Pass & Seymour 885 Series Decorator Tamper-Resistant Receptacle, 15A 125V

Pass & Seymour 885 Series Decorator Tamper-Resistant Receptacle, 15A 125V

The Pass & Seymour 885 Series Decorator Tamper-Resistant Receptacle delivers a 15A, 125V duplex outlet built to NEMA 5-15R configuration for standard residential and commercial branch circuits. Engineered with a low-profile decorator face and high-impact thermoplastic construction, this receptacle meets 2008 National Electrical Code tamper-resistant requirements with a patented shutter system that helps prevent improper insertion of foreign objects. It is cULus listed to UL498 and CSA C22.2 No.42 for use on 15A, 125V circuits.

Key Features

• Electrical Rating: Rated 15A at 125V AC for standard NEMA 5-15R duplex receptacle applications.
• Tamper-Resistant Shutters: Patented shutter system meets 2008 NEC tamper-resistant requirements and helps prevent improper insertion of foreign objects, offering superior protection over traditional outlet caps or protection plates.
• Durable Construction: High-impact resistant thermoplastic construction with ultrasonic welding of face to back body for long-term durability.
• Wiring Options: Side wire accepts #12–#14 AWG solid wire; push wire accepts #14 AWG solid only, with a Quickloop wire looping aid and side-access push wire release for faster terminations.
• Self-Grounding Design: Self-grounding models provide an automatic ground clip for simplified, code-compliant grounding.
• Extra-Long Strap: Extra-long strap and extra-large circuit break-off tabs plus longer tri-drive screws ease 12 AWG looping.
• Low-Profile Decorator Face: Low-profile face design with long-term blade retention for a clean, modern look.

Certifications & Compliance

• UL Listed (UL498)
• cULus Listed
• CSA Certified (C22.2 No.42)
• Meets 2008 National Electrical Code Tamper-Resistant Requirements

Technical Specifications

• CSA Standard: Yes
• UL Standard: Yes
• Amps: 15A
• Volts A C: 125
• cULus: Yes
• Depth (U S): 1"
• Federal Spec: No

Typical Applications

• Residential and Commercial Electrical Installations
• Kitchens, Bathrooms, and Living Areas
• Code-Compliant, Child-Safe Outlet Installations
• New Construction and Renovation Wiring
• Decorator-Style Switch and Outlet Combinations

Why Pass & Seymour?

Pass & Seymour builds the 885 Series with high-impact thermoplastic construction, ultrasonic-welded face-to-body assembly, and a patented tamper-resistant shutter system for long-term blade retention and reliable performance. Backed by UL498 and CSA C22.2 No.42 listings and cULus certification, this decorator receptacle delivers the code-compliant, child-safe protection professional electricians expect on every 15A, 125V installation.
