Pass & Seymour TP262W TradeMaster 2-Gang Nylon Wall Plate, White

Pass & Seymour TP262W TradeMaster 2-Gang Nylon Wall Plate, White

(No reviews yet) Write a Review

Model: TP262-W

In Stock (leaves warehouse same day if ordered before 3pm ET)

$51.69
$6.45
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pass & Seymour TP262W TradeMaster 2-Gang Nylon Wall Plate, White

The Pass & Seymour TP262W is a TradeMaster 2-gang wall plate with 2 decorator openings, finished in White. Molded of rugged, self-extinguishing nylon at a nominal thickness of .070 inch, this 'TP' series plate runs an extra 3/16 inch in width and height over Standard-size plates, making it a preferred choice for hospital, industrial, institutional, and other high-abuse applications. It is cULus Listed, CSA Listed, UL Listed, and RoHS Compliant.

Key Features

  • 2-Gang, 2 Decorator Openings: Configured for two decorator-style devices in a single wall plate.
  • Oversized TP Series Fit: Extra 3/16 inch width and height compared to Standard size plates for a secure, gap-free mount.
  • Durable Construction: Molded of rugged, practically indestructible self-extinguishing nylon for long-term durability.
  • Nominal Thickness: .070 inch for a low-profile, uniform finish.
  • High-Abuse Rated: Preferred for hospital, industrial, institutional, and other high-abuse applications.
  • Finish: Matte White finish for a clean, consistent look.
  • Also Available: Offered in Ivory, White, Brown, Gray, Black, Blue, Orange, Red, and Light Almond to match a range of decor.

Certifications & Compliance

  • cULus Listed
  • CSA Listed
  • UL Listed
  • RoHS Compliant

Technical Specifications

  • Country Of Origin: United States
  • Product Finish: Matte
  • Product Height: 4.6875 in
  • Product Line: Pass & Seymour
  • Product Width: 4.75 in
  • Product Depth: 0.25 in

Typical Applications

  • Hospital and Healthcare Facility Wiring
  • Industrial and Institutional Electrical Installations
  • High-Abuse Commercial Environments
  • Decorator Device Wall Plate Replacement
  • Renovation and New Construction Projects

Why Pass & Seymour?

Pass & Seymour builds the TradeMaster TP262W from practically indestructible self-extinguishing nylon, backed by cULus, CSA, and UL listings plus RoHS compliance. That combination of rugged material and recognized certifications makes it a dependable, code-compliant choice for demanding, high-abuse electrical environments.

Manufacturer Resources

Spec Sheet

Product Specs

Product Type:
Wallplate
Product Material:
Nylon
Product Color:
White
Configuration:
2-Gang
Product Finish:
Matte
Listing:
cULus
Country of Origin:
United States
Department:
Electrical
Product Group:
Wiring Devices
Finish:
Matte

Pass & Seymour TP262-W – Frequently Asked Questions

1) Will the Pass & Seymour TP262W cover gaps and rough drywall cuts around a 2-gang box?
That is what the TP series is for. The TP262W runs an extra 3/16 inch in both width and height over a Standard-size plate, so it overlaps a wider ring of wall around the opening and hides ragged drywall cuts or old paint lines. Overall it measures 4.75 inches wide by 4.6875 inches high at a nominal .070 inch thickness, so it still sits low and flat against the wall.
2) Does the TP262W fit toggle switches or duplex receptacles?
Neither. The TP262W is cut with two decorator (rectangular) openings, so it only suits decorator-style rocker switches, decorator dimmers, GFCIs and decorator-face receptacles. A toggle switch or a standard duplex receptacle needs a different cutout, so order a toggle or duplex plate for those devices.
3) What is a steel 2-gang alternative to the Pass & Seymour TP262W nylon wall plate in white?
For a 2-gang white plate in metal rather than nylon, the Mulberry 76432 is a 764 Series cold rolled steel 2-gang combination wallplate in white, and the Mulberry 76532 is the same idea in the 765 Series. The TP262W is molded nylon with two decorator openings; the Mulberry plates are cold rolled steel combination plates, so confirm the opening pattern matches your two devices before swapping. All three are 2-gang and finished white.
4) I need to match white plates already installed across a building. What white is the TP262W?
White with a matte finish, not gloss. If the existing plates in the building are glossy white the sheen will read slightly different side by side, though the color family matches. The same TP plate is also offered in Ivory, Brown, Gray, Black, Blue, Orange, Red and Light Almond if you are standardizing on something other than white.
5) Should I use a nylon plate like the TP262W or a steel plate in an industrial area?
Nylon plates such as the TP262W are non-conductive, will not rust, and take impact without denting, which is why they get specified for high-abuse hospital and industrial work. Steel is the alternative when the spec calls for metal or an industrial-look finish, and ZenSupply carries steel 2-gang combination plates such as the Mulberry 76432 (764 Series) and 76532 (765 Series) in white for those jobs.
6) For a hospital or high-abuse corridor, is the nylon TP262W or a steel plate the better pick?
Both are used in abuse-prone work for different reasons. The Pass & Seymour TP262W is molded of rugged, self-extinguishing nylon at a nominal .070 inch thickness and is cULus, CSA, and UL Listed plus RoHS compliant, and Pass & Seymour calls it out for hospital, industrial, and institutional applications; nylon will not dent or rust. The Mulberry 76532 765 Series is a cold rolled steel 2-gang combination plate in white, which gives you a metal face instead. Match the material to your facility standard and to the device openings you need.
7) Will the Eaton 35324W work in place of the Pass & Seymour TP262W?
No - they do different jobs. The Eaton 35324W is a wallplate with a 4-conductor data/voice modular jack built in, Type 625B4, so it terminates a phone or data line at the plate. The Pass & Seymour TP262W is a blank-of-devices nylon plate with two decorator openings that covers two separate decorator-style wiring devices you supply. Use the Eaton unit where you need the jack integrated, and the TP262W where the devices mount in the box.
8) How does the oversized TP262W differ from a mid-size plate like the Bryant PJ series?
The Pass & Seymour TP262W is a TradeMaster TP series plate that runs an extra 3/16 inch in width and height over standard-size plates, measuring 4.75 in wide by 4.6875 in high, which helps cover rough wall cutouts without gaps. The Bryant PJ Series is an M-size wallplate for wiring devices. Both are oversize relative to standard, so choose based on how much wall opening you need hidden and whether your device count is one or two.
9) What is the exact part number and where is the Pass & Seymour TP262W made?
Order it as TradeMaster TP262W, manufacturer part number TP262-W. It is made in the United States, which matters if you are working to a Buy American or domestic-content requirement on a government or institutional job.
10) Do mounting screws come with the TP262W?
The plate is sold as the nylon plate itself; mounting screws are typically supplied with the wiring device or the existing device already in the wall. If you are replacing plates only and the old screws are painted over or stripped, pick up matching white plate screws separately so you are not short on the job.
