Panduit Pan-Lug SCS6-L Compression Splice, Tin-Plated Copper

The Panduit Pan-Lug SCS6-L Compression Splice is a standard-barrel copper splice designed for 6 AWG copper conductors. Constructed from tin-plated copper to help inhibit corrosion, this non-insulated splice is UL Listed and CSA Certified to 35 kV and temperature rated to 90°C, making it a reliable choice for professional electrical splicing applications.

Key Features

  • Conductor Size: Sized for 6 AWG copper conductors.
  • Durable Construction: Tin-plated copper barrel helps inhibit corrosion for long-term reliability.
  • Color-Coded Barrel: Blue color-coded barrel marked with Panduit and competitor die index numbers (Panduit P24, T&B 24, Burndy 7) for proper crimp die selection.
  • Inspection Window: Aids visual confirmation of full conductor insertion for a proper crimp.
  • Insulation: Non-Insulated standard barrel design.
  • Voltage & Temperature Rating: UL Listed and CSA Certified to 35 kV with a 90°C temperature rating.
  • Wire Strip Length: Requires a 13/16" (20.6mm) strip length for proper installation.

Certifications & Compliance

  • UL Listed
  • CSA Certified to 35 kV
  • RoHS Compliant

Technical Specifications

  • REACH Status: N
  • CSA Temperature Rating (°C): 90
  • California Pro65 Cancer: No
  • Std Package Length In: 4.7
  • Maximum Voltage (kV): 35
  • UL Temperature Rating (°C): 90
  • Lead Content Indicator: N
  • Mercury Content Indicator: N
  • Std Ctn Qty: 0
  • Product Segment: IEI
  • Pallet Quantity: 0
  • ARRA Compliant: Y
  • Std. Pkg. Qty.: 50
  • T & B Die Index Number: 24
  • UOM EA PK: PK
  • Burndy Die Index Number: 7
  • Hazardous Material Flag: N
  • Any Reason Not to Sell: N
  • Insulation Material: Non-Insulated
  • Wire Strip Length (mm): 20.6
  • Restricted Use of Hazardous Substances: N
  • Copper Conductor Size: 6 AWG
  • Panduit Die Index Number: P24

Typical Applications

  • Industrial and Commercial Electrical Splicing
  • Copper Conductor Termination and Repair
  • Panelboard and Switchgear Wiring
  • Medium-Voltage Electrical Connections up to 35 kV

Why Panduit?

Panduit's Pan-Lug SCS6-L compression splice combines tin-plated copper construction, color-coded die index marking, and an inspection window to help installers achieve a proper, code-compliant crimp. Backed by UL Listing and CSA Certification to 35 kV and a 90°C temperature rating, this splice delivers dependable performance for demanding copper conductor splicing applications.

Manufacturer Resources

Product Specs

Standard Package Volume Ft3:
0.0328
Standard Package Weight Pounds:
1.2250
REACH Status:
N
Std. Pkg. UOM:
Piece
Base Material:
Copper
CSA Temperature Rating (°C):
90
California Pro65 Cancer:
No
Std Package Length In:
4.7
Maximum Voltage (kV):
35
Finish/Coating:
Tin-Plated
Overall Length (mm):
44.4
UL Temperature Rating (°C):
90
Country of Origin:
Mexico
Standard Carton Volume Ft3:
0.0000
Color Code:
Blue
Lead Content Indicator:
N
Mercury Content Indicator:
N
Std Package Length MM:
119.38
Sub Brand:
Pan-Lug™
Std Ctn Qty:
0
Wire Strip Length (In.):
13/16
Product Segment:
IEI
Product Type:
Compression Splice
Std Package Width MM:
85.09
Pallet Quantity:
0
Std Package Height In:
3.35
Standard Carton Weight Pounds:
0.0000
Std Package Height MM:
85.09
Min Order Qty:
1.0000
RoHS Compliant:
Compliant
GTIN Package:
00074983903054
Min. Order UOM:
Piece
ARRA Compliant:
Y
Std. Pkg. Qty.:
50
T & B Die Index Number:
24
Overall Length (In.):
1.75
UOM EA PK:
PK
Burndy Die Index Number:
7
Pallet Volume:
0.000000
Std Package Width In:
3.35
Hazardous Material Flag:
N
Any Reason Not to Sell:
N
Insulation Material:
Non-Insulated
Wire Strip Length (mm):
20.6
Restricted Use of Hazardous Substances:
N
Pallet Weight:
0.0000
Barrel Type:
Standard
Copper Conductor Size:
6 AWG
Panduit Die Index Number:
P24
Department:
Electrical
Product Group:
Wiring Devices
