Milbank 200A 1-Phase Ringless Meter Socket with Lever Bypass and 5th Terminal (2)

Milbank 200A 1-Phase Ringless Meter Socket with Lever Bypass and 5th Terminal

Professional metering solution with advanced bypass capability

The Milbank 200A 1-Phase Ringless Meter Socket delivers reliable electrical metering with professional-grade lever bypass functionality and 5th terminal configuration. Constructed with G90 galvanized steel and powder coat finish in a Type 3R enclosure, this surface-mount unit provides 200 continuous ampere capacity at up to 240 volts AC with glass polyester insulation for dependable service in overhead or underground cable applications.

Professional Features & Benefits

• 200 Continuous Ampere Rating: Handles substantial electrical loads for residential and light commercial applications with reliable capacity management.
• Lever Bypass Provision: Enables safe meter maintenance and replacement without service interruption, reducing downtime and operational costs.
• 5 Terminal Configuration: Provides enhanced connectivity options with 5th terminal positioned at 9 o'clock for specialized utility requirements.
• Type 3R Enclosure Rating: Weather-resistant construction protects internal components from rain, sleet, and ice formation for outdoor installations.
• G90 Galvanized Steel Construction: Corrosion-resistant material with powder coat finish ensures long-term durability and professional appearance.
• Twin Large Closing Plates: Accommodates various cable entry configurations while maintaining proper sealing and protection.
• UL Listed Certification: Meets rigorous safety standards for code compliance and professional installation confidence.

Technical Specifications

• Amperage Rating: 200 Continuous Ampere
• Brand Name: Milbank
• Bypass Provision: Lever Bypass
• Cable Entry: Overhead or Underground
• Departent: Electrical
• Equipment Ground: Ground Lug
• Frequency Rating: 60 Hertz
• Hub Closing Plate: Twin Large Closing Plates
• Insulation: Glass Polyester
• Main Breaker Size: No Main Breaker
• Number Of Jaws: 5 Terminal
• Number Of Receptacles: 0
• Phase: 1 Phase
• Product Family Code: CUHD
• Product Length: 6 IN
• Product Material: G90 Galvanized Steel with Powder Coat Finish
• Product Mounting: Surface Mount
• Product Type: Ringless Meter Socket
• Special Features: Ameren Energy
• Standard: UL Listed;Type 3R
• Terminal: 3/8 Inch Stud
• Unspsc Number: 39121102
• Voltage Rating: Up to 240 Volts Alternating Current

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Residential electrical service installations requiring meter bypass capability
• Light commercial facilities with 200A service requirements
• Multi-unit properties needing reliable metering solutions
• Utility service upgrades and modernization projects
• Professional electrical contractor installations
• Overhead and underground service entrance applications

Why Choose Milbank Quality?

Milbank delivers proven reliability through UL Listed certification and Type 3R weather-resistant construction. The G90 galvanized steel with powder coat finish ensures long-term durability, while the professional-grade glass polyester insulation and ground lug equipment grounding provide safe, code-compliant operation for demanding electrical service applications.
