Panduit TM2A-C Cable Tie Mount, Nylon 6.6
The Panduit TM2A-C Cable Tie Mount is an adhesive-backed mount designed for fast, reliable cable bundling in indoor electrical and low-voltage installations. Molded from nylon 6.6 in a natural color, this 0.43" (10.9 mm) wide mount is applied with user-supplied adhesive to a solid flat bottom surface, providing maximum holding area for miniature, intermediate, and standard cross-section cable ties. It is cULus Recognized (62275 Type 1, 11, E136577), CE compliant, and RoHS compliant, making it suitable for professional indoor cable management applications. Sold in packages of 100.
Key Features
- Compact Profile: 0.43" (10.9 mm) wide mount with a solid flat bottom surface for maximum holding area in indoor use.
- Durable Construction: Molded from nylon 6.6, increasing mechanical strength, heat resistance, wear resistance, and stiffness.
- Adhesive-Backed Mounting: Applied with user-supplied adhesive for quick, tool-free placement on flat surfaces.
- Broad Tie Compatibility: Compatible with miniature, intermediate, and standard cross-section cable ties.
- Loop Tensile Strength: Rated for a minimum loop tensile strength of 222 N (50 lb).
- Operating Temperature Range: Rated from 32°F to 158°F (0°C to 70°C) for indoor environments.
- Flammability Rating: UL94V-2 rated material construction.
- Finish: Natural color for a clean, unobtrusive appearance.
Certifications & Compliance
- cULus Recognized, 62275 Type 1, 11 (E136577)
- CE Compliant
- RoHS Compliant
Technical Specifications
- Maximum Operating Temperature (°F): 158
- Minimum Operating Temperature (°F): 32
- Maximum Operating Temperature (°C): 70
- Minimum Operating Temperature (°C): 0
- Minimum Loop Tensile Strength (N): 222
- Minimum Loop Tensile Strength (lb): 50
- For Use With: Miniature, Intermediate, Standard Cross-Section Ties
- Std. Pkg. Qty.: 100
- Std Ctn Qty: 500
- Product Group: Wiring Devices
- Country of Origin: USA
Typical Applications
- Commercial and Industrial Cable Management
- Structured Cabling and Low-Voltage Wiring
- Panelboard and Enclosure Cable Routing
- Indoor Electrical Installations
- Renovation and New Construction Cable Bundling
Why Panduit?
Panduit engineers cable management products from durable materials like nylon 6.6 to deliver dependable mechanical strength, heat resistance, and wear resistance in demanding indoor environments. With cULus recognition, CE compliance, and RoHS compliance, the TM2A-C Cable Tie Mount offers professionals a code-compliant, reliable, adhesive-backed solution for secure, organized cable routing on flat mounting surfaces.
Manufacturer Resources
Product Specs
- Standard Package Volume Ft3:
- 0.0370
- Maximum Operating Temperature (°F):
- 158
- Std. Pkg. UOM:
- Piece
- Standard Carton Volume Ft3:
- 0.1850
- Mercury Content Indicator:
- N
- Product Color:
- Natural
- Product Segment:
- IEI
- Minimum Loop Tensile Strength (N):
- 222
- Minimum Operating Temperature (°F):
- 32
- Min Order Qty:
- 500.0000
- Material Description:
- Nylon 6.6
- Minimum Loop Tensile Strength (lb):
- 50
- For Use With:
- Miniature, Intermediate, Standard Cross-Section Ties
- UOM EA PK:
- PK
- Pallet Volume:
- 59.008598
- Any Reason Not to Sell:
- N
- REACH Status:
- N
- California Pro65 Cancer:
- No
- Country of Origin:
- USA
- Std Ctn Qty:
- 500
- Product Type:
- Cable Tie Mount
- Pallet Quantity:
- 159,500
- Flammability Rating:
- UL94V-2
- Minimum Operating Temperature (°C):
- 0
- RoHS Compliant:
- Compliant
- Min. Order UOM:
- Piece
- ARRA Compliant:
- Y
- Maximum Operating Temperature (°C):
- 70
- Std. Pkg. Qty.:
- 100
- Environment:
- Indoor
- Product Material:
- Nylon 6.6
- Hazardous Material Flag:
- N
- Prop 65 Warning:
- No
- Department:
- Electrical
- Product Group:
- Wiring Devices
- Pack Size:
- 1000
Panduit TM2A-C – Frequently Asked Questions
1) Does the Panduit TM2A-C cable tie mount come with adhesive already applied?
No. The TM2A-C is applied with user-supplied adhesive to a solid flat bottom surface, so you need to supply the adhesive or tape yourself. The flat bottom gives the full footprint as holding area, but the bond is only as good as the adhesive you choose and how clean and flat the surface is.
2) What size cable ties will fit the Panduit TM2A-C mount?
It takes miniature, intermediate, and standard cross-section ties, which covers most general-purpose bundling work. The mount itself is 0.43 inch (10.9 mm) wide. Heavy-cross-section ties are outside what it is rated for.
3) Is the Panduit TM2A-C tie mount UL recognized and RoHS compliant?
It is cULus Recognized under 62275 Type 1, 11 (file E136577), CE compliant, and RoHS compliant. Material flammability is UL94V-2. That combination is what most commercial and institutional specs ask for on indoor low-voltage and panel wiring.
4) Is the Panduit TM2A-C made in the USA for a Buy American job?
Country of origin is the USA and the part is flagged ARRA compliant, which is what federal and federally funded projects typically ask for on wiring devices. It also carries no Prop 65 warning and contains no mercury.
5) What size options are there besides the standard TM2A-C mount?
Three options are offered under the Panduit tie mount line: the standard TM2A-C, a 1 x 1 inch mount (ABM2S-AT-D0), and a larger 12 x 1 inch mount (ABM112-AT-C0). The bigger footprints give more adhesive contact area, which is what you want on textured or painted surfaces or under heavier bundles.
6) Where is an adhesive tie mount the right choice versus a screw-mounted one?
Adhesive mounts like the TM2A-C suit flat, solid, indoor surfaces where you do not want to drill: enclosure and panelboard interiors, structured cabling drops, and renovation work over finished surfaces. Placement is tool-free. If the surface is rough, dirty, or outdoors, or the bundle is heavy and overhead, go with a screw-applied mount instead.
7) What material is the TM2A-C mount made from and why does that matter?
Nylon 6.6, molded in natural color. Nylon 6.6 gives higher mechanical strength, heat resistance, wear resistance, and stiffness than lower grades, which is why it holds up in warm panel and enclosure interiors up to 158 degrees F. Natural color keeps it unobtrusive on light surfaces; it is not a UV-stabilized black, another reason it is an indoor part.
8) How are Panduit TM2A-C cable tie mounts packaged for a large job?
Standard package is 100 pieces, and the standard carton holds 500. Order quantity is tracked in pieces. For a facility standardization or a multi-floor cabling rollout, working in full cartons of 500 keeps the counts clean.
How fast can I get the Panduit TM2A-C delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the
continental
U.S.
Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit,
reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Panduit TM2A-C come with a warranty?
Absolutely. The Panduit TM2A-C is backed by a manufacturer’s warranty.
For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Panduit TM2A-C?
You can call, text, or email our expert support team for fast answers. We’re here to help with
product
selection,
installation tips, and troubleshooting. Contact Us
