Product Specs
- Country Of Origin:
- Canada
- Csa Cert :
- LR21001
- Ip Rating:
- IP54
- Panel:
- Included
- Product Height:
- 8
- Product Material:
- Mild Steel
- Product Weight:
- 8 lbs
- Product Width:
- 8
- Reach Compliant:
- Yes
- Rohs Compliant:
- Yes
- Standards:
- csa, ul, ce
- Type Rating:
- type-12, type-13
- Ul File :
- E65324
- Usmca Compliant:
- Yes
- Product Depth:
- 4
- Department:
- Electrical
- Product Group:
- Boxes & Enclosures
- Product Subgroup:
- Enclosures
- Product Type:
- Hinged-Cover Enclosure
Hammond Manufacturing 1414PHH4 – Frequently Asked Questions
1) What size enclosure is the Hammond 1414PHH4 and does it come with a back panel?
The 1414PHH4 is an 8 x 8 x 4 inch enclosure (8 height, 8 width, 4 depth) and a mounting panel is included, so you don't have to order one separately for mounting terminal blocks, relays or a small drive.
2) Is the Hammond 1414PHH4 enclosure rated for washdown or outdoor use?
No. The 1414PHH4 carries Type 12 and Type 13 ratings with an IP54 seal, which covers dust, falling dirt and dripping or splashing non-corrosive liquids and oils indoors. It is not a Type 4/4X washdown or outdoor rating, so for hosedown, rain or sleet exposure you want a Type 4 or 4X box instead.
3) Will the Hammond 1414PHH4 pass an electrical inspection on a UL and CSA job?
It is built to csa, ul and ce standards, with CSA certification LR21001 and UL file E65324 on record. Those file numbers are what an inspector or a submittal package asks for when the spec calls out a listed industrial enclosure.
4) Why choose a piano hinged enclosure over a screw cover box?
The hinge is the difference on service calls. The 1414PH style uses a continuous piano hinge on the door, so the cover swings open and stays attached, no loose cover and no handful of screws to keep track of while you're working in the box. A screw cover of the same size is cheaper to make but means pulling the lid off every time, which is why hinged boxes get specified where a tech has to open the enclosure routinely.
5) What material is the Hammond 1414PHH4 enclosure made from, and will it corrode?
Body and door are mild steel. Steel boxes are suited to dry indoor and industrial interiors; in damp, chemical or coastal environments the finish is the only thing standing between the shell and rust, so stainless or non-metallic is the better pick there. Shipping weight on the unit is 8 lbs, light enough for a one-person wall mount.
6) What is the exact part number to order for the Hammond 8 x 8 x 4 piano hinged enclosure?
Order manufacturer part number 1414PHH4. That single part number covers the complete 8 x 8 x 4 piano hinged enclosure with the panel included, so there is no separate panel or finish option to specify.
7) Is the Hammond 1414PHH4 RoHS and REACH compliant, and where is it made?
Yes to both, RoHS and REACH compliant, and it is made in Canada. It is also USMCA compliant, which matters for government and institutional buyers working to domestic-content or trade-preference rules.
