MS Sedco 59J Series Jamb Style...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$71.00
$62.90
MS Sedco MS Sedco 59J Series Jamb Style Push Plate Switches MSS-59J

MS Sedco 59J Series Jamb Style Push Plate Switch for Automatic Doors

(No reviews yet) Write a Review

Model: 59J-HSS

In Stock (leaves warehouse same day if ordered before 3pm ET)

$71.00
$62.90
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

MS Sedco 59J Series Jamb Style Push Plate Switch for Automatic Doors

The MS Sedco 59J Series Jamb Style Push Plate Switch delivers a sleek, low-profile activation solution engineered for automatic doors in high-traffic commercial environments. Featuring a 1 1/2" x 4 1/4" all-active face plate and a 1 11/16" x 4 1/2" formed stainless steel back plate, the 59J Series is purpose-built for jamb-style mounting on 1-3/4" frames or MS Sedco surface mount boxes. The UL Listed SPDT momentary contact switch ensures code-compliant, dependable activation, while architectural-grade finishes and industrial-grade components provide long-term reliability. ADA and ANSI standards compliance makes this switch a trusted choice for professionals across new installations and retrofit projects alike.

Key Features

  • All-Active Face Plate Dimensions: 1 1/2" x 4 1/4" all-active face plate ensures consistent, full-surface activation for reliable door triggering.
  • Formed Stainless Steel Back Plate: 1 11/16" x 4 1/2" formed stainless steel back plate protects the door frame from wear and damage during repeated use.
  • UL Listed SPDT Switch: Momentary contact design provides reliable, code-compliant activation suitable for commercial automatic door applications.
  • Mounting Compatibility: Designed to fit 1-3/4" frames or MS Sedco surface mount boxes for flexible installation in a variety of door frame configurations.
  • Available Faceplate Styles: Choose from stainless steel with etched and paint-filled legends, or blue powder-coated aluminum with engraved legends to match architectural requirements.
  • Special Finish Options: Available in US3, US4, US10, US10B, and US32 finishes to complement a wide range of commercial interior aesthetics.
  • Wireless Versions Available: Optional radio control compatibility provides wireless activation capability for installations where wired connections are impractical.

Certifications & Compliance

  • UL Listed SPDT Switch
  • ADA Compliant
  • ANSI Standards Compliant

Technical Specifications

  • Faceplate: 1.5" x 4" all-active, formed stainless steel
  • Backplate: 1.625" x 4.5" formed stainless steel
  • Switch: UL Listed Microswitch SPDT, momentary, NO/NC/COM with wire leads, 15A @ 125VAC
  • Mounting: Fits 1.75" doorframe, or MS Sedco #1010/#1035 surface boxes (sold separately)
  • Options: Wireless version available; IP68 weatherproof option available
  • Warranty: 3 years from date of purchase

Typical Applications

  • Commercial Office Buildings with Automatic Entry Doors
  • Healthcare Facilities and Hospitals Requiring Hands-Free Access
  • Educational Institutions and Campus Buildings
  • Retail Establishments and Shopping Centers
  • Government and Municipal Buildings
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential and Hospitality Properties

Why MS Sedco 59J?

MS Sedco 59J Series push plate switches are built with architectural-grade finishes and industrial-grade components, delivering the durability and low-profile performance demanded by high-traffic commercial door applications. The UL Listed SPDT momentary contact switch, combined with a formed stainless steel back plate and all-active face plate, ensures consistent, code-compliant activation across new installations and retrofits. Engineered to meet ADA and ANSI standards, the 59J Series reflects MS Sedco's commitment to reliable, professional-grade door activation solutions.

Product Specs

Product Group:
Electronic Access Controls
Series:
59 Series
Product Subgroup:
Sensors, Switches, Relays and Timers
Product Type:
Push Plate Switches
Subcategory:
Switches
Commercial/Residential:
Commercial
Electronic:
Yes
Tags:
ms sedco push plates, mssedco
Product Model:
59J
Product Category:
Electronic Access Controls
Department:
Door Hardware

MS Sedco 59J-HSS – Frequently Asked Questions

1) Will the MS Sedco 59J push plate fit a 1-3/4 inch door frame?
That's exactly the opening it's built for. The 59J is a jamb-style plate, narrow enough to land on a 1-3/4 inch doorframe face. If your frame is narrower than that, or you're mounting on glass, block, or anywhere without a jamb face to drill, use an MS Sedco #1010 or #1035 surface box instead and mount the plate to that. Those boxes are ordered separately.
2) How big is the 59J narrow push plate and how much of it actually activates the door?
The face plate measures 1 1/2 by 4 1/4 inches and is all-active, so any point on the plate face triggers the switch, not just a center button. Behind it, the formed stainless back plate is 1 11/16 by 4 1/2 inches and takes the wear on the jamb. The all-active face matters on high traffic openings: a user hitting the plate with an elbow, a hip, or a cart edge still gets activation.
3) What switch contacts does the MS Sedco 59J have, and can I wire it into an existing automatic door operator?
It's a UL Listed SPDT momentary microswitch with normally open, normally closed, and common wire leads, rated 15A at 125VAC. Because you get both NO and NC off the same plate, it drops onto a standard operator activation input either way, and the same plate can drive an access control input or a relay that wants a normally closed loop. Momentary contact means it pulses on press and releases, which is what a low energy door operator expects.
4) Is the MS Sedco 59J push plate ADA compliant?
ADA and ANSI compliant, and the switch itself is UL Listed. The all-active face is a large part of why: the full 1 1/2 by 4 1/4 inch plate responds, so there's no small button a user has to find and press. For healthcare, education, and government work where the activation device gets inspected along with the operator, that combination is what an inspector is looking for.
5) Can I use a 4-1/2 inch square push plate in place of a narrow jamb push plate?
Only where the mounting surface is wide enough to take it. The Camden CM-46 is a 4-1/2 inch square push plate switch, so it needs roughly four and a half inches of flat surface in both directions. The MS Sedco 59J is built for the opposite condition: a 1 1/2 inch by 4 1/4 inch all-active face plate on a 1 11/16 inch by 4 1/2 inch back plate, dimensioned to fit a 1-3/4 inch door frame. On a standard hollow metal jamb face there is no room for a square plate, which is why the narrow 59J exists as its own form. Both are push plate switches and both activate an automatic operator; the choice between them is decided by the surface you are mounting to, not by the function.
6) What is the difference between the MS Sedco 59J push plate switch and the Camden CM-46?
The two differ in plate geometry and where they are meant to land. The MS Sedco 59J is a narrow jamb style switch with a 1 1/2 inch by 4 1/4 inch all-active face plate and a 1 11/16 inch by 4 1/2 inch formed stainless steel back plate, sized to sit on a 1-3/4 inch door frame or an MS Sedco #1010/#1035 surface box. The Camden CM-46 is a 4-1/2 inch square push plate switch, a plate form that goes on a wall, a bollard, or a mounting box rather than on the face of a frame member. If the activation point is the jamb itself, the narrow 59J is the shape that fits it; if the activation point is a flat wall surface beside the opening, the square CM-46 covers that.
7) Which legend and finish options does the 59J jamb plate come in?
Three faceplate versions: stainless steel with a black legend, stainless steel with a blue legend, and a blue background with a white legend. Stainless plates carry etched and paint-filled legends; the blue is powder-coated aluminum with an engraved legend. If you're matching plates already installed down a corridor, the legend color is the thing to match, since all three share the same narrow jamb footprint. Special finishes are offered in US3, US4, US10, US10B, and US32.
8) Can I get a wireless version of the 59J so I don't have to pull wire to the jamb?
A wireless version is offered, using radio control instead of a hard-wired run to the operator. That's the option to specify on retrofits where the jamb is already closed up, the opening is across a lobby from the operator, or you'd otherwise be coring an existing frame. Order it as the wireless variant rather than trying to convert a wired plate on site.
9) Will an MS Sedco 59J hold up on an exterior door exposed to weather?
For an exterior jamb, specify the IP68 weatherproof option. The standard 59J is a stainless faced plate with a formed stainless back plate, which handles interior high traffic fine, but driven rain and washdown are what the IP68 version exists for. Call it out on the order; it isn't something added later.
10) What else do I need to order with a 59J push plate switch?
On a 1-3/4 inch frame, nothing extra: the plate mounts to the jamb and lands on the operator's activation input via the NO/NC/COM leads. Anywhere you can't drill a jamb, add an MS Sedco #1010 or #1035 surface mount box, which ships separately. Decide the legend and finish at the same time, and flag wireless or IP68 up front, since both change what gets built.
11) Which push plate switch should I specify for an exterior automatic entrance where the plate is exposed to weather?
The MS Sedco 59J is offered with an IP68 weatherproof option and a wireless radio control version, which covers exterior jamb mounting and openings where running wire to the activation point is impractical. Its switch is a UL Listed SPDT microswitch, momentary, NO/NC/COM with wire leads rated 15A at 125VAC, so it drops into the same dry contact input an operator expects. The Camden CM-46 is a 4-1/2 inch square push plate switch and is the other plate form to consider when the activation point is a wall or a bollard rather than the frame face. For an exposed exterior jamb specifically, the weatherproof 59J is the one built for that condition.
