Pemko 18061 180-Degree Fire-Ra...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$27.75
$14.22
Pemko 18061 180-degree fire-rated door bottom weatherstrip, dark bronze anodized aluminum finish, 5/8" nylon brush, full-length perspective view

Pemko 18061 180-Degree Fire-Rated Door Bottom Weatherstrip with 5/8" Nylon Brush - UL10C Certified - 36" to 96"

(5 reviews) Write a Review

Model: 18061CNB 36
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$27.75
$14.22
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pemko 18061 180-Degree Fire-Rated Door Bottom Weatherstrip with 5/8" Nylon Brush

The Pemko 18061 is a 180-degree aluminum retainer door bottom weatherstrip with a 5/8" nylon brush insert, rated for commercial fire door assemblies. UL10C fire-rated with positive pressure testing, UL1784 smoke-tested, BHMA certified, and GREENGUARD Gold certified for low chemical emissions. Available in clear anodized and dark bronze anodized aluminum in lengths of 36", 42", 48", 84", and 96". Backed by a 5-year warranty.

Certifications and Compliance

  • UL10C Fire Rated, Positive Pressure
  • UL1784 Smoke Tested
  • BHMA Certified
  • GREENGUARD Gold Certified

Specifications

  • Model: 18061
  • Retainer Material: Aluminum
  • Insert Type: 5/8" Nylon Brush
  • Width: 1-1/8"
  • Height: 1/4"
  • Available Lengths: 36", 42", 48", 84", 96"
  • Finishes: Clear Anodized Aluminum, Dark Bronze Anodized Aluminum
  • Application: Commercial
  • Warranty: 5 Year

Typical Applications

  • Fire-rated door assemblies in commercial office buildings
  • Educational and healthcare facilities
  • Government and municipal buildings
  • Industrial and warehouse facilities
  • Multi-tenant residential properties

Product Specs

Insert Type:
Nylon Brush
Warranty:
5 Year
Subcategory:
Door Sweeps
Product Group:
Door Trim and Accessories
Product Subgroup:
Astragals, Gaskets and Weatherstripping
Product Type:
Weatherstripping
ANSI/BHMA:
BHMA Certified, Smoke Tested- UL1784, Fire Rated- UL10C- Positive Pressure, Underwriters Laboratory 4L10, GREENGUARD Gold Certified
Commercial/Residential:
Commercial
Product Model:
18061
Product Length:
36", 42", 48", 84" or 96"
Product Dimension:
W: 1-1/8", H: 1/4"
Product Category:
Door Trim and Accessories
Product Substrate:
Aluminum
Department:
Door Hardware

Pemko 18061CNB 36 – Frequently Asked Questions

1) What size gap will a 5/8 inch nylon brush door bottom close?
The nylon brush on the 18061 drops 5/8 inch below the retainer, so it will sweep an undercut up to roughly that. The retainer itself is 1-1/8 inch wide by 1/4 inch tall, which is the part that fastens flat to the door face. Brush is the right pick over a rubber or neoprene sweep when the floor is carpet, uneven concrete, or a threshold the door drags on, because the filaments flex instead of binding.
2) What length Pemko 18061 do I order for a 36 inch door?
Order the 36 inch. The 18061 comes in 36, 42, 48, 84, and 96 inch lengths, so match the door width for a standard opening and cut down as needed. The 84 and 96 inch pieces are there for oversized or double-egress openings, and for cutting multiple short pieces from one stick.
3) Is the Pemko 18061 a surface-mounted door bottom or does it mortise into the door?
Surface applied. The 180-degree aluminum retainer screws to the face of the door at the bottom rail, with the brush hanging below. No routing, no mortising, no door prep beyond drilling the fastener holes, which is why it's the usual retrofit choice on doors already hung. Total retainer footprint is 1-1/8 inch wide by 1/4 inch tall.
4) What else besides a door bottom do I need to seal a fire-rated opening?
A door bottom like the 18061 handles the undercut only. The head and jambs need their own gasketing. For the frame sides, the Hager 864S is a clear anodized aluminum adjustable jamb weatherstrip with a neoprene insert, and the Hager 726S is a press-on smoke seal in charcoal if you're retrofitting a frame without stopping to drill. Order the door bottom and the perimeter gasketing together or you've sealed three sides of four.
5) What is the closest nylon brush alternative to the Pemko 18061 door bottom weatherstrip?
The Cal-Royal BW-302 is the nearest match in construction: it is a nylon brush weatherstrip with an extruded aluminum seal retainer, the same retainer-plus-brush arrangement the Pemko 18061 uses with its aluminum retainer and 5/8 inch nylon brush insert. Where the two part company is on the certification package. The Pemko 18061 is BHMA certified, UL10C fire rated for positive pressure, UL1784 smoke tested, and GREENGUARD Gold certified, so it is the one to specify when the door bottom has to go on a fire door assembly and satisfy an inspector. For a non-rated opening where you just want a brush sweep in an aluminum retainer, the BW-302 covers the same mechanical job.
6) Is the Hager 864S a substitute for a Pemko 18061 door bottom?
No, and the confusion is worth clearing up because both are aluminum weatherstrip. The Hager 864S is an adjustable jamb weatherstrip with a neoprene insert in clear anodized aluminum, 84 inches long, so it mounts on the frame and seals the perimeter where the door face meets the stop. The Pemko 18061 is a door bottom: a 180 degree aluminum retainer with a 5/8 inch nylon brush that mounts on the bottom rail of the door and sweeps the threshold. On a fire door being gasketed completely you are likely buying both, the 864S up the jambs and across the head and the 18061 along the bottom, not one in place of the other.
7) Does the Pemko 18061 door bottom come in dark bronze to match my existing hardware?
Both finishes are anodized aluminum: clear and dark bronze. Every one of the five lengths (36, 42, 48, 84, 96 inch) is offered in each finish, so a property manager standardizing a building can hold one finish across mixed door widths.
8) For a smoke and draft control opening, should I use the Pemko 18061 or a neoprene insert weatherstrip like the Hager 862S?
It depends on where the seal sits and how much movement it has to tolerate. The Hager 862S is a 48 inch weatherstrip with a neoprene insert intended for smoke and draft control, a compressible elastomeric seal. The Pemko 18061 uses a 5/8 inch nylon brush in an aluminum retainer and is UL1784 smoke tested as well as UL10C fire rated for positive pressure, so it carries smoke credentials in a brush format. Brush is the usual choice at the door bottom because it sweeps over carpet, uneven slab, and threshold transitions without dragging the way a solid seal does. Neoprene is the usual choice where the door lands against a stop and can compress the seal squarely.
9) I need a dark finish door bottom. Which of these comes in a dark color?
The Pemko 18061 is offered in dark bronze anodized aluminum as well as clear anodized aluminum, in 36, 42, 48, 84, and 96 inch lengths, so a dark bronze door in a lobby or a bronze-finish storefront can be sealed without a bright aluminum line across the bottom rail. Among the comparable aluminum weatherstrips, the Hager 864S jamb weatherstrip is a clear anodized aluminum piece, and the Hager 726S smoke seal is a press-on strip in charcoal. If you are matching dark hardware at the door bottom specifically, the 18061 in dark bronze anodized is the direct route.
10) Can I cut a Pemko 18061 down to fit a narrower door?
Yes. The retainer is extruded aluminum, so it cuts to length with a hacksaw or a miter saw with a non-ferrous blade, and the nylon brush trims with it. Buyers doing a run of openings often order the 96 inch and cut two pieces from it. Take the 1-1/8 inch retainer width into account at the hinge and lock edges so the ends clear the stops.
11) Will a brush door bottom hold up in a high-traffic building?
The 18061 is a commercial-rated assembly: extruded aluminum retainer with a nylon brush insert, not a residential vinyl sweep. Nylon filaments recover after being deflected, so it tolerates the constant cycling of a stairwell or corridor door better than a rubber sweep that takes a set and stops sealing. Anodized finish on the aluminum is what handles the scuffing at floor level.
How fast can I get the Pemko 18061CNB 36 delivered?
Most orders ship the same day from our distribution partners, with quick delivery throughout the continental U.S. Need it urgently? Contact Us for expedited shipping options.
Can I return it if it doesn’t work for me?
Yes—ZenSupply offers a hassle-free return policy. If the product isn’t the right fit, reach out to our support team for a return authorization or setup a return by following our return instructions.
Does the Pemko 18061CNB 36 come with a warranty?
Absolutely. The Pemko 18061CNB 36 is backed by a manufacturer’s warranty. For full warranty terms, check the product documentation or Contact Us.
How do I get technical support or installation help for the Pemko 18061CNB 36?
You can call, text, or email our expert support team for fast answers. We’re here to help with product selection, installation tips, and troubleshooting. Contact Us
Why buy the Pemko 18061CNB 36 from ZenSupply?
ZenSupply makes it easy to get the commercial door hardware you need—fast shipping, expert support, and rewards on every order. Our team is always ready to help you choose the right product for your project.

Product Reviews

  • 4
    Keeping Drafts at Bay

    Posted by Philip on Sep 11th 2023

    The Pemko 18061 Aluminum Retainer Weatherstrip with Nylon Brush is a great investment for sealing gaps and keeping drafts out. The nylon brush is durable and effective. However, it might take some effort to trim it to the right size during installation. Overall, it's a solid choice for improving insulation.

  • 5
    Great for Draft Protection, But Installation Can Be Tricky

    Posted by Andy on Dec 27th 2023

    This weatherstrip's nylon brush effectively blocks drafts, great for energy savings. Yet, the installation might pose challenges, especially for beginners.

  • 5
    Effective Weatherstripping for Draft-Free Homes

    Posted by Ryan on Dec 14th 2023

    This Pemko 18061-180 Aluminum Retainer Weatherstrip is a winner! The nylon brush seals gaps like a champ, keeping drafts out efficiently. However, for smaller gaps, the brush might be too thick. Overall, a solid solution for maintaining a cozy home atmosphere.

  • 5
    Bye-Bye Drafts, Hello Comfort!

    Posted by Francis on Aug 25th 2023

    Scored the Pemko 18061-180 Aluminum Retainer Weatherstrip from ZenSupply. The nylon brush is a champ at keeping cold air out. My only heads-up? Installation was a bit fiddly, but once it's on, it's a game-changer. Stay cozy, friends!

  • 5
    Efficient weatherstripping for a draft-free environment.

    Posted by Ethan on Jul 13th 2023

    Howdy, folks! I recently installed the Pemko 18061-180 Aluminum Retainer Weatherstrip with 5/8" Nylon Brush from ZenSupply, and it's been a game-changer. The weatherstripping effectively seals off any gaps, keeping drafts at bay and improving energy efficiency. One aspect I really liked is the durable nylon brush, which not only provides excellent weatherproofing but also operates smoothly. However, do note that the installation process may require some precision and additional tools. Overall, it's a reliable choice for creating a more comfortable and draft-free environment.

!
