Milbank 200A 1-Phase Ringless Meter Socket with Horn Bypass and Glass Polyester Insulation

Milbank 200A 1-Phase Ringless Meter Socket with Horn Bypass and Glass Polyester Insulation

Professional electrical metering solution with horn bypass capability

The Milbank 200A 1-Phase Ringless Meter Socket delivers reliable electrical metering performance with horn bypass functionality for versatile installation applications. Featuring G90 galvanized steel construction with powder coat finish and glass polyester insulation, this UL Listed Type 3R unit accommodates 6 AWG to 350 kcmil wire ranges on both line and load sides with surface mount installation capability.

Professional Features & Benefits

• 200 Continuous Ampere Rating: Provides robust capacity for residential and light commercial electrical service applications with reliable current handling.
• Horn Bypass Provision: Enables flexible metering configurations and maintenance operations while maintaining electrical service continuity.
• G90 Galvanized Steel with Powder Coat Finish: Delivers superior corrosion resistance and long-term durability in outdoor installations.
• Glass Polyester Insulation: Ensures excellent electrical isolation and thermal performance for safe, reliable operation.
• 6 AWG - 350 kcmil Wire Range: Accommodates diverse conductor sizes for flexible installation and connection options.
• UL Listed Type 3R Rating: Meets stringent safety standards for outdoor use with protection against weather conditions.
• 4 Terminal Configuration: Provides secure mechanical connections for line and load conductors with ground lug provision.

Technical Specifications

• Amperage Rating: 200 Continuous Ampere
• Application: Meter Socket
• Brand Name: Milbank
• Bypass Provision: Horn Bypass
• Cable Entry: Overhead or Underground with Center Wireway
• Departent: Electrical
• Equipment Ground: Ground Lug
• Frequency Rating: 60 Hertz
• Insulation: Glass Polyester
• Line Side Wire Range: 6 AWG - 350 kcmil
• Load Side Wire Range: 6 AWG - 350 kcmil
• Main Breaker Size: No Main Breaker
• Number Of Jaws: 4 Terminal
• Number Of Main Breakers: 0
• Number Of Receptacles: 0
• Phase: 1 Phase
• Product Family Code: G200
• Product Length: 5.125 IN
• Product Material: G90 Galvanized Steel with Powder Coat Finish
• Product Mounting: Surface Mount
• Product Type: Ringless Meter Socket
• Standard: UL Listed;Type 3R
• Terminal: Single Mechanical
• Unspsc Number: 39121102
• Voltage Rating: 300 Volts Alternating Current

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Residential electrical service metering installations
• Light commercial facility power monitoring
• Multi-unit residential properties
• Outdoor electrical service applications
• Utility metering and monitoring systems
• Electrical contractor and maintenance operations

Why Choose Milbank Quality?

Milbank delivers proven reliability with UL Listed Type 3R certification and robust G90 galvanized steel construction with powder coat finish for long-term outdoor performance. The glass polyester insulation system and single mechanical terminal design ensure safe, dependable electrical metering service for professional installations.
