Milbank Z708124-AC Connector 1p 3/0-800kcmil Below Entry

Milbank Single Pole Wire Connector 3/0-800 kcmil Aluminum Stud Mount Below Entry

(No reviews yet) Write a Review

Model: Z708124-AC

In Stock (leaves warehouse same day if ordered before 3pm ET)

$55.10
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Milbank Single Pole Wire Connector 3/0-800 kcmil Aluminum Stud Mount Below Entry

Professional metering accessory for reliable electrical connections

The Milbank single pole wire connector delivers dependable mechanical connections for conductors ranging from 3/0 AWG to 800 kcmil. Constructed from durable aluminum with stud mounting configuration, this UL Listed connector provides secure below-entry connections rated for up to 600 volts AC and 75°C operation in professional electrical installations.

Professional Features & Benefits

  • 3/0 AWG to 800 kcmil conductor range: Accommodates a wide variety of wire sizes for versatile installation applications
  • Aluminum construction: Provides excellent conductivity and corrosion resistance for long-term reliability
  • Mechanical connection type: Ensures secure, maintenance-free connections without the need for welding or soldering
  • UL Listed certification: Meets rigorous safety standards for professional electrical installations
  • 600V AC voltage rating: Suitable for standard commercial and industrial electrical systems
  • 75°C temperature rating: Handles elevated operating temperatures in demanding environments
  • Stud mount design: Facilitates secure installation and reliable mechanical attachment

Technical Specifications

  • Application: Metering Accessory
  • Brand Name: Milbank
  • Conductor Range: 3/0 AWG to 800 kcmil
  • Connection: Mechanical
  • Departent: Electrical
  • Insulation: None
  • Number Of Conductors: 1
  • Product Family Code: MSMC
  • Product Height: 1.813 IN
  • Product Length: 1.313 IN
  • Product Material: Aluminum
  • Product Mounting: Stud
  • Product Size: 1.313 In x 3.25 In x 1.813 In
  • Product Type: Wire Connector
  • Standard: UL Listed
  • Temperature Rating: 75 Degrees Celsius
  • Unspsc Number: 39121421
  • Voltage Rating: Up to 600 Volts Alternating Current
  • Width: 3.25 IN

Professional Applications

  • Electrical metering installations and meter socket connections
  • Commercial and industrial electrical distribution systems
  • Utility service entrance applications
  • Professional electrical contractor installations
  • Below-entry conductor termination requirements
  • Heavy-duty electrical connection applications

Why Choose Milbank Quality?

Milbank wire connectors provide dependable performance with UL Listed certification and aluminum construction designed for 75°C operation. The mechanical connection design ensures reliable service in professional electrical installations where secure conductor termination is essential.

Manufacturer Resources

Product Specs

Application:
Metering Accessory
Brand Name:
Milbank
Wire Size:
3/0 AWG to 800 kcmil
Connection:
Mechanical
Number Of Conductors:
1
Product Family Code:
MSMC
Product Height:
1.813 IN
Product Length:
1.313 IN
Product Size:
1.313 In x 3.25 In x 1.813 In
Product Type:
Mechanical Lug
Standards:
UL Listed
Temperature Rating:
75 Degrees Celsius
Unspsc Number:
39121421
Voltage Rating:
Up to 600 Volts Alternating Current
Product Material:
Aluminum
Product Mounting:
Stud
Product Width:
3.25 IN
Department:
Electrical
Product Subgroup:
Lugs & Terminals
Product Group:
Wire Connectors & Terminals

Milbank Z708124-AC – Frequently Asked Questions

1) How does a stud mount connector attach, and will it fit my meter socket?
It is a stud-mount lug, meaning it bolts to a threaded stud or landing pad inside the enclosure rather than clamping to a bus edge or bolting through a flat two-hole pad. The body measures 1.313 x 3.25 x 1.813 inches, so you need that much clearance around the stud and above the gutter space. It is built as a metering accessory for below-entry conductor termination, so the natural home is a Milbank meter socket or service entrance enclosure with a below-entry conductor path.
2) Can a split bolt connector be used instead of the Milbank Z708124-AC in a meter socket?
They do different jobs. The Milbank Z708124-AC is a stud-mount mechanical wire connector for a single conductor from 3/0 AWG to 800 kcmil, built as a metering accessory that bolts to a stud inside the enclosure. A split bolt such as the NSi N-SP series tin-plated copper split bolt or the NSi N series 2-wire copper split bolt is a tap/splice device that clamps two conductors to each other in free air - there is no stud mounting provision, so it will not land a service conductor on a meter socket stud. Use the split bolt where you are splicing or tapping conductor to conductor, and the stud-mount connector where the conductor has to terminate on hardware.
3) What is the difference between the Milbank Z708124-AC and a Burndy YHD compression tap?
Connection method and purpose. The Milbank Z708124-AC is a mechanical connector - the conductor is clamped with a set screw, so it can be installed and re-tensioned with hand tools and later removed. The Burndy YHD series is an aluminum compression line tap, which is crimped permanently with a die and tool and is intended to tap one line conductor to another rather than terminate a conductor on a stud. If the installation calls for a re-enterable termination on metering equipment, the mechanical stud-mount connector is the one to specify.
4) Will an aluminum connector work with copper conductors?
The Z708124-AC body is aluminum. Aluminum-bodied mechanical lugs are commonly produced as dual-rated AL9CU, but the rating we hold on this part is UL Listed with a 75 degree C temperature rating and up to 600 volts AC. Check the AL/CU marking stamped on the lug body against the conductor metal you are landing before you torque it.
5) Is this a compression lug or a mechanical set screw lug?
Mechanical. The Z708124-AC clamps the conductor with set screws, so no hydraulic crimper, die set, or torch is needed, just a hex key or socket and a torque wrench. If your spec calls for a compression termination instead, a compression type connector such as the Burndy YHD Series aluminum compression line tap is the different animal, and it requires the matching tool and die.
6) Can I use this for a two-wire tap or splice instead of a single conductor termination?
No. It is a single pole, one-conductor connector, so it terminates one conductor to a stud. For joining two conductors together, a split bolt is the right tool. The NSi Industries copper split bolt comes in a two-wire version and a tin plated version. Those are copper connectors, so match them to copper conductors.
7) I need connectors for 12 AWG branch circuit splices in the same panel job. Is this the right part?
No, this lug starts at 3/0 AWG and will not grip anything close to 12 AWG. For small branch circuit conductors use a twist-on or push-in connector such as the Ideal Industries 30-1012 INSURE connector for 12 AWG, sold in a 90-pack. Keep the Milbank stud lug for the large service entrance conductors.
8) What part number do I order, and how many do I need for a three-phase four-wire service?
Order Milbank Z708124-AC. Because it handles one conductor each, a three-phase four-wire service needs four of them, one per phase leg plus one for the neutral, per termination point. Add a ground termination separately as it is not part of this lug.
9) Is a twist-on wire connector an alternative for terminating 3/0 to 800 kcmil service conductors?
No. Twist-on connectors such as the Ideal Industries 30-1012 INSURE are sized for small branch-circuit conductors around 12 AWG and are sold in bulk packs for device-box splices. The Milbank Z708124-AC covers 3/0 AWG to 800 kcmil on a single conductor with an aluminum mechanical body rated up to 600 volts AC at 75 degrees Celsius, which is the class of hardware service-entrance and metering terminations require.
10) When would a Burndy IMPLO implosive connector be specified instead of the Milbank Z708124-AC?
The Burndy IMPLO 9 Series and the Burndy 9052 implosive connectors are installed by an implosive charge and are used for permanent conductor splices, typically on overhead or transmission conductors. The Milbank Z708124-AC is a stud-mount mechanical connector carrying a UL Listed marking, intended for below-entry conductor termination in metering and service equipment. Choose the implosive connector for a permanent in-line splice in the field; choose the Milbank unit when the conductor must land on a stud inside an enclosure.
11) Does this connector come insulated, or do I need to tape or boot it?
It ships bare. There is no insulation on the body, which is normal for a lug landing inside a meter socket or service enclosure where the enclosure itself provides the barrier. If your installation needs the termination covered, plan on a separate insulating boot or tape per your spec. The lug is rated up to 600 volts AC.
12) Will a Wiremold pressure-type wire connector work in place of the Milbank Z708124-AC?
No. The Wiremold W30/W30G pressure-type connectors are steel components belonging to the 2000 Series raceway system and are intended for connections within that surface raceway. The Milbank Z708124-AC is an aluminum stud-mount connector measuring 1.313 in x 3.25 in x 1.813 in and sized for a single 3/0 AWG to 800 kcmil conductor in metering equipment - different material, different mounting, and a conductor range the raceway part does not address.
