Pass & Seymour Trademaster Tamper-Resistant Weather-Resistant Duplex Receptacle, 15A/125V

Pass & Seymour Trademaster Tamper-Resistant Weather-Resistant Duplex Receptacle, 15A/125V

(No reviews yet) Write a Review

Model: 3232TRWRLA

In Stock (leaves warehouse same day if ordered before 3pm ET)

$3.84
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pass & Seymour 3232TRWRLA Trademaster Tamper-Resistant Weather-Resistant Duplex Receptacle, 15A 125V, Light Almond

The Pass & Seymour 3232TRWRLA Trademaster Duplex Receptacle is a 15A 125V tamper-resistant, weather-resistant device built for reliable performance in both indoor and outdoor electrical installations. Finished in Light Almond, this receptacle accepts #12 - #14 AWG solid wire and is engineered with quality materials and a time-tested design for long-term durability. It is cULus Listed, giving electricians and property owners confidence that it meets recognized safety standards for professional-grade electrical work.

Key Features

  • Electrical Rating: Rated 15A 125V for standard residential and commercial receptacle circuits.
  • Tamper-Resistant & Weather-Resistant: Combines tamper-resistant shutters with weather-resistant construction for safe use in exposed and damp locations.
  • Wire Size: Accepts #12 - #14 AWG solid wire for straightforward termination.
  • Reinforced Strap Design: Two drive screws anchor the strap to the back body and face where abrupt removal torque is greatest, improving long-term device retention.
  • Quality Construction: Built from quality materials with a durable, time-tested design intended for demanding installation environments.
  • Finish & Color: Matte finish in Light Almond for a clean, neutral appearance that blends with common wall finishes.

Certifications & Compliance

  • cULus Listed

Technical Specifications

  • Country Of Origin: Mexico
  • Product Finish: Matte
  • Product Height: 3.31 in
  • Product Line: Pass & Seymour
  • Product Width: 1.32 in
  • Product Depth: 1.0 in

Typical Applications

  • Residential and Commercial Receptacle Replacement
  • Tamper-Resistant Code-Compliant Installations
  • Outdoor and Wet or Damp Location Receptacle Circuits
  • Kitchens, Bathrooms, and Exterior Wiring Devices
  • Renovation and New Construction Electrical Work

Why Pass & Seymour?

Pass & Seymour's Trademaster 3232TRWRLA delivers the tamper-resistant and weather-resistant protection professionals expect, backed by reinforced drive-screw strap construction and cULus Listed certification. Built from quality materials for durability, this duplex receptacle is a dependable choice for code-compliant residential and commercial electrical work.

Product Specs

Voltage Rating:
125V
Listing:
cULus
Product Type:
Duplex Receptacle
Department:
Electrical
Product Finish:
Matte
Product Group:
Wiring Devices
Amperage Rating:
15A
Product Subgroup:
Receptacles & Outlets
Product Width:
1.32 in
Product Height:
3.31 in
Product Depth:
1 in

Pass & Seymour 3232TRWRLA – Frequently Asked Questions

1) Can the Pass & Seymour 3232TRWR receptacle be used in an outdoor or damp location?
Yes. The Trademaster 3232TRWR is a weather-resistant device, built for both indoor and outdoor installations including wet or damp location circuits. Keep in mind a WR receptacle still needs the right enclosure and cover for the location, since the WR rating covers the device itself, not the box.
2) Does this Pass & Seymour receptacle meet the tamper-resistant requirement for dwelling unit outlets?
It is a tamper-resistant receptacle with shutters in the face, which is the device type specified where TR outlets are required. Rated 15A, 125V and cULus Listed.
3) Will a 15 amp tamper-resistant receptacle work on a 20 amp circuit?
A 15A, 125V duplex like the 3232TRWR is commonly installed on a 20A branch circuit where more than one receptacle is on the run, and it accepts #12 wire for that purpose. If the drawing calls for a 5-20R face (T-slot), you need a 20A device instead, such as the Leviton Decora Plus 16342 or the Leviton 16352-1PW, both 20A 125V NEMA 5-20R.
4) For a healthcare facility, can the 3232TRWR Trademaster be used in patient care areas?
The Trademaster 3232TRWR is a cULus Listed tamper-resistant, weather-resistant 15A 125V duplex device, but it is not a hospital grade product. Where the facility spec calls for hospital grade, the Leviton 16262-HGW is a hospital grade duplex receptacle in white, supplied in packs of 100 for standardizing across a wing or floor.
5) If the circuit is 20A, what duplex receptacle should be used instead of the 3232TRWR Trademaster?
The Trademaster 3232TRWR is rated 15A at 125V, so for a 20A duplex device look at the Bryant 5362B heavy-duty 20A/125V duplex receptacle, or the Leviton 16352-1PW commercial grade heavy-duty straight blade duplex rated 20A 125V NEMA 5-20R. Note that neither of those is described as tamper-resistant or weather-resistant, so if the opening is a damp or exposed location you still need a weather-resistant device.
6) What is the closest 15A 125V duplex alternative to the Pass & Seymour 3232TRWR?
The Eaton Arrow Hart 5262W is also a 15A 125V duplex receptacle with a 5-15R configuration, and it is built to industrial specification grade in gray. The difference that matters is protection: the Trademaster 3232TRWR combines tamper-resistant shutters with weather-resistant construction for damp and exposed locations, while the Arrow Hart 5262W is a straight industrial-grade device. Choose by whether the opening requires TR/WR.
7) Is the 3232TRWR Trademaster suitable for a hazardous or classified location?
No. The Trademaster 3232TRWR is a cULus Listed general-purpose 15A 125V tamper-resistant, weather-resistant duplex for indoor and outdoor wet or damp location circuits, not a classified-area device. For hazardous locations, the Appleton FSQC Series is an interlocked explosionproof receptacle, and the Appleton U-Line ECS is a factory-sealed 15 and 20 amp 3-pole plug and receptacle set.
8) What wire size does the Trademaster 3232TRWR duplex receptacle take?
It accepts #12 and #14 AWG solid wire, which covers standard 15A and 20A branch circuit conductors in residential and commercial work. Terminations are straightforward side-wire screw connections on a reinforced strap, with two drive screws anchoring the strap to the back body and face.
9) What colors does the Pass & Seymour 3232TRWR come in?
Two: Light Almond (3232TRWRLA) and White (3232TRWRW), both with a matte finish. If you are matching existing devices across a building, order by that part number so the shade and finish stay consistent across the fleet.
10) Is the Trademaster 3232TRWR a spec grade or commercial grade receptacle?
Trademaster is Pass & Seymour's standard-duty line with a reinforced strap design, not an industrial spec grade device. For heavier traffic or spec-grade requirements, look at the Eaton Arrow Hart 5262W (15A 125V 5-15R, industrial specification grade), the Eaton 816W commercial specification grade single receptacle, or the Leviton 16251W commercial grade impact-resistant straight blade receptacle. None of those are tamper-resistant and weather-resistant, so if you need TR/WR, stay with the 3232TRWR.
11) Only one device is needed at the location - is there a single receptacle alternative to the 3232TRWR?
Yes. The 3232TRWR Trademaster is a duplex device with two outlets. For a single-outlet device at 15A, the Eaton 816W commercial specification grade single receptacle is a 15A single. The Eaton 6450W is a heavy-duty industrial specification grade decorator single receptacle accepting #14-10 AWG, versus the Trademaster which accepts #12 - #14 AWG solid wire.
12) Will a Leviton Decora Plus 16342 work as a replacement for the 3232TRWR Trademaster?
They are not interchangeable on rating or style. The Leviton 16342 is a Decora Plus commercial grade duplex rated 20-Amp 125-Volt NEMA 5-20R in white, so it has the T-slot 5-20R face and a decorator opening in the plate. The Trademaster 3232TRWR is a 15A 125V device offered in Light Almond and White with a matte finish and standard duplex face. Match the amperage to the branch circuit and the face style to the existing wall plates.
13) Four outlets are needed at one box - what should be used instead of two 3232TRWR receptacles?
The Bryant 21254IGO is a quad straight-blade receptacle in NEMA 5-20R rated 20A, which puts four outlets in one device. The Trademaster 3232TRWR is a 15A 125V duplex, so going to the quad changes both the outlet count and the amperage configuration - confirm the branch circuit supports a 20A 5-20R device before swapping.
14) What should be used instead of the 3232TRWR for a 277V motor circuit or a high-amperage locking connection?
The Trademaster 3232TRWR is a 15A 125V straight-blade duplex and will not serve those loads. For a 277V two-pole three-wire motor-duty device, the Bryant 430R9W of the 4750DR series applies. For a high-amperage locking connection, the Eaton 7379 is an industrial locking receptacle rated 50A at 600V/250V AC/DC in black, built to extra heavy duty grade.
15) For high-abuse areas, is there a tougher alternative to the 3232TRWR Trademaster?
The Leviton 16251W is a commercial grade heavy-duty impact-resistant straight blade receptacle, which targets abuse resistance directly. The Trademaster 3232TRWR takes a different approach for retention: two drive screws anchor the strap to the back body and face where removal torque is greatest, plus it carries the tamper-resistant and weather-resistant shutters the Leviton commercial device is not described as having.
16) What are the dimensions of the 3232TRWR receptacle body?
3.31 in height, 1.32 in width, 1.0 in depth. That is a standard duplex strap footprint, so it drops into a single-gang box with a normal duplex wall plate.
17) Is a wall plate or box included with the Pass & Seymour 3232TRWR?
No. You get the duplex receptacle itself with its mounting strap and screws. Wall plate, box, and any weatherproof in-use cover for an exterior location are separate.
18) What is the difference between the Bryant 5362BI and the Pass & Seymour 3232TRWR?
The Bryant 5362BI is a 20A 125V heavy-duty duplex receptacle. The Pass & Seymour 3232TRWR Trademaster is 15A 125V with tamper-resistant shutters and weather-resistant construction, offered in Light Almond and White. If the existing device is a 20A heavy-duty duplex, the Bryant matches the rating; if the code requirement at the opening is tamper-resistant and weather-resistant, the Trademaster is the one that carries both.
