Burndy Aluminum Multiple Tap Connector 4-Port 10 AWG-250 kcmil with Plastisol Insulation

Burndy Aluminum Multiple Tap Connector 4-Port 10 AWG-250 kcmil with Plastisol Insulation

Professional electrical connection solution for multiple conductor applications

The Burndy aluminum multiple tap connector delivers reliable electrical connections for professional installations requiring multiple conductor terminations. This 4-port connector accommodates copper stranded conductors from 10 AWG to 250 kcmil and aluminum conductors from 8 AWG to 250 kcmil, featuring clear Plastisol insulation and 600V minimum voltage rating for versatile electrical distribution applications.

Professional Features & Benefits

• 4-Port Design: Enables multiple conductor connections in a single compact unit, reducing installation time and connection points
• Wide Conductor Range: Accommodates 10 AWG-250 kcmil copper stranded and 8 AWG-250 kcmil aluminum conductors for flexible application compatibility
• 600V Voltage Rating: Provides reliable performance in commercial and industrial electrical systems with appropriate voltage capacity
• Plastisol Insulation: Clear insulated design offers protection while allowing visual inspection of connections
• UL Listed Compliance: Meets UL468A-468B industry standards ensuring code compliance and professional installation requirements
• Aluminum Construction: Unplated aluminum hardware provides corrosion resistance and reliable conductivity for long-term performance
• CSA Certified: Canadian Standards Association certification expands installation approval for North American markets

Technical Specifications

• Aluminum Size Range: 8 AWG-250 kcmil
• Copper Solid Size Range: N/A
• Copper Stranded Range: 10 AWG-250 kcmil
• Csa Certified: Y
• Culus: N
• Height In: 2.13
• Hex Size Key: 16-May
• Industry Standards: UL468A-468B
• Insulation Type: Plastisol
• Length In: 3.91
• Min Voltage Rating: 600
• Number Of Ports: 4
• Number Of Screws: 4
• Plated Yes Or No: N
• Product Description: Aluminum Multiple Tap Connector, Clear Insulated, 4 Port, 1 Sided Entry, 10 AWG-250 kcmil, Al/Cu Ra
• Rated For Direct Burial: N
• Rohs Compatible: Compliant
• Type Of Hardware: Aluminum
• Type Of Plating: Unplated
• Ul Listed: Y
• Ul Recognized: N
• Width In: 2.07

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Commercial electrical distribution systems
• Industrial power distribution panels
• Multi-circuit branch connections
• Electrical service upgrades and expansions
• Professional electrical installations requiring multiple tap connections
• Code-compliant electrical junction applications

Why Choose Burndy Quality?

Burndy multiple tap connectors provide professional-grade reliability with UL Listed and CSA Certified approvals, ensuring code compliance and long-term performance. The RoHS compliant construction and industry standard compliance deliver the quality and durability expected from Burndy electrical connection solutions.
