Panduit PLP2S-C Locking Push Mount Cable Tie, Nylon 6.6

Panduit PLP2S-C Locking Push Mount Cable Tie, Nylon 6.6

(No reviews yet) Write a Review

Model: PLP2S-C

In Stock (leaves warehouse same day if ordered before 3pm ET)

$41.43
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit PLP2S-C Locking Push Mount Cable Tie, Nylon 6.6

The Panduit PLP2S-C Locking Push Mount Tie uses an easy-to-use, all-in-one wingless design to secure cable bundles to surfaces in confined spaces. The anchor presses directly into a pre-formed hole and locks in place, eliminating separate mounting hardware. Built from Nylon 6.6 in natural color with a standard cross section and 7.88" (200mm) overall length, each tie delivers a 50 lb (222 N) minimum loop tensile strength and ships in convenient packages of 100.

Key Features

  • Overall Length: 7.88" (200mm) standard cross-section tie for general bundling applications.
  • Durable Construction: Molded from Nylon 6.6 in natural color for reliable indoor performance.
  • Locking Push Mount Design: Wingless, all-in-one anchor presses into a pre-formed hole and locks in place, ideal for confined-space mounting without extra hardware.
  • Loop Tensile Strength: 50 lb (222 N) minimum loop tensile strength for secure bundle retention.
  • Bundle Diameter Range: Accommodates bundles from 0.06" (1.5mm) up to 1.75" (44.5mm).
  • Operating Temperature Range: Rated from -76°F to 185°F, with a minimum installation temperature of -4°F.
  • Compatible Mounts: Designed for use with GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, PTH, PPTS, STS2, and STH2 mounting bases.
  • Packaging: Supplied in packages of 100 pieces (PK100).

Certifications & Compliance

  • UL Recognized (File #E56854)
  • UL 62275 Compliant (Type 1, 11)
  • RoHS Compliant

Technical Specifications

  • Product Type: Premium Cable Tie
  • Product Size: 9"
  • Overall Length (mm): 200
  • Material Description: Nylon 6.6
  • Color: Natural
  • Minimum Loop Tensile Strength (lb): 50
  • Minimum Loop Tensile Strength (N): 222
  • Minimum Bundle Diameter (mm): 1.5
  • Maximum Bundle Diameter (mm): 44.5
  • Maximum Operating Temperature (°F): 185
  • Minimum Operating Temperature (°F): -76
  • Minimum Installation Temperature (°F): -4
  • For Use With: GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, PTH, PPTS, STS2, STH2
  • Std Ctn Qty: 1000
  • Country of Origin: Costa Rica, Malaysia

Typical Applications

  • Cable and Wire Bundling in Confined Spaces
  • Data Center and Telecommunications Wiring
  • Panelboard and Enclosure Cable Management
  • Commercial and Industrial Electrical Installations
  • Renovation and New Construction Wiring

Why Panduit?

Panduit PLP2S-C ties are built from Nylon 6.6 for durable, code-compliant cable management and are UL Recognized and UL 62275 Compliant, giving installers confidence in demanding commercial and industrial environments. The locking push mount design simplifies installation in tight spaces while the RoHS-compliant construction supports environmentally responsible builds. Trust Panduit for consistent, reliable bundle retention across your electrical and data infrastructure projects.

Manufacturer Resources

Product Specs

Standard Package Volume Ft3:
0.0474
Maximum Operating Temperature (°F):
185
Standard Package Weight Pounds:
0.4000
Std. Pkg. UOM:
Piece
Body Width (In.):
0.19
Standard Carton Volume Ft3:
0.4739
Std Package Length MM:
242.57
Lead Content Indicator:
N
Mercury Content Indicator:
N
Minimum Installation Temperature (°F):
-4
Product Segment:
IEI
Minimum Loop Tensile Strength (N):
222
Standard Carton Weight Pounds:
4.0000
Minimum Operating Temperature (°F):
-76
Min Order Qty:
1,000.0000
Maximum Bundle Diameter (mm):
44.5
Material Description:
Nylon 6.6
GTIN Package:
00074983555086
Minimum Loop Tensile Strength (lb):
50
Minimum Bundle Diameter (In.):
0.06
Std Carton Width MM:
262.89
UOM EA PK:
PK
Pallet Volume:
37.909378
Std Package Width In:
5.7
Minimum Bundle Diameter (mm):
1.5
Any Reason Not to Sell:
N
Body Thickness (mm):
1.3
REACH Status:
N
Std Carton Length In:
17.4
California Pro65 Cancer:
No
Std Carton Height In:
4.5
Std Package Length In:
9.55
Overall Length (mm):
200
Country of Origin:
Costa Rica, Malaysia
Std Carton Width In:
10.35
Std Ctn Qty:
1000
Maximum Bundle Diameter (In.):
1.75
Body Thickness (In.):
0.05
Product Type:
Premium Cable Tie
GTIN Carton:
50074983555081
Std Carton Height MM:
114.3
Std Package Width MM:
144.78
Pallet Quantity:
80,000
Std Package Height In:
2.1
Minimum Operating Temperature (°C):
-60
Std Package Height MM:
53.34
RoHS Compliant:
Compliant
Product Color:
Natural
Product Size:
9"
Department:
Electrical
Product Group:
Wiring Devices
Pack Size:
100

Panduit PLP2S-C – Frequently Asked Questions

1) What size bundle will the Panduit PLP2S-C push mount cable tie hold?
The PLP2S-C handles bundles from 0.06 in (1.5 mm) up to 1.75 in (44.5 mm), so it covers everything from a single pair of conductors to a fairly heavy bundle of data cable. Overall tie length is 200 mm, with a 0.19 in wide, 0.05 in thick standard cross section body.
2) Do I need a separate mounting base or screw for the Panduit PLP2S-C locking push mount tie?
No separate hardware is needed when you have a pre-formed hole. The anchor on the PLP2S-C is a wingless, all-in-one push mount that presses into the hole and locks, which is why it works in tight enclosure and panel spaces where you cannot get a screwdriver behind the panel. Where there is no hole to push into, Panduit lists it for use with the GTS-E, GS2B-E, GTH-E, GS4H-E, PTS, PTH, PPTS, STS2 and STH2 mounting bases.
3) Can I install Panduit PLP2S-C ties in a cold warehouse or outdoors in winter?
Installation temperature is the limit to watch. The PLP2S-C is rated to install at -4 F or warmer, even though the service range runs from -76 F (-60 C) up to 185 F. Below -4 F the nylon gets brittle enough that the tie can crack as the pawl engages. Warm the ties before use if the space is colder than that.
4) Will a push mount tie work in a panelboard or enclosure with no pre-drilled hole?
Not directly. The locking anchor on the PLP2S-C has to seat into a pre-formed hole to lock. If the sheet metal or panel is blank, either drill for the anchor or use one of the Panduit mounting bases it is listed with, such as the PTS, PTH or STS2, which adhere or screw to the surface and accept the tie.
5) Is natural nylon 6.6 cable tie OK for outdoor or UV exposed runs?
Natural is the indoor color. The PLP2S-C is molded from Nylon 6.6 in natural, which has no carbon black for UV protection, so keep it inside enclosures, panelboards, ceilings and data rooms. For sunlight exposure specify a weather resistant black nylon tie instead.
6) What certifications does the Panduit PLP2S-C cable tie carry?
It is UL Recognized under file E56854 and compliant to UL 62275 Types 1 and 11, plus RoHS compliant. Those are the listings a spec inspector or facility engineer looks for on cable management in commercial and industrial installs.
7) How are Panduit PLP2S-C ties packaged and what is the minimum I can order?
They come in bags of 100 pieces, with 1,000 to a standard carton and a 1,000 piece minimum order. A full carton weighs about 4 lb. Worth knowing before you spec them into a small job, since one bag is not an orderable quantity on its own.
