Philips Lighting 9137012 CENTIUM Electronic Fluorescent Ballast, 120-277V, Metal SC Housing

Philips Lighting 9137012 CENTIUM Electronic Fluorescent Ballast, 120-277V, Metal SC Housing

(No reviews yet) Write a Review

Model: 913701264801

In Stock (leaves warehouse same day if ordered before 3pm ET)

$128.83
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Philips Lighting 9137012 CENTIUM Electronic Fluorescent Ballast, 120-277V, Metal SC Housing

The Philips Lighting 9137012 CENTIUM electronic fluorescent ballast delivers reliable, code-compliant performance for commercial and outdoor fluorescent fixtures. This ballast accepts a universal 120 to 277V input at 50 to 60 Hz, housed in a durable metal SC-type enclosure measuring 9.5" x 1.7" x 1.18". With just 10% Total Harmonic Distortion (USA) and CSA certification, the 9137012 supports tandem, through, and remote wiring configurations for flexible fixture design.

Key Features

  • Universal Input: 120 to 277 V at 50 to 60 Hz supports commercial voltage systems without additional hardware.
  • Metal SC Housing: Durable metal housing measuring 9.5" x 1.7" x 1.18", rated Hum and Noise Level A for quiet operation.
  • Electronic Fluorescent Ballast Type: Series lamp connection supporting 1/2 lamp(s) per unit, with tandem, through, and remote wiring configurations allowed.
  • Low THD: 10% Total Harmonic Distortion (USA) delivers improved power quality on the connected circuit.
  • Solid Wire Leads: 18AWG solid wire with 0.50/0.375 mm strip length; no connector included, simplifying field termination.
  • Outdoor Rated: Suitable for outdoor use with a 70°C maximum case temperature, ideal for exposed commercial fixtures.

Certifications & Compliance

  • CSA Certificate
  • FCC Non-Consumer EMC Immunity Standard

Technical Specifications

  • Numerator Packs Per Outer Box: 10
  • Total Harmonic Distortion Usa: 10%
  • Numerator Quantity Per Pack: 1
  • Hum And Noise Level: A
  • Ul Recognized: No
  • Housing Type: SC
  • Tandem Wiring Configuration Allowed: Yes
  • Suitable For Outdoor Use: Yes
  • Through Wiring Configuration Allowed: Yes
  • Remote Wiring Configuration Allowed: Yes

Typical Applications

  • Commercial Fluorescent Fixture Retrofits
  • Outdoor Lighting Installations
  • Tandem and Through-Wired Fixture Configurations
  • New Construction Commercial Lighting

Why Philips Lighting?

Philips Lighting engineers the CENTIUM ballast series with durable metal SC housings and CSA-certified performance for demanding commercial and outdoor installations. Low 10% THD and support for tandem, through, and remote wiring configurations deliver consistent, code-compliant operation, while the Hum and Noise Level A rating and solid 18AWG wire leads simplify quiet, reliable field installation.

Manufacturer Resources

Product Specs

Numerator Packs Per Outer Box:
10
Housing Dimensions:
9.5" x 1.7" x 1.18"
Housing Material:
Metal
Material Nr 12nc:
9.13701E+11
Wire Striplength:
0.50/0.375 mm
Input Frequency:
50 to 60 Hz
Lamp Connection:
Series
Total Harmonic Distortion Usa:
10%
Ballast Type:
Electronic Fluorescent
Numerator Quantity Per Pack:
1
Input Voltage:
120 to 277 V
Color Input Terminals:
No terminals
Wire Type:
Solid
Product Type:
Fluorescent Ballast
Ean Upc Product:
7.81087E+11
Color Output Terminals:
No terminals
Approval Marks:
CSA certificate
Hum And Noise Level:
A
Ul Recognized:
No
Connector Type:
No connector
Wire Gauge Nom:
18AWG mm
Housing Type:
SC
T Case Maximum Nom:
70 °C
Tandem Wiring Configuration Allowed:
Yes
Emc Immunity Standard:
FCC Non-Consumer
Order Code:
9.13701E+11
Suitable For Outdoor Use:
Yes
Through Wiring Configuration Allowed:
Yes
Wire Length By Color:
See data sheet
Remote Wiring Configuration Allowed:
Yes
Number Of Lamps:
1/2 piece/unit
Department:
Electrical

Philips Lighting 913701264801 – Frequently Asked Questions

1) Will the Philips CENTIUM ICN2S ballast run on both 120V and 277V circuits?
Yes. The CENTIUM ICN2S is a universal-voltage electronic fluorescent ballast accepting 120 to 277 V at 50 to 60 Hz, so the same part works on a 120V tenant circuit or a 277V commercial lighting panel. That is what lets a property manager or MRO stock stock one ballast across mixed-voltage buildings instead of two.
2) How many lamps does the Philips CENTIUM ICN2S ballast drive?
It runs one or two lamps, wired in series. Series lamp connection means both lamps on a two-lamp circuit share the same current path, so if one lamp fails the pair goes out. Order the wattage version that matches the lamps you are running: the CENTIUM ICN2S is offered in 86W and 110W.
3) Will this Philips ballast fit in my existing fluorescent fixture channel?
The housing measures 9.5 x 1.7 x 1.18 inches and is a metal SC-case ballast, which is the standard small-can shape that drops into most strip and troffer channels. Measure the channel opening against those three numbers before you commit, since older fixtures vary.
4) Can I use the CENTIUM ICN2S ballast in an outdoor or unheated parking garage fixture?
Yes, it is rated for outdoor use, with a maximum case temperature of 70 C. Outdoor use still assumes the fixture itself is a wet or damp location enclosure protecting the ballast; the rating covers the ballast, not the housing it goes in.
5) Does this Philips ballast support tandem or remote wiring across multiple fixtures?
All three configurations are permitted: tandem wiring, through wiring, and remote wiring. That means you can run one ballast to lamps in an adjacent fixture, daisy-chain power through the ballast compartment, or mount the ballast away from the lamps, which is useful in tight cove and sign applications.
6) What wire do I land on the Philips CENTIUM ICN2S, and does it come with connectors?
Leads are 18 AWG solid wire with no terminals and no connector fitted, so you make up the joints with your own wire nuts or push connectors. Strip length is 0.50/0.375 mm as specified. Solid leads mean it is a straight nut-and-tape connection in the ballast channel, not a plug-in module.
7) Is the Philips CENTIUM ICN2S quiet enough for an office or classroom?
It carries an A sound rating, the quietest class for fluorescent ballasts, which is what you want over desks, in classrooms, libraries, and patient rooms. Total harmonic distortion is 10 percent, low enough for facilities with harmonic limits on lighting branch circuits.
8) What approvals does this Philips fluorescent ballast carry for a spec job?
The ballast holds a CSA certificate and meets FCC Non-Consumer EMC immunity. It is not UL Recognized, so if your specification calls specifically for a UL Recognized component, this one will not satisfy that line.
9) How is the CENTIUM ICN2S ballast packed for a bulk retrofit order?
Each ballast is packed individually, with 10 packs to an outer box. For a re-lamp and re-ballast across a floor, that means ordering in tens keeps you on full cases.
