Pass & Seymour TP262 TradeMaster 2-Gang Nylon Wallplate, 2 Decorator Openings, Brown

Pass & Seymour TP262 TradeMaster 2-Gang Nylon Wallplate, 2 Decorator Openings, Brown

(No reviews yet) Write a Review

Model: TP262

In Stock (leaves warehouse same day if ordered before 3pm ET)

$51.70
$1.33
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pass & Seymour TP262 TradeMaster 2-Gang Nylon Wallplate, 2 Decorator Openings, Brown

The Pass & Seymour TP262 is a TradeMaster 2-Gang nylon wall plate with 2 decorator openings, finished in Brown for a clean, uniform look on any wall. Molded of rugged, practically indestructible self-extinguishing nylon, the TP262 is built to a nominal thickness of .070 inch and is cULus Listed for code-compliant installation. Its 'TP' series sizing adds an extra 3/16 inch of width and height over standard-size plates, making it a preferred choice for hospital, industrial, institutional, and other high-abuse applications.

Key Features

  • 2-Gang Configuration: Two decorator-style openings accommodate dual decorator devices in a single plate.
  • Durable Nylon Construction: Molded of rugged, practically indestructible self-extinguishing nylon for long-term durability.
  • Oversized 'TP' Series Fit: Extra 3/16 inch width and height compared to Standard size plates for improved wall coverage.
  • Nominal Thickness: .070 inch nominal thickness for a low-profile, secure fit.
  • High-Abuse Rated: Preferred for hospital, industrial, institutional, and other high-abuse environments.
  • Finish: Matte Brown finish for a clean, professional appearance.
  • Color Family Options: Also available in Ivory, White, Gray, Black, Blue, Orange, Red, and Light Almond.

Certifications & Compliance

  • cULus Listed

Technical Specifications

  • Country Of Origin: United States
  • Product Finish: Matte
  • Product Height: 4.6875 in
  • Product Line: Pass & Seymour
  • Product Width: 4.75 in
  • Product Depth: 0.25 in

Typical Applications

  • Hospital and Healthcare Facility Wiring Devices
  • Industrial and Institutional Electrical Installations
  • High-Abuse Commercial Environments
  • Dual Decorator Device Coverage
  • Commercial and Residential Renovation Projects

Why Pass & Seymour?

Pass & Seymour's TradeMaster TP262 wall plate is molded of rugged, self-extinguishing nylon designed to withstand the demands of hospital, industrial, and institutional environments. Backed by cULus Listing, it delivers dependable, code-compliant performance for professional electrical installations where standard plates fall short.

Manufacturer Resources

Spec Sheet

Product Specs

Product Type:
Decorator Wallplate
Product Material:
Nylon
Product Color:
Brown
Product Finish:
Matte
Configuration:
2-Gang Decorator
Listing:
cULus
Country Of Origin:
United States
Department:
Electrical
Product Group:
Wiring Devices
Product Subgroup:
Wallplates
Product Height:
4.688 in
Product Width:
4.75 in
Product Depth:
0.25 in

Pass & Seymour TP262 – Frequently Asked Questions

1) Will the Pass & Seymour TP262 cover a rough or oversized drywall cutout around a 2-gang box?
That is what the TP262 is built for. It is a 'TP' series oversized plate, adding an extra 3/16 inch of width and height over a standard-size plate, and it measures 4.75 inches wide by 4.688 inches high. That extra margin hides ragged drywall cuts and patch edges around a 2-gang box that a standard plate leaves exposed.
2) Does the TP262 fit toggle switches or only decorator/rocker devices?
Decorator only. The TP262 has two decorator-style (rectangular rocker) openings, so it suits decorator switches, GFCIs, and decorator receptacles. Standard toggle switches and duplex receptacles will not fill these openings; you need a plate punched for those device styles instead.
3) I only have a single decorator device in that box - is the Pass & Seymour TP262 still the right plate?
No. The TP262 is a 2-gang plate with two decorator openings, 4.75 in wide by 4.688 in high, so it will not cover a single-gang box correctly. For one opening, a 1-gang decorator plate such as the Bryant NP26W, from Bryant's HWS series, covers a single device instead. Match the plate gang count to the box gang count before you order.
4) The box turned out to be three gang - what do I use in place of the TP262?
Step up to a three-gang decorator plate. The Eaton 7729V-SP is a decorator triple-gang wallplate cover, which covers three decorator devices where the TP262's two decorator openings would leave the third device exposed. Nothing about the TP262 can be adapted to a 3-gang box.
5) Is a nylon wallplate strong enough for a hospital corridor or industrial plant?
Nylon is the usual choice there. The TP262 is molded of rugged, self-extinguishing nylon, which resists cracking from impact far better than thermoset or thin steel plates, and Pass & Seymour calls the oversized TP series a preferred choice for hospital, industrial, institutional and other high-abuse applications. It is also cULus Listed.
6) I need the same oversized plate for a single device or a three-gang box, not two. What are my options?
The TP262 is 2-gang only. For a single opening, Bryant's NP26W in the HWS series is a 1-gang wallplate; for three decorator openings, the Eaton 7729V-SP is a decorator triple-gang cover. Those are different brands, so the color and finish will not match a brown TradeMaster plate exactly if the openings sit side by side in the same room.
7) Does the brown TP262 match a Bryant NP26W already on the adjacent wall?
No. The TP262 is brown with a matte finish, while the Bryant NP26W is a white plate. For a uniform look across a run of openings, keep one color family throughout; the TradeMaster 2-gang plate is also offered in ivory, white, gray, black, blue, orange, red and light almond if you need to match existing white devices.
8) For a hospital corridor, is a standard decorator plate like the Eaton 7729V-SP equivalent to the TP262?
They are not interchangeable in gang count or size. The TP262 is a 2-gang nylon decorator plate in the oversized TP series, adding an extra 3/16 inch of width and height over standard-size plates, which is why it is specified for hospital, industrial and institutional high-abuse work where screw holes and cut drywall edges need extra coverage. The Eaton 7729V-SP is a triple-gang decorator cover. If you need two devices covered with the oversized footprint, the TP262 is the plate; if you need three openings, the Eaton is the one that fits the box.
9) How thick is the TP262 plate, and will it sit flush if the device is set deep in the box?
The plate body is .070 inch nominal thickness with an overall depth of 0.25 inch, so it sits low against the wall. Because it is a flat plate with no built-in device support, the receptacle or switch yoke has to be set so the device face comes close to the finished wall surface; a deeply recessed device leaves a gap behind the plate and may need a box extender or longer device screws.
10) Is the TP262 made in the USA?
Yes, country of origin on the TP262 TradeMaster plate is the United States, which matters on government and institutional jobs carrying domestic-sourcing requirements.
11) I need a listed plate for an inspected commercial job - how does the TP262 compare on material and listing?
The Pass & Seymour TP262 is molded of self-extinguishing nylon, 0.25 in deep with a .070 inch nominal thickness, and is cULus Listed, so it satisfies an inspector looking for a listed wallplate. Among comparable decorator covers, the Bryant NP26W is a 1-gang plate in the HWS series and the Eaton 7729V-SP is a triple-gang decorator cover; choose by gang count, since all three are decorator-opening plates and only the TP262 carries the oversized TP footprint.
