Milbank 3-Position Ring-Type Meter Socket 100A 1-Phase 600V with Small Closing Plate

Milbank 3-Position Ring-Type Meter Socket 100A 1-Phase 600V with Small Closing Plate

Professional Multi-Position Metering Solution for Electrical Service Applications

The Milbank 3-Position Ring-Type Meter Socket delivers reliable electrical metering capability with 100 continuous ampere rating and 600V AC capacity. This 1-phase vertical mount unit features G90 galvanized steel construction with powder coat finish for durability, glass polyester insulation, and UL Listed Type 3R rating for professional installations requiring multiple meter positions.

Professional Features & Benefits

• 100 Continuous Ampere Rating: Provides robust current handling capacity for demanding electrical service applications with reliable performance.
• 3-Position Configuration: Accommodates multiple meters in a single compact unit, maximizing installation efficiency and space utilization.
• Ring-Type Terminal Design: Features lay-in terminals with 6 AWG - 250 kcmil line side and 6 - 2/0 AWG load side wire ranges for versatile connection options.
• G90 Galvanized Steel Construction: Delivers superior corrosion resistance and structural integrity with powder coat finish for long-term durability.
• UL Listed Type 3R Rating: Ensures compliance with safety standards and weather resistance for outdoor installations.
• Overhead or Underground Cable Entry: Supports flexible installation methods to accommodate various service entrance configurations.
• Glass Polyester Insulation: Provides reliable electrical isolation and thermal performance for safe operation.

Technical Specifications

• Amperage Rating: 100 Continuous Ampere
• Application: Meter Socket
• Barrel Lock Provision: 7/8 Inch Knockout and Angle Bracket For Barrel Lock Provision
• Brand Name: Milbank
• Bypass Provision: No Bypass
• Cable Entry: Overhead or Underground
• Departent: Electrical
• Frequency Rating: 60 Hertz
• Hub Closing Plate: Small Closing Plate
• Insulation: Glass Polyester
• Line Side Wire Range: 6 AWG - 250 kcmil
• Load Side Wire Range: 6 - 2/0 AWG
• Main Breaker Size: No Main Breaker
• Number Of Main Breakers: 0
• Number Of Meter Positions: 3 Positions
• Number Of Receptacles: 0
• Phase: 1 Phase
• Product Family Code: GVGS
• Product Height: 31.5 IN
• Product Length: 4.188 IN
• Product Material: G90 Galvanized Steel with Powder Coat Finish
• Product Mounting: Surface Mount
• Product Size: 4.188L x 12W x31.5H
• Product Type: Ring Type Meter Socket
• Standard: UL Listed;Type 3R
• Terminal: Lay in
• Unspsc Number: 39121102
• Voltage Rating: 600 Volts Alternating Current
• Width: 12 IN

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Multi-Unit Residential Properties
• Commercial Building Electrical Services
• Apartment Complex Metering
• Small Commercial Facilities
• Professional Office Buildings
• Retail Strip Centers
• Light Industrial Applications

Why Choose Milbank Quality?

Milbank delivers proven reliability with UL Listed certification and Type 3R weather resistance rating. The G90 galvanized steel construction with powder coat finish ensures long-term durability and corrosion resistance for professional electrical installations requiring dependable multi-position metering solutions.
