Advance Metal Halide Ballast 100W M90/M140 120/277V F-CAN High Reactance

Advance Metal Halide Ballast 100W M90/M140 120/277V F-CAN High Reactance

(No reviews yet) Write a Review

Model: 72C5381NP001
Selected Model is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$461.36
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Advance Metal Halide Ballast 100W M90/M140 120/277V F-CAN High Reactance

Professional Metal Halide Lighting Control Solution

The Advance Metal Halide Ballast delivers reliable 100W power control for M90 and M140 metal halide lamps with dual voltage 120/277V operation. This F-CAN high reactance ballast features pulse start technology and 0.9 power factor for efficient lighting performance in commercial and industrial applications.

Professional Features & Benefits

  • 100W Power Rating: Optimized for single metal halide lamp operation with consistent power delivery and reliable performance.
  • Dual Voltage 120/277V: Versatile voltage compatibility reduces inventory requirements and simplifies installation planning.
  • M90/M140 ANSI Compatibility: Supports standard metal halide lamp types for flexible fixture design and lamp replacement options.
  • High Reactance Circuit: Provides stable lamp operation with excellent current regulation and extended lamp life.
  • Pulse Start Technology: Ensures reliable lamp ignition and faster warm-up times for improved lighting performance.
  • 0.9 Power Factor: High efficiency operation reduces energy costs and meets utility power factor requirements.
  • F-CAN Design: Compact form factor enables installation in standard fixture housings with space-efficient mounting.

Technical Specifications

  • Ansi Code: M90 OR M140
  • Ballast Type: F-CAN
  • Circuit Type: HIGH REACTANCE
  • Country Of Origin: USA
  • Frequency: 60 HZ
  • Frequency Rating: 60 Hz
  • Lamp Type: METAL HALIDE
  • Nema Standard: 2A
  • Number Of Lamps: 1
  • Power Factor: 0.9
  • Product Height: 2.6300 IN
  • Product Length: 11.7500 IN
  • Product Wattage: 100 W
  • Product Weight: 10.100 Lbs
  • Product Width: 3.1900 IN
  • Standard: CSA certificate;UL certificate;RoHS Compliant
  • Start Type: PULSE
  • Voltage Rating: 120/277 V

Professional Applications

  • Commercial Office Buildings
  • Retail and Shopping Centers
  • Industrial Facilities
  • Warehouse and Distribution Centers
  • Educational Institutions
  • Healthcare Facilities
  • Municipal and Government Buildings

Why Choose Advance Quality?

Advance ballasts deliver proven reliability with UL and CSA certifications ensuring code compliance and safety. The RoHS compliant design meets environmental standards while the USA manufacturing provides quality assurance and support. With NEMA 2A rating and robust construction, this ballast provides long-term performance in demanding commercial lighting applications.

Manufacturer Resources

Product Specs

Ansi Code:
M90 OR M140
Ballast Type:
F-CAN
Circuit Type:
HIGH REACTANCE
Country Of Origin:
USA
Frequency:
60 HZ
Frequency Rating:
60 Hz
Lamp Type:
METAL HALIDE
Nema Standard:
2A
Number Of Lamps:
1
Power Factor:
0.9
Product Height:
2.6300 IN
Product Length:
11.7500 IN
Product Wattage:
100 W
Product Weight:
10.100 Lbs
Product Width:
3.1900 IN
Standard:
CSA certificate;UL certificate;RoHS Compliant
Start Type:
PULSE
Voltage Rating:
120/277 V
Department:
Electrical

Advance 72C5381NP001 – Frequently Asked Questions

1) Will the Advance 72C5381NP001 ballast run my 100W metal halide lamp?
It drives one 100W metal halide lamp carrying ANSI code M90 or M140. Match the ANSI code printed on the lamp, not just the wattage: a 100W lamp with any other ANSI designation (M90 and M140 aside) is not the right lamp for this ballast. It is a single-lamp ballast, so one fixture, one lamp.
2) Can I wire this Advance metal halide ballast on 277V, or is it 120V only?
Both. The 72C5381NP001 is a dual-voltage 120/277V unit at 60 Hz, so the same part works on a 120V branch circuit in one building and a 277V lighting circuit in another. You select the voltage by which input lead you land, so keep the unused lead capped. For fleets with mixed circuits, that cuts you down to one ballast to stock.
3) Is this a pulse start or probe start metal halide ballast?
Pulse start. That means the lamp you install has to be a pulse start type as well; a probe start lamp will not operate properly on it. Pulse start pairs with the M90 and M140 ANSI codes this ballast is rated for.
4) Will an F-CAN ballast fit inside my existing fixture housing?
The F-CAN core and coil assembly measures 11.75 inches long, 3.19 inches wide and 2.63 inches high. Check those three numbers against the ballast tray or pocket in your housing before you pull the old unit, and remember it weighs 10.1 pounds, so the tray and its fasteners have to carry that load. F-CAN refers to the can style, so a retrofit into a fixture built for a different can shape may need a new mounting pattern.
5) What does high reactance mean for a metal halide ballast, and how is it different from CWA?
High reactance is the circuit type on the Advance 72C5381NP001. It is a simpler, normally-cheaper circuit than a constant wattage autotransformer, and it tolerates less line voltage swing. If your site has a soft or fluctuating supply, or the run from the panel is long, a CWA ballast holds lamp wattage steadier. On a stable 120V or 277V feed at 60 Hz, high reactance is fine, and this unit carries a 0.9 power factor so it still meets utility power factor requirements.
6) Is this ballast high power factor, and will it satisfy our utility requirement?
Power factor is 0.9, which is the high power factor threshold utilities and energy codes normally write to. That keeps line current down on the branch circuit compared with a normal power factor ballast, which matters when you are loading several fixtures on one 20A circuit.
7) Is the Advance 100W metal halide ballast UL listed for use in a government or healthcare facility?
It carries both UL and CSA certification and is RoHS compliant, and it is built to NEMA 2A. The CSA certificate is what you need for Canadian jurisdictions. For spec submittals, cite Advance model 72C5381NP001 with those marks.
8) What is the Advance part number and where is it made?
Order it as Advance 72C5381NP001. It is manufactured in the USA, which is the answer procurement teams working to domestic sourcing preferences usually need in writing.
9) Can I use this ballast on 50 Hz power overseas?
No. This one is rated 60 Hz only, so it is a North American 60 Hz application. On a 50 Hz supply the lamp current will not regulate correctly. For a 50 Hz job you need a ballast rated for that frequency.
