Pemko 29326-62 Fire-Rated Door...
IN STOCK (leaves warehouse same day if ordered before 3pm ET)
$60.83
$45.57
Pemko 29326 62" (5.16') Door Bottom Sweep with 9/16" Vinyl Sweep

Pemko 29326-62 Fire-Rated Door Bottom Sweep with 9/16" Nylon Brush Insert - 62" Length

(No reviews yet) Write a Review

Model: 29326-CV62
Selected Finish is

In Stock (leaves warehouse same day if ordered before 3pm ET)

$60.83
$45.57
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Pemko 29326 Fire-Rated Door Bottom Sweep with 9/16"; Nylon Brush Insert - 62"; Length

Professional Fire-Rated Door Sealing Solution

The Pemko 29326 Door Bottom Sweep delivers comprehensive door sealing with a 9/16"; nylon brush insert designed for 62"; door applications. This aluminum construction door sweep features BHMA certification and UL10C fire rating with positive pressure testing, ensuring reliable performance in commercial environments. The snap-on aluminum cover provides vandal-resistant protection while concealing mounting hardware for a clean professional appearance with 7/8"; profile height.

Professional Features & Benefits

  • Precise Length Specification: 62"; (5.16') length designed for standard commercial door widths with professional installation requirements.
  • Fire-Rated Performance: UL10C positive pressure fire rating and UL1784 smoke testing certification for code-compliant installations in fire-rated assemblies.
  • Professional Brush Sealing: 9/16"; nylon brush insert provides effective sealing against air infiltration, dust, and light while allowing smooth door operation.
  • Vandal-Resistant Design: Aluminum snap cover conceals mounting screws and snaps securely into place to deter tampering and vandalism.
  • Durable Aluminum Construction: Aluminum substrate provides long-term durability and corrosion resistance for demanding commercial applications.
  • Clean Aesthetic Profile: 7/8"; profile height with concealed mounting hardware delivers professional appearance suitable for high-visibility installations.
  • Multiple Certifications: BHMA certified, cUL Listed 4L10, and GREENGUARD Gold certified for comprehensive compliance and indoor air quality standards.
  • Manufacturer Warranty: 5 Year warranty coverage for added confidence and long-term protection.

Technical Specifications

  • ANSI/BHMA: BHMA Certified, Fire Rated UL10C Positive Pressure, cUL Listed 4L10, GREENGUARD Gold Certified
  • Commercial/Residential: Commercial
  • Department: Door Hardware
  • Features: Aluminum Snap Cover Conceals Mounting Screws to Provide a Clean Aesthetic Appearance, Cover Snaps Securely Into Place to Deter Vandalism, Profile Height: 7/8";
  • Insert Type: Nylon Brush Insert
  • Product Category: Door Trim and Accessories
  • Product Group: Door Trim and Accessories
  • Product Length: 62";
  • Product Model: 29326
  • Product Subgroup: Door Bottom Sweeps and Door Shoes
  • Product Substrate: Aluminum
  • Product Type: Door Sweeps and Bottoms
  • Subcategory: Door Bottoms & Door Shoes
  • Warranty: 5 Year

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Pemko Quality?

Pemko door bottom sweeps deliver professional-grade sealing performance with aluminum construction and comprehensive certifications including BHMA, UL10C fire rating, and GREENGUARD Gold certification. The 5 Year warranty coverage and vandal-resistant snap cover design ensure reliable long-term performance in demanding commercial applications where effective door sealing and professional appearance are essential.

Product Specs

Features:
Aluminum Snap Cover Conceals Mounting Screws to Provide a Clean Aesthetic Appearance, Cover Snaps Securely Into Place to Deter Vandalism, Profile Height: 7/8"
Insert Type:
Nylon Brush Insert
Warranty:
5 Year
Product Group:
Door Trim and Accessories
Product Subgroup:
Door Bottom Sweeps and Door Shoes
Product Type:
Door Sweeps and Bottoms
Subcategory:
Door Bottoms & Door Shoes
ANSI/BHMA:
BHMA Certified, Fire Rated UL10C Positive Pressure, cUL Listed 4L10, GREENGUARD Gold Certified
Commercial/Residential:
Commercial
Product Model:
29326
Product Length:
62"
Product Substrate:
Aluminum
Product Category:
Door Trim and Accessories
Department:
Door Hardware

Pemko 29326-CV62 – Frequently Asked Questions

1) Will a 62 inch Pemko 29326 door sweep work on a standard 36 inch commercial door?
No, not without cutting. The 29326 comes as a 62 inch extrusion, which is sized for wide leaves or a pair of doors, not a single 36 inch opening. Aluminum sweep housings are routinely cut to length on site with a hacksaw or chop saw, so a 62 inch piece can be trimmed down, but if you want a stock length closer to the door width you are better off ordering a shorter piece rather than throwing away two feet of aluminum on every opening.
2) Is the Pemko 29326 sweep approved for use on a fire rated door?
Yes. The 29326 is BHMA certified and fire rated to UL10C positive pressure, and it is cUL Listed 4L10 for Canadian jobs. It also carries GREENGUARD Gold certification, which matters on healthcare and school specs where indoor air quality language shows up in the submittal.
3) Should I use a nylon brush door sweep or a vinyl or neoprene one?
Brush is the choice when the door drags or sees heavy traffic. The 29326 carries a 9/16 inch nylon brush insert, which sweeps dust, light and air infiltration without the drag and eventual tearing you get from a solid blade rubbing a rough threshold. A solid insert seals tighter against air and water, so for a weather-exposed exterior opening look at a vinyl sweep like the NGP 101V or a neoprene one like the NGP 197NA instead. For extreme temperature swings, the NGP 200SA silicone sweep is rated from -100 F to 500 F.
4) How much clearance under the door does the Pemko 29326 sweep need?
The brush hangs 9/16 inch below the housing, and the housing itself is a 7/8 inch profile height that mounts to the face of the door above the bottom edge. So plan on roughly a half inch undercut for the brush to sweep the floor without being crushed. If your door is hung tight to the finish floor, the brush will be compressed and will wear early.
5) Which door sweep should I use on an opening that needs a solid weather seal instead of a brush?
A brush insert like the one on the Pemko 29326 lets air pass through the bristles by design, which suits smoke and dust control and doors that drag. Where you need a continuous blade against the floor, the NGP 101V uses a vinyl seal in an aluminum alloy housing and the NGP 197NA uses a neoprene seal in an anodized aluminum housing. All three mount to the face of the door bottom in an aluminum carrier, so the mounting approach on the door does not change with the seal material.
6) What door sweep handles high heat where the Pemko 29326 brush is not the right choice?
For openings with extreme temperature swings - boiler rooms, kitchen lines, freezer vestibules - the NGP 200SA is the one to look at. It is a silicone door sweep in an anodized aluminum housing rated over a temperature range of -100 F to 500 F. The Pemko 29326 is a nylon brush sweep on an aluminum body and is BHMA certified with a UL10C positive pressure fire rating, so it is the one to specify when the requirement on the drawing is fire-rated assembly compliance rather than a service temperature.
7) Do any of the alternative door sweeps carry the same fire rating as the Pemko 29326?
The Pemko 29326 is the one to specify when the opening is a fire-rated assembly. It is BHMA certified, fire rated to UL10C positive pressure, cUL Listed 4L10, and GREENGUARD Gold certified. The comparable sweeps are identified by seal material and housing - the NGP 101V by its vinyl seal, the NGP 197NA by neoprene, the NGP 200SA by silicone, and the Cal-Royal BTN-112 by a neoprene insert in an extruded aluminum retainer. For an inspector signing off on a rated door, specify the 29326 and its listings.
8) What finishes does the Pemko 29326 door sweep come in?
Two anodized aluminum finishes: clear anodized and dark bronze anodized. Clear is the usual match for aluminum storefront and mill finish frames; dark bronze matches bronze anodized entrances and dark painted hollow metal. Since the snap cover is the visible part of the assembly, pick the one that matches the door face rather than the threshold.
9) Will a nylon brush sweep stop water and drafts on an exterior entrance?
Only partly. A 9/16 inch nylon brush blocks dust, light and air infiltration while letting the door swing freely, but bristles do not form the continuous contact seal a solid blade does, so it is not the part to specify where you are fighting driving rain. The 29326 is a commercial product and it earns its place on interior fire rated openings, corridor doors, and smoke separations. For a weather seal at an exterior door, a vinyl or neoprene sweep such as the NGP 101V or NGP 197NA is the better fit.
10) I am replacing brush sweeps across a building. Can I standardize on the Pemko 29326?
It works as a fleet standard if your openings are wide leaves or pairs, since it ships in a single 62 inch length rather than a range of sizes. One model number, two finishes, and a UL10C positive pressure rating means the same part can go on both your fire rated and non rated openings, which keeps the stockroom simple. If the building also has narrower single doors, you will either be cutting these down or carrying a shorter brush sweep alongside, such as the NGP 600 1/2 inch nylon brush sweep.
11) Does the Pemko 29326 sweep have any smoke rating for a smoke barrier door?
Yes. Alongside the UL10C positive pressure fire rating, the 29326 is UL1784 smoke tested, which is the air leakage standard inspectors look for on smoke barrier assemblies. Combined with cUL Listed 4L10, it covers both US and Canadian fire and smoke submittals.
12) For a vandal-prone entrance, which door sweep conceals its mounting screws?
The Pemko 29326 is the one built for that. Its aluminum snap cover conceals the mounting screws and snaps securely into place to deter vandalism, giving a clean 7/8 inch profile with no exposed fasteners to pick at. The Cal-Royal BTN-112 carries its neoprene insert in an extruded aluminum retainer, and the NGP 197NA and NGP 200SA use anodized aluminum housings. Where tampering at the door bottom is the concern in a school corridor or public restroom, the concealed-screw cover is the difference.
13) How does the Pemko 29326 differ from a Cal-Royal BTN-112 door sweep?
Different insert material, same general idea. The 29326 is a nylon brush in an aluminum housing with a snap cover over the screws. The Cal-Royal BTN-112 uses an extruded aluminum retainer with a neoprene insert, so it is a solid blade seal rather than bristles. Neoprene seals air and weather more tightly; brush tolerates uneven floors and heavy swing cycles better. Choose on the floor condition and the traffic, not the housing.
