Panduit DB-C Divider Wall Mounting Base, Black, Polycarbonate
The Panduit DB-C Divider Wall Mounting Base, Black, Polycarbonate mounts inside any type of Panduit PVC wiring duct to create multiple wiring channels for improved cable organization and circuit separation. Measuring 0.19" x .65" (4.8 mm x 16.5mm), this polycarbonate mounting base snaps together with the matching Panduit divider wall once installed, and secures using Panduit NR1 or #8, #10, M4, or M5 fasteners. It carries a UL 94 flame class of V-0 with a UL recognized continuous-use temperature up to 122°F (50°C), and ships in a convenient 100-piece (PK100) package for wiring duct installation projects.
Key Features
- Compact Profile: 0.19" x .65" (4.8 mm x 16.5mm) mounting base fits inside Panduit PVC wiring duct for channel separation.
- Durable Construction: Molded from polycarbonate for long-lasting performance in wiring duct installations.
- Flexible Fastening: Compatible with Panduit NR1 or #8, #10, M4, or M5 fasteners for secure mounting.
- Flame Rating: UL 94 flame class of V-0 for added safety in electrical enclosures and panels.
- Temperature Rated: UL recognized continuous-use temperature up to 122°F (50°C) for reliable performance.
- Universal Fit: Mounts inside any type of Panduit PVC wiring duct to create multiple channels.
- Color: Black finish for a consistent, professional appearance across wiring duct systems.
- Bulk Package: Sold in a 100-piece (PK100) package to support larger duct installation jobs.
Certifications & Compliance
- Standards Met: UL508/508A
- RoHS Compliant
- UL 94 Flame Class V-0
Technical Specifications
- Std. Pkg. Qty.: 100
- UOM EA PK: PK
- Country of Origin: United States
- Dimensions: 0.19" x .65" (4.8 mm x 16.5mm)
- Continuous-Use Temperature: Up to 122°F (50°C)
Typical Applications
- Panduit PVC Wiring Duct Channel Separation
- Commercial and Industrial Electrical Panel Wiring
- Control Panel and Enclosure Cable Management
- Data Center and Telecommunications Wiring Duct Installations
- New Construction and Wiring Duct Retrofit Projects
Why Panduit?
Panduit engineers the DB-C Divider Wall Mounting Base with a UL 94 V-0 flame class rating and polycarbonate construction for reliable, code-compliant performance in demanding wiring duct installations. Backed by UL508/508A standards and RoHS compliance, this mounting base delivers the durability, precise fit, and safety that electrical professionals expect from Panduit wiring duct accessories on every job.
Manufacturer Resources
Product Specs
- Standard Package Volume Ft3:
- 0.0230
- Standard Package Weight Pounds:
- 0.2000
- REACH Status:
- N
- Std. Pkg. UOM:
- Piece
- Std Carton Length In:
- 8.5
- Screw Size:
- #8, #10, M4 or M5
- California Pro65 Cancer:
- No
- Std Carton Height In:
- 5.95
- Application:
- Installation of Wiring Duct Divider Walls
- Std Package Length In:
- 5.45
- Country of Origin:
- United States
- Standard Carton Volume Ft3:
- 0.2298
- Std Package Length MM:
- 138.43
- Lead Content Indicator:
- N
- Mercury Content Indicator:
- N
- Std Carton Width In:
- 8.1
- Sub Brand:
- Panduct®
- Std Ctn Qty:
- 1000
- Product Segment:
- IEI
- Product Type:
- Duct Divider Wall Mounting Base
- GTIN Carton:
- 50074983348775
- Std Carton Height MM:
- 151.13
- Std Package Width MM:
- 127
- Pallet Quantity:
- 200,000
- Std Package Height In:
- 1
- Flammability Rating:
- UL94 V-2
- Standard Carton Weight Pounds:
- 2.0000
- Std Package Height MM:
- 25.4
- Min Order Qty:
- 1,000.0000
- RoHS Compliant:
- Compliant
- GTIN Package:
- 00074983348770
- Min. Order UOM:
- Piece
- ARRA Compliant:
- Y
- Std. Pkg. Qty.:
- 100
- Std Carton Length MM:
- 215.9
- Std Carton Width MM:
- 205.74
- UOM EA PK:
- PK
- Pallet Volume:
- 45.956250
- Std Package Width In:
- 5
- Hazardous Material Flag:
- N
- Any Reason Not to Sell:
- N
- Restricted Use of Hazardous Substances:
- N
- Pallet Weight:
- 400.0000
- Product Color:
- Black
- Department:
- Electrical
- Product Group:
- Wiring Devices
- Pack Size:
- 100
Panduit DB-C – Frequently Asked Questions
1) What does the Panduit DB-C divider wall mounting base actually do in a wiring duct?
The DB-C is the mounting foot for a Panduit divider wall. It fastens to the floor of the duct, and the divider wall snaps into it, splitting a single run of Panduit PVC wiring duct into separate channels. That is how you keep power and control conductors apart inside one duct instead of running two ducts. The base is sold on its own, so you order the matching divider wall separately to complete the assembly.
2) What screws do I need to mount the Panduit DB-C base, and are they included?
Fasteners are not included. The base takes a Panduit NR1 rivet or a #8, #10, M4 or M5 screw. On a control panel build most people use the NR1 so nothing protrudes through the back of the duct into the subpanel; if you are screwing through, watch your screw length against whatever is behind the duct.
3) How many DB-C bases come in a package and what is the minimum I can order?
They come 100 pieces to a package, with 1,000 pieces (ten packages) to a standard carton. The order minimum is 1,000 pieces, so this is a carton-quantity item rather than something you pick up by the handful. A full package weighs about 0.2 lb; a carton about 2 lb.
4) Can the Panduit DB-C divider base handle the heat inside a loaded control panel?
The polycarbonate base carries a UL recognized continuous-use temperature up to 122 F (50 C). That covers most enclosed panel and data center environments, but if your enclosure runs hotter than that around drives or transformers, it is outside the rated range.
5) Does the Panduit DB-C meet RoHS and Buy American type requirements for a government or institutional job?
The DB-C is RoHS compliant, ARRA compliant, and made in the United States. It also carries no lead or mercury content and is not flagged as hazardous material, which keeps the submittal paperwork simple on public and healthcare work.
6) Is the DB-C base black to match standard black Panduit wiring duct?
Yes, the DB-C is molded in black, so it blends with black Panduit duct and divider walls rather than standing out inside the panel. It is part of the Panduct line.
