Panduit Dry-Shrink™ HSTT Series Heat Shrink Tubing, Flame-Retardant Polyolefin

Panduit Dry-Shrink™ HSTT Series Heat Shrink Tubing, Flame-Retardant Polyolefin

(No reviews yet) Write a Review

Model: HSTT25-C5

In Stock (leaves warehouse same day if ordered before 3pm ET)

$135.46
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Panduit Dry-Shrink™ HSTT Series Heat Shrink Tubing, Flame-Retardant Polyolefin

The Panduit Dry-Shrink™ HSTT Series is a thin-wall heat shrink tubing built from green, cross-linked polyolefin, sized at .38" (9.5mm) diameter and supplied 100 ft. (30.5m) per reel. Engineered with a 2:1 shrink ratio and flame-retardant resistance properties, this HSTT Series tubing is designed for dry-location electrical installations where reliable insulation and mechanical protection are required. It carries UL Recognized, CSA Approved, and MIL SPEC listings for use in professional electrical and industrial wiring applications.

Key Features

  • Trade Size: .38" (9.5mm) diameter thin-wall tubing for standard wire and cable bundling.
  • Durable Construction: Green, cross-linked polyolefin material with flame-retardant resistance properties.
  • Shrink Ratio: 2:1 shrink ratio activated at a shrink temperature of 194°F (90°C) for fast, reliable application.
  • Operating Temperature Range: Rated from -67°F (-55°C) minimum to 275°F (135°C) maximum for wide environmental durability.
  • Wall Thickness: 0.025 in. (0.6mm) nominal recovered wall thickness for a low-profile finish.
  • Application: Intended for dry-location use in commercial and industrial electrical systems.
  • Packaging: Supplied on a 100 ft. (30.5m) reel for continuous-length installations.

Certifications & Compliance

  • UL Recognized
  • CSA Approved
  • MIL SPEC

Technical Specifications

  • Mercury Content Indicator: N
  • Lead Content Indicator: N
  • Minimum Operating Temperature (°F): -67
  • UOM EA PK: EA
  • California Pro65 Cancer: No
  • Country of Origin: CHN
  • Std Ctn Qty: 10
  • Pallet Quantity: 80
  • Minimum Operating Temperature (°C): -55
  • Std. Pkg. Qty.: 1
  • Hazardous Material Flag: N
  • Restricted Use of Hazardous Substances: N
  • Maximum Operating Temperature (°F): 275
  • Product Segment: IEI
  • Shrink Temperature (°C): 90
  • Any Reason Not to Sell: N
  • REACH Status: N
  • Shrink Ratio: 2:1
  • Shrink Temperature (°F): 194
  • Nominal Recovered Wall Thickness (mm): 0.6
  • RoHS Compliant: Compliant
  • ARRA Compliant: N
  • Maximum Operating Temperature (°C): 135
  • Overall Length (In.): 1200
  • Overall Length (ft.): 100
  • Adhesive Lined: No

Typical Applications

  • Wire and Cable Bundling Protection
  • Electrical Splice and Termination Insulation
  • Industrial and Commercial Wiring Systems
  • Dry-Location Electrical Installations
  • Panel and Enclosure Wiring Protection

Why Panduit?

Panduit's Dry-Shrink™ HSTT Series delivers flame-retardant, cross-linked polyolefin construction backed by UL Recognized, CSA Approved, and MIL SPEC listings, giving electrical professionals confidence in code-compliant performance. Consistent 2:1 shrink performance and a wide -67°F to 275°F operating range make this tubing a dependable choice for demanding dry-location wiring projects.

Manufacturer Resources

Product Specs

Standard Package Volume Ft3:
0.4230
Overall Length (m):
30.48
Nominal Recovered Wall Thickness (In.):
0.025
Standard Carton Volume Ft3:
4.2297
Mercury Content Indicator:
N
Lead Content Indicator:
N
Minimum Operating Temperature (°F):
-67
Std Carton Width MM:
365.76
UOM EA PK:
EA
Pallet Volume:
33.837857
California Pro65 Cancer:
No
Std Package Length In:
13.5
Country of Origin:
CHN
Std Ctn Qty:
10
Product Type:
Heat Shrink Tubing
Pallet Quantity:
80
Minimum Operating Temperature (°C):
-55
Std. Pkg. Qty.:
1
Std Carton Length MM:
708.66
Hazardous Material Flag:
N
Restricted Use of Hazardous Substances:
N
Maximum Operating Temperature (°F):
275
Std. Pkg. UOM:
Roll
Std Package Length MM:
342.9
Sub Brand:
Dry-Shrink™
Product Segment:
IEI
Resistance Properties:
Flame-Retardant
Min Order Qty:
1.0000
Shrink Temperature (°C):
90
Any Reason Not to Sell:
N
REACH Status:
N
Std Carton Length In:
27.9
Std Carton Height In:
18.2
Application:
For Dry Locations
Overall Length (mm):
30480
Std Carton Width In:
14.4
Shrink Ratio:
2:1
Shrink Temperature (°F):
194
Std Carton Height MM:
462.28
Nominal Recovered Wall Thickness (mm):
0.6
RoHS Compliant:
Compliant
Min. Order UOM:
Roll
ARRA Compliant:
N
Maximum Operating Temperature (°C):
135
Overall Length (In.):
1200
Overall Length (ft.):
100
Adhesive Lined:
No
Product Material:
Cross-Linked Polyolefin
Product Color:
Green
Department:
Electrical
Product Group:
Wiring Devices
