Milbank Ringless Meter Socket ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$1,436.00
Milbank U2818-O-PSEG-DES Ringless Plain Top Test Switch Prewired Add Inhibitor Configuration 21 Public Service Electric And Gas New Jersey

Milbank Ringless Meter Socket 20A 3-Phase 600V with Plain Top Test Switch Configuration

(No reviews yet) Write a Review

Model: U2819-O-PSEG-DES

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,436.00
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Milbank Ringless Meter Socket 20A 3-Phase 600V with Plain Top Test Switch Configuration

Professional utility metering solution for commercial and industrial applications

The Milbank Ringless Meter Socket delivers reliable 3-phase power metering with 20 continuous ampere rating and 600V AC capacity. Featuring G90 galvanized steel construction with powder coat finish and Type 3R enclosure rating, this surface-mount meter socket provides durable performance for underground cable entry applications. The plain top configuration with test switch and 8-terminal design ensures professional installation flexibility.

Professional Features & Benefits

  • 20 Continuous Ampere Rating: Provides reliable current handling capacity for commercial metering applications with consistent performance under continuous load conditions.
  • 3-Phase 600V AC Configuration: Supports high-capacity electrical systems with professional-grade voltage handling for commercial and industrial installations.
  • G90 Galvanized Steel with Powder Coat Finish: Delivers superior corrosion resistance and long-term durability in outdoor and harsh environmental conditions.
  • Type 3R Enclosure Rating: Ensures protection against rain, sleet, and ice formation while providing reliable outdoor performance and weather resistance.
  • 8-Terminal Design: Offers comprehensive connection options with single mechanical terminals for secure wire termination and professional installation.
  • Underground Cable Entry: Accommodates below-grade electrical service connections with proper sealing and protection for buried cable applications.
  • UL Listed Certification: Meets rigorous safety standards and electrical codes for professional installation and regulatory compliance.

Technical Specifications

  • Amperage Rating: 20 Continuous Ampere
  • Application: Meter Socket
  • Brand Name: Milbank
  • Bypass Provision: No Bypass
  • Cable Entry: Underground
  • Departent: Electrical
  • Equipment Ground: Ground Lug
  • Frequency Rating: 60 Hertz
  • Hub Closing Plate: Plain Top
  • Insulation: Glass Polyester
  • Line Side Wire Range: 4 - 14 AWG
  • Load Side Wire Range: 4 - 14 AWG
  • Main Breaker Size: No Main Breaker
  • Number Of Jaws: 8 Terminal
  • Number Of Main Breakers: 0
  • Number Of Meter Positions: 1 Position
  • Number Of Receptacles: 0
  • Phase: 3 Phase
  • Product Family Code: CT20
  • Product Height: 20 IN
  • Product Length: 4.125 IN
  • Product Material: G90 Galvanized Steel with Powder Coat Finish
  • Product Mounting: Surface Mount
  • Product Size: 4.125L x 12W x20H
  • Product Type: Ringless Meter Socket
  • Special Features: Public Service Electric and Gas New Jersey
  • Standard: UL Listed;Type 3R
  • Terminal: Single Mechanical
  • Unspsc Number: 39121102
  • Voltage Rating: 600 Volts Alternating Current
  • Width: 12 IN

Professional Applications

  • Commercial Building Electrical Service
  • Industrial Facility Power Distribution
  • Multi-Tenant Property Metering
  • Utility Service Connections
  • Underground Electrical Systems
  • Professional Office Buildings
  • Retail and Commercial Establishments

Why Choose Milbank Quality?

Milbank delivers proven reliability with UL Listed certification and Type 3R weather protection. The G90 galvanized steel construction with powder coat finish ensures long-term durability and corrosion resistance for professional electrical installations requiring dependable utility metering performance.

Manufacturer Resources

Product Specs

Amperage Rating:
20 Continuous Ampere
Application:
Meter Socket
Brand Name:
Milbank
Bypass Provision:
No Bypass
Cable Entry:
Underground
Equipment Ground:
Ground Lug
Frequency Rating:
60 Hertz
Hub Closing Plate:
Plain Top
Insulation:
Glass Polyester
Line Side Wire Range:
4 - 14 AWG
Load Side Wire Range:
4 - 14 AWG
Main Breaker Size:
No Main Breaker
Number Of Jaws:
8 Terminal
Number Of Main Breakers:
0
Number Of Meter Positions:
1 Position
Number Of Receptacles:
0
Phase:
3 Phase
Product Family Code:
CT20
Product Height:
20 IN
Product Length:
4.125 IN
Product Size:
4.125L x 12W x20H
Product Type:
Ringless Meter Socket
Special Features:
Public Service Electric and Gas New Jersey
Standards:
UL Listed;Type 3R
Terminal:
Single Mechanical
Unspsc Number:
39121102
Voltage Rating:
600 Volts Alternating Current
Product Material:
G90 Galvanized Steel with Powder Coat Finish
Product Mounting:
Surface Mount
Amps:
20
Product Width:
12 IN
Department:
Electrical
Product Subgroup:
Electrical
Insulation Type:
Glass Polyester
Hub Style:
Plain Top
Installation Category:
Surface Mount
Terminal Type:
Single Mechanical
Number of Phases:
3
Frequency:
60 hertz
Product Details:
Ringless Meter Socket
Product Group:
Metering & Service Entrance

Milbank U2819-O-PSEG-DES – Frequently Asked Questions

1) What is the difference between the Milbank U2818-O-PSEG-DES and U2819-O-PSEG-DES meter sockets?
Terminal count is the difference. The U2818-O-PSEG-DES is the 8 terminal version and the U2819-O-PSEG-DES is the 13 terminal version. Everything else on the CT20 family socket is the same: ringless plain top, 20 continuous amp rating, 3 phase, 600V AC, Type 3R enclosure, single meter position. Pick the terminal count your utility's test switch wiring diagram calls for.
2) Is this Milbank meter socket approved for PSE&G service in New Jersey?
It is built to the Public Service Electric and Gas New Jersey specification, which is what the PSEG-DES suffix on the U2818 and U2819 catalog numbers refers to. If you are metering outside PSE&G territory, check your serving utility's approved socket list before you buy, because utility-specific sockets are not interchangeable between service areas.
3) Why is a 20 amp meter socket rated for 600 volts? Does it handle my 400 amp service?
It does not carry the service current. This is a transformer rated (CT) socket, family code CT20, so the 20 continuous amp rating applies to the secondary current coming from the current transformers, not the load. The service conductors run through separate CTs in a CT cabinet; only the small metering leads land in this socket. That is also why the wire range on both line and load side is just 4 to 14 AWG.
4) Is this meter socket set up for overhead or underground service?
Underground. Cable entry is specified as underground, and the top is a plain top with no hub opening, so there is no provision for a service entrance mast or weatherhead conduit hub on top.
5) What size wire can I land in the Milbank U2818 meter socket terminals?
Both line side and load side accept 4 through 14 AWG on single mechanical terminals. That range covers standard CT secondary metering leads. There is also a ground lug for the equipment grounding conductor.
6) Can this meter socket be installed outdoors?
Yes. The enclosure is Type 3R and UL Listed, so it is rated for outdoor use against rain, sleet and ice. The body is G90 galvanized steel with a powder coat finish for corrosion resistance, and the insulation is glass polyester.
7) Will a single-phase meter fit this socket?
No. This is a 3 phase socket at 60 hertz with an 8 or 13 terminal arrangement depending on which catalog number you order, and it holds one meter position. A single-phase self-contained meter uses a different jaw configuration and will not work here.
8) What does ringless mean on a Milbank meter socket, and can I use a ring-type cover with it?
Ringless means the cover is retained by the socket itself rather than by a sealing ring clamped around the meter, so you lift the hinged cover to access the meter. A ring-type meter is not the right pairing here, and utilities generally specify one style or the other. This one is ringless with a plain top, built to the PSE&G New Jersey spec.
