Norton Rixson M190 Heavy Duty ...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$595.13
$351.91
Norton Rixson Norton Rixson Model M190 - Heavy Duty Full Mortise Intermediate Pivots RIX-M190

Norton Rixson M190 Heavy Duty Full Mortise Intermediate Pivot with 3/4" Offset

(No reviews yet) Write a Review

Model: M190-RH-626
$595.13
$351.91
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$595.13
$351.91
Adding to cart… The item has been added
Free Shipping on orders over $99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Norton Rixson M190 Heavy Duty Full Mortise Intermediate Pivot with 3/4" Offset

Professional Intermediate Pivot Solution for Challenging Frame Conditions

The Norton Rixson M190 is a heavy-duty full mortise intermediate pivot designed for applications where frame conditions do not allow standard top pivot installation. This load-bearing pivot features a 3/4" (19mm) offset standard configuration and is engineered for doors 60" (1524mm) to 90" (2286mm) in height. Constructed with non-ferrous base metal and heavy-duty needle bearings, the M190 maintains proper door alignment while providing lateral load-bearing support for demanding commercial applications.

Professional Features & Benefits

  • Heavy-Duty Construction: Full mortise design with non-ferrous base metal and heavy-duty needle bearings for exceptional durability in commercial applications.
  • Offset Configuration: 3/4" (19mm) standard offset with 1-1/2" (38mm) offset option available for versatile installation requirements.
  • Load-Bearing Design: Lateral load-bearing capability maintains door alignment and aids in installing floor closers and bottom pivots.
  • Door Height Compatibility: Designed for doors 60" (1524mm) to 90" (2286mm) in height with additional pivots recommended for each additional 30" (762mm).
  • Fire Door Option: Available for fire door assemblies with ferrous material construction (specify FM190) including 20-minute label option.
  • Complete Hardware Package: Furnished with wood and machine screws for immediate installation.
  • Manufacturer Warranty: 2-year limited warranty for added confidence and protection.
  • CAL FIRE Certification: Certain models certified CAL FIRE, 3725-0047:0108 for code compliance applications.

Technical Specifications

  • Application: Standard Door
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Door Hand Direction: Handed
  • Duty Level: Heavy Duty
  • Electronic: No
  • Fasteners: Torx Screws Optional
  • Fire Rating: No
  • Hang Type: Offset Hung
  • Mounting Method: Center Hung
  • Pivot Type: Top & Bottom
  • Product Attribute: Pivots
  • Product Category: Door Hinges and Pivots
  • Product Group: Door Hinges and Pivots
  • Product Subgroup: Pivots and Pivot Sets
  • Product Substrate: Non-ferrous
  • Product Type: Intermediate Pivots - Offset
  • Series: M190
  • Subcategory: Intermediate Pivots
  • Warranty: 2 Year Limited

Installation & Operation

  1. Review manufacturer specifications and verify door preparation requirements including door thickness, stile width, and handing as applicable to this product.
  2. Use manufacturer-provided templates to mark mounting hole locations accurately on door and frame surfaces.
  3. Prepare door and frame by drilling required holes and routing as specified in manufacturer instructions.
  4. Install all mounting hardware and secure the device to door and frame per manufacturer torque specifications.
  5. Adjust operational components for proper alignment, latching, and smooth operation throughout the full range of motion.
  6. Test device operation to verify proper function and make final adjustments as needed. Refer to manufacturer documentation for complete installation details and troubleshooting.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Norton Rixson Quality?

Norton Rixson intermediate pivot products deliver professional-grade reliability with heavy-duty needle bearing construction and non-ferrous base metal materials. Backed by a 2-year limited warranty and CAL FIRE certification on select models, the M190 series is engineered for demanding commercial applications where dependable door alignment and load-bearing performance are essential.

Product Specs

Series:
M190
Duty Level:
Heavy Duty
Hang Type:
Offset Hung
Warranty:
2 Year Limited
Product Group:
Door Hinges and Pivots
Product Subgroup:
Pivots and Pivot Sets
Product Type:
Intermediate Pivots
Subcategory:
Intermediate Pivots
Fasteners:
Torx Screws Optional
Commercial/Residential:
Commercial
Electronic:
No
Pivot Type:
Top & Bottom
Mounting Method:
Center Hung
Application:
Standard Door
Product Attribute:
Pivots
Door Hand Direction:
Handed
Fire Rating:
No
Product Category:
Door Hinges and Pivots
Product Substrate:
Non-ferrous
Department:
Door Hardware

Norton Rixson M190-RH-626 – Frequently Asked Questions

1) What is the Norton Rixson Model M-190 intermediate pivot used for?
The M-190 is a heavy-duty full mortise intermediate pivot designed for use between the top and bottom pivots on tall or heavy doors. It provides additional support and alignment for doors that exceed standard height or weight requirements.
2) What door sizes and weights are compatible with the M-190 pivot?
The M-190 is designed for heavy-duty applications with large commercial doors. Verify specific door dimensions and weight capacity with the manufacturer's specifications. Typically used on doors over 8 feet tall or exceeding standard weight limits.
3) Is this pivot handed for left or right swing doors?
The M-190 intermediate pivot is typically non-handed and can be used on both left and right swing doors. The pivot mechanism is symmetrical for universal application between top and bottom pivots.
4) What finishes are available for the Norton Rixson M-190?
Norton Rixson typically offers standard architectural finishes including satin chrome, bright chrome, and bronze options. Verify available finishes for your specific application as options may vary by model configuration.
5) What is the load capacity and duty rating of this intermediate pivot?
The M-190 is rated for heavy-duty commercial applications. Exact load capacity depends on door configuration and other pivot components in the system. Consult Norton Rixson specifications for precise load ratings with your door assembly.
6) Does this pivot meet commercial building code requirements?
Norton Rixson pivots are designed to meet commercial building codes when properly installed. Verify local code requirements for your specific application. The M-190 is suitable for commercial door installations requiring intermediate support.
7) What parts and accessories are included with the M-190 pivot?
The M-190 includes the intermediate pivot mechanism and mounting hardware. Installation templates and specific fasteners may be included. Check with manufacturer specifications for complete parts list and any separately ordered accessories.
8) How is the M-190 intermediate pivot installed?
Installation requires mortising into both the door edge and frame jamb at the intermediate location. Use manufacturer templates for precise positioning. Coordinate with top and bottom pivot locations for proper door alignment and operation.
9) Can the M-190 pivot be adjusted after installation?
Intermediate pivots typically have limited adjustment compared to top and bottom pivots. Primary door adjustments are made at the top and bottom pivot points. The M-190 provides fixed intermediate support once properly installed.
10) What other Norton Rixson pivot models work with the M-190?
The M-190 is designed to work with compatible Norton Rixson top and bottom pivot sets in the same product series. Consult with Norton Rixson pivot hardware specifications to ensure proper system compatibility.
11) What environmental conditions can the M-190 pivot handle?
The M-190 is designed for interior commercial applications with standard environmental conditions. For exterior or harsh environment applications, verify material compatibility and finish durability with manufacturer specifications.
12) What are the key measurements needed for ordering the M-190?
Key measurements include door thickness, frame jamb depth, and intermediate pivot location height from floor. Verify mortise dimensions and clearance requirements from manufacturer templates before ordering and installation.
