Norton Rixson 994M Wall Mounted Electromagnetic Door Holder with Adjustable Armature and Tri-Volt Operation

Norton Rixson 994M Wall Mounted Electromagnetic Door Holder with Adjustable Armature and Tri-Volt Operation

(No reviews yet) Write a Review

Model: RIX-994M 689
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$725.54
$416.71
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Norton Rixson 994M Wall Mounted Electromagnetic Door Holder with Adjustable Armature and Tri-Volt Operation

Professional Fire-Rated Door Control Solution

The Norton Rixson 994M electromagnetic door holder delivers reliable fire-rated door control with wall-mounted installation and adjustable armature design. This Grade 1 certified unit features tri-volt operation (120VAC, 24VAC/DC, 12VDC) with 25-40 lbs. holding force standard, expandable to 50-55 lbs. with voltage specification. The concealed wiring design and 3-3/4" total projection provide clean installation aesthetics while the adjustable armature allows rotation up and down, back and forth for optimal door alignment on solid wood doors.

Professional Features & Benefits

  • Adjustable Armature Design: Rotation up and down, back and forth for precise door alignment and optimal holding performance in various installation conditions.
  • Tri-Volt Operation: Standard 120VAC, 24VAC/DC, 12VDC compatibility provides flexible integration with existing fire alarm and access control systems.
  • Variable Holding Force: 25-40 lbs. standard holding force with option for 50-55 lbs. when voltage is specified for heavy-duty applications.
  • Concealed Wiring Installation: Clean professional appearance with 3-3/4" total projection and hidden wire routing through wall-mounted design.
  • Fail-Safe Operation: Power failure automatically releases door to close, ensuring fire safety compliance and emergency egress functionality.
  • Grade 1 Certification: ANSI/BHMA A156.15 Grade 1 rating and UL-cUL fire-rated up to 3 hours for demanding commercial applications.
  • Flexible Configuration: Can be used without adjustment piece as model 997M, and requires 2" x 4" x 2-1/2" outlet box with proper wall reinforcement.
  • Manufacturer Warranty: 2-year limited warranty for added confidence and protection in commercial installations.

Technical Specifications

  • ANSI/BHMA: ANSI/BHMA A156.15, Grade 1
  • Application: Commercial Doors
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Hand Direction: Non-Handed
  • Electronic: Yes
  • Grade: Grade 1
  • Mounting Method: Wall
  • Product Category: Door Controls
  • Product Finish: Aluminum
  • Product Group: Door Controls
  • Product Subgroup: Electromagnetic Door Holder / Releases
  • Product Type: Electromagnetic Door Holder / Releases
  • Product Voltage: 120VAC, 24VAC/DC, 12VDC
  • Subcategory: Electromechanical Closers & Holders
  • Warranty: 2 Year Limited
  • Wiring: Concealed

Installation & Operation

  1. Verify electrical requirements match available power supply. Confirm voltage (120VAC, 24VAC/DC, or 12VDC) and current capacity before proceeding.
  2. Disconnect power supply before beginning installation. Follow all applicable electrical codes and safety procedures.
  3. Mount the unit in the specified location ensuring adequate clearance for wiring access, ventilation, and future service requirements.
  4. Route and connect wiring according to manufacturer wiring diagrams. Use appropriate wire gauge and connectors for the application.
  5. Configure operational settings including fail-safe operation per application requirements.
  6. Restore power and test all functions including normal operation, alarm/alert functions, and integration with connected systems.
  7. Complete final inspection and document settings. Refer to manufacturer documentation for complete wiring diagrams, programming instructions, and troubleshooting.

Professional Applications

  • Commercial Building Fire Safety Systems
  • Educational Facility Emergency Egress
  • Healthcare Institution Fire Door Control
  • Retail Establishment Safety Compliance
  • Industrial Facility Fire Protection
  • Government and Municipal Building Safety
  • Multi-Tenant Residential Fire Systems

Why Choose Norton Rixson Quality?

Norton Rixson electromagnetic door holders deliver professional-grade reliability with Grade 1 ANSI/BHMA certification and UL-cUL fire rating up to 3 hours. The 2-year limited warranty and fail-safe operation provide confidence in critical fire safety applications. Engineered for demanding commercial applications where dependable fire door control and emergency egress performance is essential.

Product Specs

Condition:
New
Grade:
Grade 1
Warranty:
2 Year Limited
ANSI/BHMA:
ANSI/BHMA A156.15, Grade 1
Product Group:
Door Controls
Product Subgroup:
Electromagnetic Door Holder / Releases
Product Type:
Electromagnetic Door Closers
Subcategory:
Electromechanical Closers & Holders
Commercial/Residential:
Commercial
Electronic:
Yes
Application:
Commercial Doors
Wiring:
Concealed
Product Voltage:
120VAC, 24VAC/DC, 12VDC
Product Finish:
Aluminum
Door Hand Direction:
Non-Handed
Mounting Method:
Wall
Product Category:
Door Controls
Department:
Door Hardware

Norton Rixson RIX-994M 689 – Frequently Asked Questions

1) What happens to the door if the power drops on a Norton Rixson 994M electromagnetic holder?
Loss of power releases the door. The 994M magnet drops out on power failure so the door closer can pull the opening shut, which is how it satisfies fire door duty on an alarm signal. Wire it to a fire alarm relay that opens on alarm and the door closes on both alarm and any power loss.
2) How far off the wall does the Norton Rixson 994M stick out, and will it reach my door?
Total projection is 3-3/4 inches from the wall. The armature is adjustable, rotating up and down and back and forth, so you can square the strike plate to the door face where the door doesn't sit perfectly parallel to the wall. If your door swings back further than 3-3/4 inches from the wall face, this wall unit won't make contact and you need a floor-mounted holder or an extended wall bumper instead.
3) What do I need in the wall before installing a Norton Rixson 994M holder?
Plan for a 2 inch x 4 inch x 2-1/2 inch outlet box behind the unit, plus reinforcement in the wall at that point. Wiring runs concealed through the box, so the rough-in has to be set before the drywall closes up. The magnet pulls against the wall every time the door is caught, which is why the blocking matters as much as the box.
4) Is the Norton Rixson 994M approved for use on a fire rated door?
Yes. The 994M carries an ANSI/BHMA A156.15 Grade 1 rating and is UL-cUL fire rated up to 3 hours, which is what an inspector looks for on a hold-open at a rated corridor or cross-corridor opening.
5) Do I have to order a Norton Rixson 994M in a handed version for a left hand door?
No handing to specify. The 994M is non-handed, so one part number covers left and right hand openings. That's useful on a building where you're standardizing holders across a corridor: order the quantity and the finish, and it works on every door regardless of swing direction.
6) What is the difference between the Norton Rixson 994M and the 997M?
Same unit, different configuration. The 994M includes the adjustable armature piece that lets you rotate the armature up and down and back and forth to align with the door. Run it without that adjustment piece and it becomes the 997M. Choose the 994M when the door face and wall aren't parallel or the strike needs to be trued up on site; the 997M is the simpler fixed setup.
7) Does an electromagnetic door holder replace the door closer, or do I still need one?
You still need a closer. A magnetic holder like the 994M only catches the door in the open position and releases it on alarm or power loss; it has no mechanism to swing the door shut. The closer does the closing. Budget both on any fire rated opening you want to hold open.
