit

(No reviews yet) Write a Review

Model: 71A5692001D
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$413.90
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Advance 200W Metal Halide Magnetic Ballast M136 ANSI Quad Kit

Professional Magnetic HID Ballast for Outdoor Lighting Applications

The Advance 200W Metal Halide Magnetic Ballast delivers reliable performance for outdoor lighting luminaire applications. This magnetic HID ballast features M136 ANSI code compatibility, multi-voltage operation at 120/208/240/277V, and Class P thermal protection for dependable service. UL Listed and CSA certified with RoHS compliance, this ballast provides professional-grade power management for metal halide lighting systems.

Professional Features & Benefits

  • 200W Power Rating: Optimized for high-intensity metal halide lamps delivering consistent light output and energy efficiency.
  • Multi-Voltage Operation (120/208/240/277V): Versatile voltage compatibility reduces inventory requirements and simplifies installation planning.
  • M136 ANSI Code: Industry-standard lamp compatibility ensures proper electrical matching and optimal lamp performance.
  • Class P Thermal Protection: Built-in thermal safeguards protect against overheating and extend ballast service life.
  • Magnetic HID Technology: Proven magnetic ballast design provides reliable starting and stable operation for metal halide lamps.
  • Outdoor Suitable Design: Engineered for outdoor luminaire applications with appropriate environmental protection.
  • UL Listed & CSA Certified: Meets rigorous safety standards for professional electrical installations.

Technical Specifications

  • Ansi Code: M136
  • Ballast Factor: 1
  • Country Of Origin: USA
  • Dimmable: No
  • Frequency Rating: 60 Hz
  • Lamp Type: METAL HALIDE
  • Microfarad: 15 MFD
  • Number Of Lamps: 1
  • Power Factor: 0.9
  • Power Rating: 200 WTT
  • Product Height: 2.8100 IN
  • Product Length: 3.9400 IN
  • Product Type: Magnetic HID
  • Product Wattage: 200 W
  • Product Weight: 8.780 Lbs
  • Product Width: 2.8000 IN
  • Standard: ULR;CSA certificate;RoHS Compliant
  • Start Type: PULSE
  • Thermal Protection: CLASS P
  • Voltage Rating: 120/208/240/277 V

Professional Applications

  • Outdoor Area Lighting
  • Commercial Parking Lot Illumination
  • Industrial Facility Lighting
  • Sports Field and Recreation Lighting
  • Security and Perimeter Lighting
  • Municipal Street and Pathway Lighting
  • Warehouse and Loading Dock Applications

Why Choose Advance Quality?

Advance ballasts deliver proven reliability with UL Listed and CSA certified safety compliance. The Class P thermal protection and RoHS compliant construction ensure long-term durability and environmental responsibility. Made in USA with professional-grade components for dependable lighting system performance.

Manufacturer Resources

Product Specs

Ansi Code:
M136
Ballast Factor:
1
Country Of Origin:
USA
Dimmable:
No
Frequency Rating:
60 Hz
Lamp Type:
METAL HALIDE
Microfarad:
15 MFD
Number Of Lamps:
1
Power Factor:
0.9
Power Rating:
200 WTT
Product Height:
2.8100 IN
Product Length:
3.9400 IN
Product Type:
Magnetic HID
Product Wattage:
200 W
Product Weight:
8.780 Lbs
Product Width:
2.8000 IN
Standard:
ULR;CSA certificate;RoHS Compliant
Start Type:
PULSE
Thermal Protection:
CLASS P
Voltage Rating:
120/208/240/277 V
Department:
Electrical

Advance 71A5692001D – Frequently Asked Questions

1) Will this ballast fit inside my existing pole-mounted shoebox fixture?
Check the ballast tray before ordering. The core and coil measures 3.94 x 2.81 x 2.80 inches and the assembly weighs 8.78 lbs. The capacitor and ignitor mount separately in most HID fixtures, so allow tray space beyond those core dimensions. The weight matters for older fixtures where you are also judging whether the arm and pole take the load.
2) Can I put this 200W metal halide ballast on a dimmer or an occupancy sensor?
No. This is a non-dimmable magnetic HID ballast. Metal halide also needs a restrike cooldown after any interruption, so switching it off a motion sensor leaves the area dark for minutes. For parking or security zones that need dimming or instant re-strike, that job belongs to an LED retrofit rather than a magnetic HID ballast.
3) Is this ballast safety listed for a municipal or institutional electrical spec?
It carries UL recognition and a CSA certificate, and it is RoHS compliant. Thermal protection is Class P, the self-resetting thermal cutout that most fixture and code specs call for on enclosed HID ballasts. Country of origin is the USA, which covers domestic-preference language on a lot of government and school work.
4) Can I use this on a 150W or 250W metal halide lamp instead?
No. Wattage and ANSI code have to match the lamp exactly. This unit is a 200W ballast built to the M136 code, and running a 150W or 250W lamp on it will either fail to start or drive the lamp outside its design current. Order the ballast whose ANSI code matches the lamp already in the fixture.
5) What comes in the Advance 200W metal halide quad kit besides the core and coil?
It is a kit, so the capacitor value is part of the spec: 15 MFD, with pulse start ignitor operation. Replace the whole kit as a set rather than swapping a core against a mismatched capacitor, since the capacitor value determines lamp current and a wrong MFD will short lamp life or fail to strike.
6) Is this ballast high power factor, and does it matter for a parking lot retrofit?
Rated 0.9 power factor with a ballast factor of 1.0. High power factor means lower line current per fixture, which is what lets you put more heads on a circuit without a re-pull. A ballast factor of 1.0 means the lamp runs at its full rated lumen output, so light levels match the original design when you swap a failed unit.
