Philips Lighting 913710407801 F-CAN Pulse-Start Magnetic HID Ballast, 70W Metal Halide, 120/277V

Philips Lighting 913710407801 F-CAN Pulse-Start Magnetic HID Ballast, 70W Metal Halide, 120/277V

(No reviews yet) Write a Review

Model: 913710407801
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$391.70
$341.70
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Philips Lighting 913710407801 F-CAN Pulse-Start Magnetic HID Ballast, 70W Metal Halide, 120/277V

The Philips Lighting 913710407801 F-CAN HID ballast is a magnetic high-intensity-discharge ballast engineered to operate a 70W Metal Halide (MH) lamp using a pulse-start ANSI M98(PULSESTART) circuit. Rated for 120/277V input at 60 Hz and 94W nominal input power with a 0.9 nominal power factor, this HX-HPF magnetic ballast is housed in a durable metal can measuring 11.75 x 2.63 x 3.19 and carries CSA certification for reliable indoor and outdoor luminaire use.

Key Features

  • Lamp Compatibility: Engineered for a 70W Metal Halide (MH) lamp with a Rated Lamp Power of 70W.
  • Ballast Type & Circuit: Magnetic HID ballast with HX-HPF circuit and ANSI M98(PULSESTART) pulse-start ignition.
  • Dual Voltage Input: Operates on 120/277V at 60 Hz, drawing 94W nominal input power at a 0.9 nominal power factor.
  • Durable Metal Housing: Metal can construction measuring 11.75 x 2.63 x 3.19 with a net weight of 4.086 kg.
  • Remote Wiring Capable: Supports remote wiring configuration up to a maximum ballast-to-lamp distance of 10'.
  • Outdoor Rated: Suitable for outdoor use in commercial and industrial fixtures.

Certifications & Compliance

  • CSA Certificate (Approval Marks)
  • UL Insulation Class A (105°C)
  • Suitable for Outdoor Use

Technical Specifications

  • Automatic Restart: No
  • Ballast Factor Nom: 1
  • Base Model: 72C5282
  • Capacitor Catalog Number: Inside Can
  • Constant Wattage Deviation: 10%
  • Ean Upc Product: 7.81087E+11
  • Ignitor Catalog Number: Inside Can
  • Input Current Nom: 0.85/0.37 A A
  • Input Current Open Circuit: 1.6/0.75 A
  • Input Current Short Circuit: 0.55-0.85/0.25-0.4 A
  • Input Current Starting: 1.25/0.55 A
  • Material Nr 12nc: 9.1371E+11
  • Max Ballast Lamp Distance Remote Wiring: 10'
  • Number Of Lamps: 1 piece/unit
  • Numerator Packs Per Outer Box: 1
  • Numerator Quantity Per Pack: 1
  • Open Circuit Voltage Test Volts: 230-280 V
  • Order Code: 9.1371E+11
  • Order Product Name: F-CAN HID 72C5282NP001
  • Power Factor Nom: 0.9
  • Recommended Fuse Value: 4/2 A
  • Remote Wiring Configuration Allowed: Yes
  • Secondary Short Circuit Current: 0.95-1.2 A
  • Suitable For Outdoor Use: Yes
  • Temperature Marking: 90°C max. case
  • Ul Recognized: No
  • Ul Temperature Code: NA
  • Wire Length By Color: 12"
  • Wire Striplength: 0.5 mm

Typical Applications

  • Commercial and Industrial HID Lighting Fixtures
  • Outdoor Area and Site Lighting
  • Metal Halide Luminaire Retrofits and Replacements
  • Remote-Mount Ballast Enclosures
  • Parking Lot, Roadway, and Security Lighting

Why Philips Lighting?

Philips Lighting engineers HID ballasts like the F-CAN 913710407801 (Base Model 72C5282) to deliver reliable, code-compliant performance for demanding lighting installations. With CSA certification, a rugged metal can housing, and precise ANSI M98(PULSESTART) pulse-start circuitry, this magnetic HX-HPF ballast is built to keep 70W Metal Halide fixtures running dependably in both indoor and outdoor environments.

Manufacturer Resources

Product Specs

Ansi Code:
M98(PULSESTART)
Approval Marks:
CSA certificate
Automatic Restart:
No
Ballast Factor Nom :
1
Ballast Type:
Magnetic HID
Base Model:
72C5282
Capacitor Catalog Number:
Inside Can
Circuit Type:
HX-HPF
Constant Wattage Deviation:
10%
Ean Upc Product:
7.81087E+11
Hipot Test 1 Minute :
1600 V
Hipot Test 2 Seconds :
2000 V
Housing Dimensions:
11.75 x 2.63 x 3.19
Housing Material:
Metal
Housing Type:
F-Can
Ignitor Catalog Number:
Inside Can
Input Current Nom :
0.85/0.37 A A
Input Current Open Circuit :
1.6/0.75 A
Input Current Short Circuit :
0.55-0.85/0.25-0.4 A
Input Current Starting :
1.25/0.55 A
Input Frequency:
60 Hz
Input Power Nom :
94 W
Input Voltage:
120/277 V
Lamp Type:
70W MH
Material Nr 12nc :
9.1371E+11
Max Ballast Lamp Distance Remote Wiring:
10'
Net Weight Piece :
4.086 kg
Number Of Lamps:
1 piece/unit
Numerator Packs Per Outer Box:
1
Numerator Quantity Per Pack:
1
Open Circuit Voltage:
255 V
Open Circuit Voltage Test Volts :
230-280 V
Order Code:
9.1371E+11
Order Product Name:
F-CAN HID 72C5282NP001
Power Factor Nom :
0.9
Rated Lamp Power:
70 W
Recommended Fuse Value:
4/2 A
Remote Wiring Configuration Allowed:
Yes
Secondary Short Circuit Current:
0.95-1.2 A
Suitable For Outdoor Use:
Yes
Temperature Marking:
90ºC max. case
Ul Insulation Class:
A(105°C)
Ul Recognized:
No
Ul Temperature Code:
NA
Wire Length By Color:
12"
Wire Striplength:
0.5 mm
Wire Type:
Stranded
Product Type:
HID Ballast
Department:
Electrical

Philips Lighting 913710407801 – Frequently Asked Questions

1) Will the Philips 913710407801 ballast run a probe-start 70W metal halide lamp?
No. The 913710407801 F-CAN ballast uses an ANSI M98 (pulse-start) circuit, so it needs a 70W pulse-start metal halide lamp. Probe-start 70W MH lamps run on a different ANSI code circuit and should not be paired with it. Check the ANSI code printed on the lamp before you install.
2) Can this 70W metal halide ballast be wired for both 120V and 277V?
Yes, it is a dual-voltage 120/277V ballast at 60 Hz. Nominal input current is 0.85A on 120V and 0.37A on 277V, and the recommended fuse value follows the same order, 4A for 120V and 2A for 277V. You select the voltage by which input lead you connect, so the same part covers both a 120V tenant circuit and a 277V commercial lighting branch.
3) How far can I mount this HID ballast away from the lamp?
Remote mounting is allowed, with a maximum ballast-to-lamp distance of 10 feet. That covers a remote ballast box or a pole base feeding a nearby fixture head, but anything beyond 10 feet is outside the rating and risks unreliable starting on the pulse-start circuit.
4) Will this ballast fit inside my existing metal halide fixture housing?
The metal F-can measures 11.75 x 2.63 x 3.19 inches and weighs 4.086 kg, so measure the ballast tray or compartment in your luminaire against those three numbers before ordering. Lead wires are 12 inches long and stranded, stripped 0.5 mm, which limits how far the can can sit from the wiring compartment.
5) Do I need to buy a separate capacitor and ignitor for this pulse-start ballast?
No. On the 913710407801 both the capacitor and the ignitor are supplied inside the can, so it ships as a complete pulse-start assembly. It ships one piece per pack, one pack per box, and drives a single lamp, so order one per fixture.
6) Is this ballast approved for outdoor parking lot and wall pack fixtures?
Yes, it is rated suitable for outdoor use and carries a CSA certificate, which is what lets it go into exterior area, roadway, and security luminaires. Case temperature marking is 90 C max with UL Insulation Class A (105 C), so the enclosure it sits in has to keep the can at or below that 90 C case limit.
7) What is the difference between an HX-HPF ballast and a constant-wattage HID ballast?
HX-HPF, the circuit used here, is a high-reactance high-power-factor design: fewer components, a 0.9 nominal power factor, and a constant wattage deviation of 10 percent, meaning lamp wattage moves about 10 percent as line voltage swings. A CWA (constant wattage autotransformer) ballast holds lamp wattage tighter over a wider input voltage range and is the better choice where the supply is unstable. For a clean 120V or 277V branch feeding a 70W MH head, the HX-HPF is the normal fit.
8) How much load does a 70W metal halide fixture with this ballast draw on the circuit?
Figure 94W nominal input power for the ballast and lamp together, above the 70W rated lamp power because of ballast losses. Starting current is 1.25A at 120V or 0.55A at 277V, so size branch breakers and inrush allowance for that, not just the running 0.85A/0.37A.
9) Will this ballast restrike the lamp on its own after a power blip?
No, automatic restart is not a feature of this ballast. After a momentary outage the metal halide lamp has to cool before it will reignite, and the fixture relights only when the ballast is re-energized. If you need light immediately after a dropout at a security or egress location, plan on a separate quartz restrike fixture or an instant-on source instead.
10) Is the Philips 913710407801 the same as base model 72C5282?
Yes. 913710407801 is the ordering number and the ballast is built on Philips base model 72C5282, catalogued as F-CAN HID 72C5282NP001. If your old ballast label reads 72C5282, this is the matching 70W pulse-start F-can.
11) What open circuit voltage should I read at the lamp socket when testing this ballast?
Open circuit voltage is 255V nominal, with an acceptable test window of 230 to 280V. Secondary short circuit current runs 0.95 to 1.2A. If your meter reads outside the 230 to 280V band with no lamp installed, the ballast or capacitor is the suspect rather than the lamp.
12) Can I use this ballast to run two 70W metal halide lamps off one can?
No, it drives one lamp per unit. Two heads means two ballasts. Ballast factor is 1, so the lamp delivers its rated 70W light output rather than a reduced or boosted level.
