Pemko 253FG Thermal Barrier Threshold with Frost Guard 3" Wide Half Saddle

Pemko 253FG Thermal Barrier Threshold with Frost Guard 3" Wide Half Saddle

(No reviews yet) Write a Review

Model: 253X3AFG 36
$103.89
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$103.89
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pemko 253 Thermal Barrier Threshold with Frost Guard 3"; Wide Half Saddle Mill Aluminum

Professional Half Saddle Threshold Solution

The Pemko 253 series thermal barrier threshold is a 3"; wide half saddle designed to effectively fill offset floors by 1/2"; and create smooth transitions between different floor surfaces. This BHMA certified and fire rated threshold features an integrated channel for connecting thermal keys and mill aluminum construction for commercial applications. Available in lengths from 24"; minimum to 185"; maximum with custom cutting capabilities.

Professional Features & Benefits

  • Precise Offset Compensation: 1/2"; height and 3"; width dimensions effectively fill floor offsets for smooth surface transitions.
  • Thermal Performance: Integrated channel design accommodates thermal keys for enhanced energy efficiency and weather sealing.
  • Fire Safety Compliance: Fire rated construction meets commercial building safety requirements for egress applications.
  • BHMA Certification: Certified performance standards ensure reliable operation in demanding commercial environments.
  • Flexible Length Options: Available from 24"; minimum to 185"; maximum length with custom cutting capabilities for precise fit.
  • ADA Accessibility: When butted to a 1/2"; offset, provides ADA compliant transition for accessible design requirements.
  • Modular Configuration: Can be combined with other half saddles to create custom size and configuration solutions.
  • Professional Installation: Wood screw standard fasteners (#10 x 1.5";) with alternative fastener options available for various substrates.

Technical Specifications

  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Product Category: Door Trim and Accessories
  • Product Dimension: H: 1/2", W: 3";
  • Product Group: Door Trim and Accessories
  • Product Model: 253
  • Product Subgroup: Door Thresholds
  • Product Substrate: Aluminum
  • Product Type: Thresholds
  • Subcategory: Thresholds

Professional Applications

  • Commercial Office Building Entrances
  • Educational Facility Doorways
  • Healthcare Institution Access Points
  • Retail Store Entry Systems
  • Industrial Facility Personnel Doors
  • Multi-Tenant Residential Common Areas
  • Government Building Egress Points

Why Choose Pemko Quality?

Pemko 253 series thresholds deliver professional-grade performance with aluminum construction and BHMA certification for demanding commercial applications. Fire rated design ensures code compliance while the integrated thermal channel system provides enhanced energy efficiency. Engineered for reliable long-term performance in high-traffic commercial environments where smooth floor transitions and thermal control are essential.

Product Specs

Product Group:
Door Trim and Accessories
Product Subgroup:
Door Thresholds
Subcategory:
Thresholds
Commercial/Residential:
Commercial
Product Model:
253
Product Dimension:
H: 1/2", W: 3"
Product Substrate:
Aluminum
Product Category:
Door Trim and Accessories
Department:
Door Hardware
Product Type:
Thresholds

Pemko 253X3AFG 36 – Frequently Asked Questions

1) Will the Pemko 253 threshold work where my finished floors are at different heights?
That's what the 253 half saddle is built for. At 1/2 inch high and 3 inches wide, it fills a 1/2 inch floor offset and gives you a transition between two different floor surfaces. Butted to a 1/2 inch offset it produces an ADA compliant transition. If your offset is larger than 1/2 inch, this profile won't bridge it on its own.
2) Is the Pemko 253 threshold fire rated for a labeled opening?
Fire rated, and BHMA certified. The 253 is a commercial-duty aluminum threshold intended for egress and other code-driven openings in offices, schools, healthcare, retail and government buildings.
3) What is the difference between the Pemko 253 with Frost Guard and the version with the ThermoSeal insert?
Two builds ship under the 253. One is the 6-1/8 inch Thermal Barrier Threshold with Frost Guard; the other is the Thermal Barrier Threshold with Frost Guard and ThermoSeal Insert. Both are the same 1/2 by 3 inch half saddle aluminum profile in mill or dark bronze anodized, and both use the integrated channel that connects thermal keys. Pick the ThermoSeal insert build where you want the added seal element at the threshold; pick the plain Frost Guard build where the thermal break alone is what the spec calls for.
4) Is a half saddle threshold the right choice, or do I need a full saddle?
A half saddle like the 253 sits on one side of the opening and is meant to fill an offset between two floor levels, 1/2 inch here. A full saddle spans the whole door opening and crowns in the middle, which is what you want when both floors are level and you need a single symmetrical piece under the door. If your floors step, the half saddle is the correct part, and two half saddles can be combined to build a custom configuration across the opening.
5) What screws do I need to install a Pemko 253 threshold, and are they included?
The standard fastener for the 253 is a #10 x 1-1/2 inch wood screw. Alternative fasteners are offered for other substrates, so if you're anchoring into concrete or a steel sill rather than a wood sub-sill, order the fastener type that matches the floor you're drilling into.
6) Which finish should I order on the Pemko 253 to match the rest of my entrances?
Two finishes cover the 253: mill finish aluminum and dark bronze anodized aluminum, and both are available in all four stock lengths (36, 40, 48 and 72 inches). Mill is the plain silver-grey aluminum that disappears under most storefront and hollow metal work; dark bronze anodized matches bronze-finish entrance systems. Anodizing also puts a harder surface on the wear face, which matters on a threshold that gets walked over all day.
7) What does the thermal barrier on the Pemko 253 actually do at an exterior door?
The 253 carries an integrated channel that connects thermal keys, breaking the metal-to-metal path through the threshold. That's what keeps the interior face from conducting cold straight through at an exterior opening, which is where the frost guard name comes from. On an interior transition between two floor finishes the thermal break does nothing for you, so the plainer half saddle profiles are the ones to look at there.
8) I'm replacing a worn Pemko 253 threshold. Can I reuse the existing screw holes?
The 253 profile is unchanged at 1/2 inch high by 3 inches wide, so a like-for-like replacement drops into the same footprint. Whether the old anchor holes line up depends on how the original was laid out, and the standard #10 x 1-1/2 inch wood screws will need fresh purchase if the sub-sill is chewed up. Order the length that matches your opening from the 36, 40, 48 and 72 inch stock sizes, or have a piece cut anywhere from 24 to 185 inches.
9) Will an aluminum threshold hold up in a high traffic building entrance?
The 253 is aluminum and specified as a commercial product, used at office entrances, school and healthcare doorways, retail entries, industrial personnel doors and government egress points. For a property manager standardizing across a portfolio, it's the same profile every time at 1/2 by 3 inches, so replacements match what's already down.
