3 in. or 4 in. PVC 9 in. x 9 in. Bell Trap Drain
43633 - spec sheet
Features
- Water drains into a well in the drain that serves as a trap to contain sewer gas
- 9 x 9 in. square bell trap drain
- Body and drain cover made of durable PVC
- Strainer snaps into the drain body
- Allows for quick and easy installation
- Bell trap drain solvent welds to drain pipe
- Fits over 3 in. or inside 4 in. PVC Sch. 40 DWV pipe
- PVC bell trap floor drain
- Ideal for use with garage, patio and outdoor drains
43633 - spec sheet
Manufacturer Resources
Product Specs
- Drain Orientation:
- General Purpose
- Volume:
- 0.243
- Department:
- Plumbing
- Product Group:
- Plumbing
- Product Subgroup:
- Drainage Products
- Product Type:
- Drain
- Product Finish:
- White
- Product Material:
- PVC
- Product Weight:
- 2.325
OATEY 43633 – Frequently Asked Questions
1) What is a bell trap drain and do I still need a P-trap under it?
A bell trap holds water in a well built into the drain body, and that standing water is what blocks sewer gas from coming back up through the grate. The Oatey 43633 has that trap integral to the 9 x 9 inch body, so the trap function is built in rather than piped separately below the floor. It is meant for general purpose drainage such as garages, patios and outdoor areas.
2) How big is the opening I need to frame or core for an Oatey 43633 bell trap?
The drain body is a 9 by 9 inch square, so the block-out in the slab or deck has to accept that footprint plus the pipe stub below it. Plan the pour around the square body rather than a round core, and set the grate flush with finished grade so water sheets into it.
3) Is the Oatey 43633 grate removable for cleaning out debris?
The strainer snaps into the drain body, so it lifts out by hand when the trap well silts up with leaves or sand. That matters on a patio or garage drain, because the water well that blocks sewer gas is also where debris collects, and a bell trap needs periodic cleaning to keep draining.
4) Will a PVC bell trap drain hold up outdoors in a garage or patio slab?
Both the body and the cover are PVC, which is what makes it suitable for garage, patio and outdoor drains where a metal grate would corrode. It is a white PVC assembly, not a cast or coated metal drain, so it is not the part to pick where vehicle or heavy load traffic runs directly over the grate.
5) What do I need to order alongside the Oatey 43633 to finish the install?
The drain comes as a body with a snap-in strainer, so on the job you supply the PVC DWV pipe and the PVC solvent cement and primer to weld the connection. Order the bell trap as model 43633. Nothing else bolts to it, there is no clamping ring or separate trap to buy.
