Panduit Mini-Com Flush Mount 24-Port Patch Panel, Black
The Panduit Mini-Com Flush Mount 24-Port Patch Panel is a 1 RU modular patch panel that accepts up to 24 Mini-Com Modules for unshielded (UTP) applications. Built from CRS (cold-rolled steel) and finished in black, the panel mounts flush with the rack and fits both 19 inch and 23 inch racks and cabinets. It is part of Panduit's Pan-Net platform and is RoHS Compliant, giving network installers a durable, code-conscious termination point for structured cabling.
Key Features
- Port Capacity: Accepts up to 24 Mini-Com Modules in a single 1 RU footprint for high-density terminations.
- Durable Construction: CRS (cold-rolled steel) body provides a rigid, long-lasting mounting platform.
- Flush Mount Style: Flat, flush-mounted design sits cleanly against the rack for a low-profile installation.
- Rack Compatibility: Mounts to both 19 inch and 23 inch racks and cabinets for flexible deployment.
- Unshielded Applications: Shield Type is Unshielded (UTP), suited to standard copper network cabling.
- Labeling Ready: Panel can be identified with adhesive labels for quick port mapping and moves/adds/changes.
- Finish: Black finish for a clean, professional appearance in the rack.
Certifications & Compliance
- RoHS Compliant
Technical Specifications
- Number of Rack Units: 1
- Number of Ports: 24
- REACH Status: N
- California Pro65 Cancer: No
- Std Carton Height In: 7.1
- Mercury Content Indicator: N
- Std Ctn Qty: 10
- Pallet Quantity: 240
- Std Package Height In: 2.9
- ARRA Compliant: Y
- Std. Pkg. Qty.: 1
- Std Carton Length MM: 534.67
- Overall Depth (In.): 1.04
- Std Carton Width MM: 480.06
- UOM EA PK: EA
- Pallet Volume: 38.853354
- Std Package Width In: 3.65
- Hazardous Material Flag: N
- Any Reason Not to Sell: N
- Product Material: CRS
Typical Applications
- Structured Cabling and Network Termination
- Data Center and Server Room Cabling
- 19 Inch and 23 Inch Rack and Cabinet Installations
- Commercial and Enterprise Network Closets
- Telecommunications Rooms and MDF/IDF Spaces
Why Panduit?
Panduit's Mini-Com Pan-Net patch panel combines a rugged CRS steel body with a flush-mount design built for demanding network environments. Backed by RoHS compliance and support for both 19 inch and 23 inch rack formats, it delivers a dependable, professional-grade termination point for structured cabling projects of any size.
Manufacturer Resources
Spec Sheet
Product Specs
- Number of Rack Units:
- 1
- Standard Package Volume Ft3:
- 0.1619
- Number of Ports:
- 24
- Standard Package Weight Pounds:
- 1.4650
- REACH Status:
- N
- Std. Pkg. UOM:
- Piece
- Overall Width (mm):
- 482.6
- Std Carton Length In:
- 21.05
- California Pro65 Cancer:
- No
- Std Carton Height In:
- 7.1
- Std Package Length In:
- 20.45
- Country of Origin:
- Mexico, China
- Standard Carton Volume Ft3:
- 1.6189
- Patch Panel Style:
- Flat
- Mercury Content Indicator:
- N
- Std Package Length MM:
- 519.43
- Std Carton Width In:
- 18.9
- Sub Brand:
- Pan-Net®
- Std Ctn Qty:
- 10
- Shield Type:
- Unshielded (UTP)
- Product Segment:
- EDI-ENT
- Product Type:
- Flush Mounted Patch Panel
- GTIN Carton:
- 50074983036542
- Std Carton Height MM:
- 180.34
- Std Package Width MM:
- 92.71
- Pallet Quantity:
- 240
- Std Package Height In:
- 2.9
- Standard Carton Weight Pounds:
- 14.6500
- Overall Height (In.):
- 1.72
- Std Package Height MM:
- 73.66
- Min Order Qty:
- 10.0000
- RoHS Compliant:
- Compliant
- GTIN Package:
- 00074983036547
- Min. Order UOM:
- Piece
- ARRA Compliant:
- Y
- Module Type:
- Mini-Com®
- Std. Pkg. Qty.:
- 1
- Overall Depth (mm):
- 26.4
- Std Carton Length MM:
- 534.67
- Overall Depth (In.):
- 1.04
- Std Carton Width MM:
- 480.06
- UOM EA PK:
- EA
- Pallet Volume:
- 38.853354
- Std Package Width In:
- 3.65
- Identification Type:
- Adhesive Label
- Hazardous Material Flag:
- N
- Any Reason Not to Sell:
- N
- Product Material:
- CRS
- Product Color:
- Black
- Department:
- Electrical
- Product Group:
- Wiring Devices
- Product Subgroup:
- Parts & Accessories
Panduit CPP24FMWBLY – Frequently Asked Questions
1) Do the jacks come with the Panduit CPP24FMWBLY 24-port patch panel, or do I order them separately?
The CPP24FMWBLY ships as a bare frame. It accepts up to 24 Panduit Mini-Com modules, and those modules are ordered separately, so you pick the category and color of jack you need per port. Budget the full 24 modules if you are loading the panel out, or partially populate and fill in later since the openings are modular.
2) Will this Panduit flush mount patch panel fit a 23 inch rack, or only a standard 19 inch?
Both. The Mini-Com flush mount panel is built to mount in 19 inch and 23 inch racks and cabinets. The panel body itself is 482.6 mm wide, which is the standard 19 inch EIA rack face, and it takes 23 inch mounting when required.
3) Can I use this Panduit panel for shielded Cat6A cabling?
No. This panel is specified as unshielded, UTP. There is no bonding path for shielded module drains, so if your run is F/UTP or S/FTP you need a shielded Panduit panel and shielded Mini-Com jacks instead. For standard UTP copper runs it is the right part.
4) How much rack space does the Panduit CPP24FMWBLY take up?
One rack unit. Twenty-four ports in 1 RU, with an overall height of 1.72 inches. If you are stacking panels and horizontal cable managers in a wall-mount cabinet, count 1 RU per panel plus whatever manager you put between them.
5) How deep does the Panduit CPP24FMWBLY sit behind the rack rails?
The panel is only 1.04 inches deep overall, about 26.4 mm. It is a flat, flush-mount style, so the frame sits tight against the rails and the depth behind the rack comes almost entirely from the loaded modules and the cable bend radius, not the panel itself. That matters in shallow wall-mount cabinets and in two-post installs where you have equipment directly behind.
6) Is the Panduit Mini-Com flush mount panel angled or flat?
Flat, flush mounted. Ports face straight out of the rack face. A flat panel is the usual choice when you are running horizontal cable managers between panels or working in an enclosed cabinet. An angled panel is what you reach for instead when you want patch cords to fall naturally toward vertical managers and skip the horizontal managers entirely.
7) Does the Panduit 24-port Mini-Com panel meet Buy American / ARRA requirements for a federal job?
The CPP24FMWBLY is flagged ARRA compliant, and it is RoHS compliant. Country of origin is Mexico and China. For federal and institutional specs, take those three facts together: ARRA compliance is stated, but confirm your contract's specific domestic-content clause against the stated origin.
8) Can I mix Cat5e and Cat6 jacks in the same Panduit CPP24FMWBLY panel?
Yes. The panel is module-agnostic within the Mini-Com line, so any mix of Mini-Com UTP modules drops into the 24 openings. That is the point of a modular panel over a fixed-jack one: you standardize on the frame across the building and change only the module when a drop gets upgraded.
9) How do I label the ports on this Panduit patch panel?
Identification is by adhesive label. The panel is set up to take label strips for port mapping, which is what you want for documenting moves, adds and changes in an IDF. There is no engraved or window-insert designation on this one.
10) Is the Panduit CPP24FMWBLY metal or plastic, and what color?
Cold-rolled steel, finished in black. CRS gives a rigid face that will not flex when you are seating 24 modules or pulling patch cords, which is the practical difference against a plastic-bodied panel.
