Pemko 277 Series Latching Panic Saddle Threshold, 7/8" Height

Pemko 277 Series Latching Panic Saddle Threshold with Integrated Gasket Seal - 7/8" Height

(No reviews yet) Write a Review

Model: 277DS 36
$120.27
$107.69
Selected Latching Panic Saddle Threshold is
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$120.27
$107.69
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pemko 277 Series Latching Panic Saddle Threshold with Integrated Gasket Seal - 7/8"; Height

Professional Door Sealing Solution for Acoustic Applications

The Pemko 277 Series Latching Panic Saddle Threshold delivers comprehensive door bottom sealing with an integrated gasket system designed for acoustic applications. This 7/8"; height aluminum threshold creates an effective seal against sound, air infiltration, wind, and debris while accommodating 5/8"; door clearance. Available with either sponge neoprene or silicone insert options, this threshold works in conjunction with surface applied vertical rod exit devices or functions as a standalone stop and seal solution.

Professional Features & Benefits

  • Precise Dimensions: 7/8"; height design with 5/8"; door clearance for proper fit and operation with standard door configurations.
  • Flexible Length Options: Available in lengths from 6"; minimum to 185"; maximum to accommodate various door widths and configurations.
  • Aluminum Construction: Durable aluminum base material provides long-lasting performance and corrosion resistance in commercial applications.
  • Integrated Gasket Sealing: Built-in gasket creates comprehensive seal against sound, air infiltration, wind, and debris for superior acoustic performance.
  • Exit Device Compatibility: Specifically designed for use with surface applied vertical rod exit devices for comprehensive door sealing systems.
  • Dual Insert Options: Choose between sponge neoprene (277R) for temperature flexibility or silicone (277S) for high-performance chemical and weather resistance.
  • Standard Installation: Includes WS #10 x 1.5"; wood screws with other fastener options available for different substrate requirements.

Technical Specifications

  • Department: Door Hardware
  • Product Category: Door Trim and Accessories
  • Product Dimension: H: 7/8";
  • Product Group: Door Trim and Accessories
  • Product Model: 277
  • Product Subgroup: Door Thresholds
  • Product Type: Commercial Thresholds
  • Series: 277 Series
  • Subcategory: Thresholds

Professional Applications

  • Commercial Office Buildings with Acoustic Requirements
  • Educational Facilities and Classroom Environments
  • Healthcare Institutions Requiring Sound Control
  • Recording Studios and Audio Production Facilities
  • Conference Rooms and Meeting Spaces
  • Hotels and Hospitality Sound Management
  • Multi-Tenant Buildings with Noise Control Needs

Insert Material Options

The 277R model features sponge neoprene insert that remains flexible at high and low temperatures while resisting deterioration from oily substances with slight compressibility for effective sealing. The 277S model utilizes high-performance silicone insert made from synthetic materials that are nonreactive, stable, and resistant to extreme environments including sunlight, weather, ozone, water, and flame with self-extinguishing properties and resistance to fungus and mildew.

Why Choose Pemko Quality?

Pemko 277 Series thresholds combine precision aluminum construction with advanced gasket technology rated for lengths up to 185"; maximum. The dual insert material options provide flexibility for specific environmental requirements while maintaining consistent sealing performance. Engineered for demanding commercial applications where acoustic control and environmental sealing are essential.

Product Specs

Subcategory:
Thresholds
Product Group:
Door Trim and Accessories
Product Subgroup:
Door Thresholds
Product Type:
Commercial Thresholds
Product Model:
277
Product Dimension:
H: 7/8"
Product Category:
Door Trim and Accessories
Department:
Door Hardware
Series:
277 Series

Pemko 277DS 36 – Frequently Asked Questions

1) Will the Pemko 277 threshold work with a surface vertical rod exit device on my door?
That's what the 277 saddle threshold is built around. It's a latching panic saddle, so the bottom rod of a surface applied vertical rod exit device latches into it, and the integrated gasket seals the door bottom at the same time. If your pair or single has an SVR device with a bottom rod, this is the matching threshold. If you've pulled the bottom rod (an LBR setup) or you're running a rim device, the 277 still functions as a plain stop and seal, you just won't be using the latching feature.
2) How much clearance do I need under the door for a Pemko 277 saddle threshold?
The 277 is a 7/8 inch high threshold that accommodates 5/8 inch door clearance. Measure from the finished floor to the bottom of the door in the swing: you need 5/8 inch of undercut for the door to clear the saddle and compress the gasket properly. Doors cut tighter than that will drag or won't close; doors cut much deeper leave the gasket short of a seal.
3) Should I order the 277R neoprene or the 277S silicone insert?
Pick by what the door sees. The 277R sponge neoprene stays flexible hot and cold and shrugs off oily substances, which suits service entrances, kitchens, and shops. The 277S silicone is nonreactive and stable against sunlight, weather, ozone, water, and flame, self-extinguishing, and resists fungus and mildew, so it's the one for exterior exposure, wet or humid areas, and anywhere UV hits the sill. Mill finish and dark bronze anodized are both offered with the silicone insert.
4) What fasteners come with the Pemko 277 threshold and will they work on a concrete sill?
The 277 ships with WS #10 x 1.5 inch wood screws, which are fine into wood sills or a wood subfloor. Concrete needs anchors instead, and Pemko lists other fastener options for different substrates, so specify the concrete fastener when you order rather than assuming the bundled wood screws will do. Budget the anchors and the drilling into the job either way.
5) Is the Pemko 277 threshold available in dark bronze to match our other door hardware?
Two finishes are offered on the 277 saddle: mill finish aluminum and dark bronze anodized aluminum. Both are available in the 36 inch and 72 inch lengths. Mill is the standard raw aluminum look that disappears at most commercial entrances; dark bronze anodized is the one to order when the frames and exit devices on the rest of the building are dark bronze.
6) Will a saddle threshold with a gasket actually cut sound transfer under a classroom or office door?
The gasket is the part doing the acoustic work. The 277 carries an integrated gasket that seals against sound, air infiltration, wind, and debris, and the door bottom is where most sound leaks on an otherwise solid opening. It only performs if the rest of the perimeter is sealed too, so pair it with head and jamb gasketing on classrooms, conference rooms, exam rooms, and studios. A sealed sill under an unsealed frame does not get you a quiet room.
