Philips Lighting 16.5W PL-L LED Tube 2G11 Base Retrofit

(No reviews yet) Write a Review

Model: 532903

In Stock (leaves warehouse same day if ordered before 3pm ET)

$25.18
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Philips Lighting 16.5W PL-L LED Tube 3500K 2200 Lumens Ballast Compatible Retrofit Lamp

Professional LED retrofit solution with superior energy efficiency

The Philips Lighting 16.5W PL-L LED Tube delivers professional-grade illumination with 3500K color temperature and 2200 lumens output. This ballast-compatible retrofit lamp features durable polycarbonate construction and 2G11 base configuration, providing over 40% energy savings compared to traditional CFL alternatives. With 50000-hour rated lifetime and 82 CRI, this LED tube offers reliable performance for commercial and residential applications.

Professional Features & Benefits

  • 16.5W Power Rating: Delivers efficient illumination while reducing energy consumption by over 40% compared to traditional CFL lamps
  • 3500K Color Temperature: Provides warm white light ideal for retail, hospitality, and general lighting applications
  • 2200 Lumens Output: Ensures bright, consistent illumination with 133 lm/W luminous efficacy for professional environments
  • Ballast Compatible Design: Type A configuration works directly with existing fluorescent ballasts for easy plug-and-play installation
  • 50000 Hour Lifetime: Extended operational life minimizes maintenance costs and replacement frequency
  • DLC Standard Certification: Meets energy efficiency standards for utility rebate eligibility and professional installations
  • Durable Polycarbonate Construction: Withstands temperature ranges from -20�C to 45�C ambient for reliable long-term performance

Technical Specifications

  • Base: 2G11 [ 2G11]
  • Beam Angle Nom : 160 �
  • Color Code: 835 [ CCT of 3500K]
  • Color Consistency: <6
  • Color Designation: White (WH)
  • Color Rendering Index Nom : 82
  • Correlated Color Temperature Nom : 3500 K
  • Dimmable: No
  • Energy Certifications: DLC Standard
  • Energy Saving Product: Yes
  • Eu Rohs Compliant: Yes
  • Initial Lumen Nom : 2200 lm
  • Input Frequency: 40000-160000 Hz
  • Lamp Current Max : 400 mA
  • Lamp Current Min : 200 mA
  • Llmf At End Of Nominal Lifetime Nom : 70%
  • Luminous Efficacy Rated Nom : 133.00 lm/W
  • Nominal Lifetime Nom : 50000 h
  • Power Factor Nom : 0.9
  • Power Rated Nom : 16.5 W
  • Starting Time Nom : 0.5 s
  • Switching Cycle: 50000X
  • T Ambient Max : 45 �C
  • T Ambient Min : -20 �C
  • T Case Maximum Nom : 75 �C
  • T Storage Max : 65 �C
  • T Storage Min : -40 �C
  • Ul Type: Type A - works on ballast
  • Voltage Nom : 70-110 V
  • Warm Up Time To 60 Light Nom : 0.5 s

Professional Applications

  • Retail and hospitality environments requiring warm white illumination
  • Residential and multi-family complexes for general lighting upgrades
  • Office buildings and commercial facilities seeking energy-efficient retrofits
  • Educational institutions and healthcare facilities
  • Property management companies upgrading existing fluorescent systems
  • Maintenance and facility management operations

Why Choose Philips Lighting Quality?

Philips Lighting delivers proven reliability with DLC Standard certification and RoHS compliance. The 50000-hour rated lifetime and superior color maintenance ensure consistent performance throughout the lamp's operational life, while the polycarbonate construction provides durability in demanding commercial environments.

Manufacturer Resources

Product Specs

T Storage Min:
-40 °C
Input Frequency:
40000-160000 Hz
T Ambient Max:
45 °C
Color Rendering Index Nom:
82
Voltage Nom:
70-110 V
Energy Certifications:
DLC Standard
Energy Saving Product:
Yes
Power Rated Nom:
16.5 W
T Ambient Min:
-20 °C
Power Factor Nom:
0.9
Beam Angle Nom:
160 °
Lamp Current Max:
400 mA
Dimmable:
No
Ul Type:
Type A - works on ballast
Warm Up Time To 60 Light Nom:
0.5 s
Base:
2G11 [ 2G11]
Starting Time Nom:
0.5 s
Product Type:
LED Tube
Switching Cycle:
50000X
Lamp Current Min:
200 mA
Eu Rohs Compliant:
Yes
Llmf At End Of Nominal Lifetime Nom:
70%
T Case Maximum Nom:
75 °C
T Storage Max:
65 °C
Color Consistency:
<6
Nominal Lifetime Nom:
50000 h
Department:
Electrical

Philips Lighting 532903 – Frequently Asked Questions

1) Do I have to rewire the fixture or remove the ballast to install this Philips 16.5W PL-L LED tube?
No rewiring. The Philips 16.5W PL-L LED lamp is a UL Type A lamp, meaning it runs on the existing fluorescent ballast, so it drops straight into the 2G11 sockets and you are done. Keep in mind the ballast has to stay in the circuit and keep working; when it eventually fails, the lamp goes dark with it.
2) Will this LED lamp work on my existing PL-L fluorescent ballast, or do I need to check something first?
Check the ballast's output against the lamp's operating window. This PL-L LED retrofit runs at 70-110 V with a lamp current between 200 mA and 400 mA, on a ballast output frequency of 40,000 to 160,000 Hz. That covers typical electronic PL-L ballasts. If the fixture uses an older magnetic ballast operating outside that frequency band, the lamp is not a match for it.
3) Can I put this PL-L LED lamp on a dimmer?
No. The Philips 16.5W PL-L LED tube is non-dimmable. Putting it on a dimming ballast or a wall dimmer will give you flicker or no start at all. For a space that needs dimming, spec a lamp rated for it rather than this one.
4) Is this PL-L LED lamp OK in an unheated parking garage or exterior canopy fixture?
It runs in ambient temperatures from -20 C up to 45 C, which covers most unheated garages and covered exterior fixtures in moderate climates. Case temperature tops out at 75 C, so a tightly enclosed lensed fixture in a hot mechanical space is the situation to watch. Storage range is -40 C to 65 C if stock sits in a trailer or an attic stockroom.
5) Does this Philips PL-L LED retrofit qualify for a utility rebate?
It carries DLC Standard listing, which is the qualification most utility prescriptive rebate programs require for LED retrofit lamps. It is also EU RoHS compliant. Rebate amounts and program rules vary by utility, so confirm the DLC Standard tier is accepted on the program you are filing under.
6) Will these lamps look consistent from fixture to fixture across a floor?
Color consistency is held to under 6 SDCM, and every lamp is 82 CRI at the ordered color temperature. Across a run of fixtures in the same corridor that keeps visible color shift down, provided you order all of one color temperature rather than mixing the 3500K and 4000K versions.
7) Will this LED retrofit trip the breaker or upset power quality if I install hundreds of them in a building?
Power factor is 0.9 nominal at 16.5 W per lamp. On a large-scale changeout the connected load per fixture drops substantially against the fluorescent lamp plus ballast it replaces, so existing branch circuits end up loaded lighter, not heavier.
