Pass & Seymour S122W Deep Old Work Switch and Outlet Box with Quick/Click, Thermoplastic

The Pass & Seymour S122W Deep Old Work Switch and Outlet Box is a Gray thermoplastic retrofit box engineered for fast, secure device mounting in existing walls. It features the Quick/Click device-mounting system, an adjustable swing bracket, and integrated Auto/Clamps, and it carries UL Listed and cULus Listed certification for professional electrical installations. Built for old-work applications, this box gives electricians a durable, code-compliant solution for adding or replacing switches and outlets without disturbing surrounding wall structure.

Key Features

  • Auto/Clamps: Clamps on each end eliminate the need for separate cable clamps, simplifying installation and reducing part count.
  • Adjustable Swing Bracket: Swing bracket adjusts from 1 1/4 inch to 1/8 inch to accommodate varying wall thicknesses in old-work retrofit installations.
  • Quick/Click Device Mounting: The Quick/Click feature secures devices quickly and easily, speeding up switch and outlet installation.
  • Over-Torque Protection: Does not strip when over-torqued, protecting the box during installation and reducing callbacks.
  • Durable Construction: Molded from Gray thermoplastic for reliable, long-lasting performance in switch and outlet box applications.

Certifications & Compliance

  • UL Listed
  • cULus Listed
  • RoHS Compliant

Technical Specifications

  • Country Of Origin: United States
  • Product Color: Gray
  • Product Line: Pass & Seymour
  • Product Material: Thermoplastic

Typical Applications

  • Old-Work (Retrofit) Switch and Outlet Box Installations
  • Residential and Commercial Remodel Wiring
  • Replacing Existing Switch or Outlet Boxes Without Wall Damage
  • Adding New Devices to Finished Walls
  • Renovation and Repair Electrical Projects

Why Pass & Seymour?

Pass & Seymour builds the S122W from durable Gray thermoplastic with an Auto/Clamp design and Quick/Click mounting system that speeds installation while resisting over-torque damage. Backed by UL Listed, cULus Listed, and RoHS Compliant certification, this old work box delivers dependable, code-compliant performance for electricians handling retrofit switch and outlet installations.

Manufacturer Resources

Spec Sheet

Product Specs

Product Material:
Thermoplastic
Product Color:
Gray
Product Type:
Switch Box
Country of Origin:
United States
Listing:
cULus
Department:
Electrical
Product Group:
Boxes & Enclosures
Product Subgroup:
Electrical Boxes
Product Depth:
3.5 in
Product Length:
3.75 in
Product Width:
2.313 in

Pass & Seymour S122-W – Frequently Asked Questions

1) Will the Pass & Seymour S122W work in an existing finished wall, or is it a new-construction box?
The S122W is an old-work box, meant to go into a wall that is already closed up. It mounts with an adjustable swing bracket that grips the back of the wall, so you cut the opening, feed the cable, and tighten the bracket without opening up drywall or plaster to reach a stud. For new construction where you can nail to framing, you want a new-work box instead.
2) What wall thickness does the swing bracket on the S122W adjust to?
The swing bracket adjusts from 1 1/4 inch down to 1/8 inch, which covers the usual range of finished wall materials you run into on retrofit work, from thin paneling up to thick plaster or double-layer drywall.
3) Do I need to add cable clamps to the S122W old work box?
No separate clamps needed. The box has integrated Auto/Clamps on each end, so the cable is secured by the box itself. That is one less part to carry and one less thing to leave out on an inspection.
4) Is the Pass & Seymour S122W UL listed for commercial work?
It carries both UL Listed and cULus Listed certification, and it is RoHS compliant. The cULus listing means it is accepted for Canadian installations as well as US.
5) What is the Quick/Click feature on the S122W and does it change how I mount a device?
Quick/Click is the device-mounting system built into the box: the switch or receptacle seats and secures quickly rather than needing the screws run all the way down blind. The mounting points also resist stripping if you over-torque them, which is the usual failure on plastic boxes when a device gets snugged hard against an uneven wall.
6) Is the S122W metal or plastic, and does that matter for grounding?
It is molded thermoplastic in gray, not metal. A nonmetallic box is not part of the ground path, so your equipment ground has to be carried on the wire and landed on the device. If your job spec calls for a metallic box, this is not the one.
7) Can I use the S122W for both switches and receptacles, or just one?
Both. It is a single-gang switch/outlet box, so it takes a switch or a receptacle equally, which is why it works well for property managers standardizing on one box for device replacements across finished walls.
8) What is the exact part number and origin for the Pass & Seymour deep old work box in gray?
Order it as Pass & Seymour S122-W, sold as the S122W model. It is made in the United States.
