Precision Limit Switch, E47, Roller plunger, Screw Terminals, 15A at 250 Vac, 6A at 30 Vdc, 0.01 mm/s-1m/s, 1-SPDT (Form C)
Manufacturer Resources
Product Specs
- Actuator:
- Roller plunger
- Certifications:
- CSA Certified
- Connection:
- Screw terminal
- Contact Configuration:
- 1-SPDT (form C)
- Contact Rating:
- 15A at 250 Vac, 6A at 30 Vdc
- Enclosure Material:
- Mineral filled phenolic
- Environmental Rating:
- NEMA 1
- Maximum Ac Current:
- 15 A
- Maximum Dc Current:
- 15 A
- Operating Speed:
- 0.01 mm/s-1m/s
- Operating Temperature Max:
- 176 °F
- Operating Temperature Min:
- -13 °F
- Product Height:
- 1.82 in
- Product Length Depth:
- 1.94 in
- Product Weight:
- .1 lb
- Product Width:
- .69 in
- Series:
- E47
- Type:
- E47
- Product Group:
- Electrical
