Milbank 5 Terminal Ringless Meter Socket 100A 1 Phase with Horn Bypass and 7/8" Barrel Lock

Milbank 5 Terminal Ringless Meter Socket 100A 1 Phase with Horn Bypass and 7/8" Barrel Lock

Professional 2-Position Meter Socket with Horn Bypass Provision

The Milbank 5 Terminal Ringless Meter Socket delivers reliable 100 continuous ampere service in a durable G90 galvanized steel construction with powder coat finish. This 1 phase, 300V AC rated meter socket features 2 meter positions with horn bypass provision and 7/8" barrel lock capability for enhanced security and operational flexibility in residential and commercial applications.

Professional Features & Benefits

• 100 Continuous Ampere Rating: Provides reliable power handling capacity for demanding electrical service requirements.
• 5 Terminal Configuration: Offers versatile connection options with lay-in terminals for simplified installation and maintenance.
• Horn Bypass Provision: Enables temporary power continuity during meter maintenance or replacement operations.
• G90 Galvanized Steel Construction: Delivers superior corrosion resistance and long-term durability in outdoor environments.
• Type 3R Enclosure Rating: Provides protection against rain, sleet, and ice formation for reliable outdoor performance.
• UL Listed Certification: Ensures compliance with safety standards and code requirements for professional installations.
• 7/8" Barrel Lock Provision: Includes knockout and angle bracket for enhanced security and tamper resistance.

Technical Specifications

• Amperage Rating: 100 Continuous Ampere
• Application: Meter Socket
• Barrel Lock Provision: 7/8 Inch Knockout and Angle Bracket For Barrel Lock Provision
• Brand Name: Milbank
• Bypass Provision: Horn Bypass
• Cable Entry: Overhead or Underground
• Departent: Electrical
• Equipment Ground: Ground Lug
• Frequency Rating: 60 Hertz
• Hub Closing Plate: Small Closing Plate
• Insulation: Glass Polyester
• Line Side Wire Range: 2 AWG - 350 kcmil
• Load Side Wire Range: 6 - 2/0 AWG
• Main Breaker Size: No Main Breaker
• Number Of Jaws: 5 Terminal
• Number Of Main Breakers: 0
• Number Of Meter Positions: 2 Positions
• Number Of Receptacles: 0
• Phase: 1 Phase
• Product Family Code: G125
• Product Height: 14 IN
• Product Length: 4.5 IN
• Product Material: G90 Galvanized Steel with Powder Coat Finish
• Product Mounting: Surface Mount
• Product Size: 4.5L x 24.5W x14H
• Product Type: Ringless Meter Socket
• Standard: UL Listed;Type 3R
• Terminal: Lay in
• Unspsc Number: 39121102
• Voltage Rating: 300 Volts Alternating Current
• Width: 24.5 IN

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Residential Electrical Service
• Commercial Building Metering
• Multi-Unit Properties
• Professional Offices
• Retail Establishments
• Light Industrial Facilities
• Utility Service Connections

Why Choose Milbank Quality?

Milbank delivers proven reliability with UL Listed certification and Type 3R enclosure rating for dependable outdoor performance. The G90 galvanized steel construction with powder coat finish ensures long-term durability and corrosion resistance, making this meter socket a trusted choice for professional electrical installations requiring secure, code-compliant metering solutions.
