Panduit Dry-Shrink™ HSTT100-48-5 Heat Shrink Tubing, Black, Cross-Linked Polyolefin

The Panduit Dry-Shrink™ HSTT100-48-5 is a thin-wall heat shrink tubing that shrinks around wires, connectors, joints, and terminals when heated, protecting them against abrasion in indoor, dry locations. Measuring 1.00” D x 4’ L (25.4 mm x 1.2 m) and shrinking to 0.5” ID at a 2:1 shrink ratio, this black, flame-retardant, cross-linked polyolefin tubing is rated for a -67°F to 275°F (-55°C to 135°C) operating range and is UL Listed. Each package contains 5 pieces (PK5), ready for insulating and protecting wires and cables in professional electrical installations.

Key Features

  • Dimensions: 1.00” D x 4’ L (25.4 mm x 1.2 m), shrinking down to 0.5” ID for a snug, protective fit.
  • Durable Construction: Flame-retardant, cross-linked polyolefin material resists abrasion and everyday wear.
  • 2:1 Shrink Ratio: Shrinks at 90°C (194°F) to conform tightly around wires, connectors, joints, and terminals.
  • Wide Operating Range: Performs from -67°F to 275°F (-55°C to 135°C) for demanding indoor environments.
  • Color: Black for standard wire and cable insulation applications.
  • Packaging: Sold in convenient 5-piece packages (PK5) for stocking and job-ready use.

Certifications & Compliance

  • UL Listed: E122770
  • Mil Spec: AMS-DTL-23053/5 Class 1
  • RoHS Compliant

Technical Specifications

  • Maximum Operating Temperature (°F): 275
  • Lead Content Indicator: N
  • Mercury Content Indicator: N
  • Product Segment: IEI
  • Minimum Operating Temperature (°F): -67
  • Shrink Temperature (°C): 90
  • UOM EA PK: PK
  • Any Reason Not to Sell: N
  • REACH Status: N
  • California Pro65 Cancer: No
  • Country of Origin: CHN
  • Shrink Temperature (°F): 194
  • Shrink Ratio: 2:1
  • Std Ctn Qty: 0
  • Minimum Operating Temperature (°C): -55
  • ARRA Compliant: N
  • Maximum Operating Temperature (°C): 135
  • Std. Pkg. Qty.: 5
  • Overall Length (In.): 48
  • Overall Length (ft.): 4
  • Adhesive Lined: No
  • Hazardous Material Flag: N
  • Restricted Use of Hazardous Substances: N
  • Prop 65 Warning: No

Typical Applications

  • Insulating and Protecting Wires and Cables in Dry Locations
  • Terminal, Connector, and Joint Protection
  • Wire and Cable Bundle Abrasion Protection
  • Commercial and Industrial Electrical Panels
  • Panel Building and Control Cabinet Wiring

Why Panduit?

Panduit's Dry-Shrink™ heat shrink tubing delivers flame-retardant, cross-linked polyolefin construction with a proven 2:1 shrink ratio and a wide -67°F to 275°F operating range, backed by UL Listing and Mil Spec compliance. It's built for reliable, code-compliant wire and cable protection in professional electrical and industrial installations.

Manufacturer Resources

Product Specs

Maximum Operating Temperature (°F):
275
Std. Pkg. UOM:
Piece
Overall Length (m):
1.22
Standard Carton Volume Ft3:
0.0000
Lead Content Indicator:
N
Mercury Content Indicator:
N
Sub Brand:
Dry-Shrink™
Product Segment:
IEI
Resistance Properties:
Flame-Retardant
Standard Carton Weight Pounds:
0.0000
Minimum Operating Temperature (°F):
-67
Min Order Qty:
5.0000
Shrink Temperature (°C):
90
UOM EA PK:
PK
Pallet Volume:
0.000000
Any Reason Not to Sell:
N
REACH Status:
N
California Pro65 Cancer:
No
Overall Length (mm):
1219.2
Shrink Temperature (°F):
194
Shrink Ratio:
2:1
Std Ctn Qty:
0
Product Type:
Heat Shrink Tubing
Minimum Operating Temperature (°C):
-55
RoHS Compliant:
Compliant
Min. Order UOM:
Piece
Arra Compliant:
N
Maximum Operating Temperature (°C):
135
Std. Pkg. Qty.:
5
Overall Length (In.):
48
Overall Length (ft.):
4
Product Material:
Cross-Linked Polyolefin
Adhesive Lined:
No
Hazardous Material Flag:
N
Restricted Use of Hazardous Substances:
N
Prop 65 Warning:
No
Department:
Electrical
Product Group:
Cable Management & Identification
Product Subgroup:
Electrical Sleeves

Panduit PAN-HSTT-09CC – Frequently Asked Questions

1) What temperature do I need to hit to shrink Panduit Dry-Shrink tubing, and will a standard heat gun do it?
Recovery starts at 90 C (194 F), which any standard electrical heat gun reaches easily. Keep the gun moving along the length so the polyolefin recovers evenly instead of scorching in one spot. Once installed, the tubing holds from -67 F to 275 F (-55 C to 135 C), so it will sit in a hot control cabinet or an unheated outbuilding without going brittle.
2) Can I use this heat shrink on a direct burial or wet location splice?
No. Dry-Shrink tubing is a thin-wall, non-adhesive-lined product intended for indoor, dry locations. There is no internal sealant, so water can wick along the conductor under the tubing. For a buried or submerged splice you need an adhesive-lined (dual-wall) tubing or a potted splice kit instead.
3) Is Panduit Dry-Shrink tubing flame retardant and UL listed for panel wiring?
The cross-linked polyolefin is flame retardant and carries UL Listing E122770, plus Mil Spec AMS-DTL-23053/5 Class 1. That is the combination panel shops and inspectors look for on control cabinet and industrial panel wiring.
4) Does this Panduit heat shrink meet RoHS and Prop 65 requirements for a government or institutional job?
RoHS compliant, with no lead or mercury content flagged and no Prop 65 cancer warning. Country of origin is China, and it is not ARRA compliant, which matters if your project carries a Buy American clause.
5) Will 4 foot sticks work for a production panel shop, or should I be looking at spooled tubing?
The 48 inch stick format suits panel building and field terminations where you cut short pieces per connector, and it stores flat in a van bin without a reel. For high-volume repetitive cutting on a bench, continuous spooled tubing feeds faster. For MRO stocking and mixed job work, the 5-piece pack of 4 foot sticks is the practical format.
