Printable Markers
Notes
- Order Multiple 25 sheets.
- Order Multiple 25 cards.
Features
- Self-laminating markers have a clear overlay of polyester that protects the legend against oils, grease, water, chemicals, and foreign matter.
- 6 Mil Polyester (same material as WPR rolls. Test template included with each 25 pack.
- Markers feature a strong adhesive for maximum adhesion to the wire and are available in a variety of sizes, both as standard and specials.
Manufacturer Resources
Product Specs
- Inner Package:
- 25
- Marker Size W X L:
- 2 x 2.25
- Markers Per Sheet:
- 12
- Max Wire Diameter Inches:
- 15/32
- Order Multiple:
- 25
- Outer Package:
- 750
- Package Height:
- 10.5
- Package Length:
- 10.5
- Package Width:
- 7.5
- Paper Size W X L:
- 9 x 9
- Print Area W X L:
- 2 x 2.25
- Product Group:
- Cable Management & Identification
- Rohs Compliance:
- Yes
- T B Sold In Uom:
- Each
- T B Weight Per Uom:
- 2.86 lbs. per 100
- Department:
- Electrical
- Product Subgroup:
- Wire Markers & Labels
- Product Style:
- Typewriter Printable
- Product Type:
- Printer Label
Thomas & Betts WTW-2214 – Frequently Asked Questions
1) What is the largest wire diameter the Thomas & Betts WTW-2214 self-laminating marker will wrap?
The WTW-2214 marker handles wire up to 15/32 inch in diameter. The marker itself is 2 x 2.25 inches, with the printed legend occupying a 2 x 2.25 inch print area and the clear polyester tail wrapping around the conductor to laminate over the text. If your cable runs larger than 15/32 inch, you need a longer marker body so the clear overlay can still make a full wrap.
2) How many wire markers do I get per sheet, and how do these have to be ordered?
Each sheet of WTW-2214 carries 12 markers, and the markers ship in an inner pack of 25 sheets. Orders go in multiples of 25, so the smallest quantity is a 25 sheet pack (300 markers), with a full outer carton at 750. A test template is included with each 25 pack so you can dial in your printer alignment before running the real sheets.
3) Will the WTW-2214 marker sheets feed through my printer?
The sheets measure 9 x 9 inches, which is not letter size, so check your printer's tray and manual feed tolerance before you commit to a run. The style is typewriter printable, meaning the stock is built for impact and flat-path printing rather than a tight-radius roller path. Each 25 sheet pack includes a test template so you can prove the feed and the print registration on one sheet first.
4) Will these wire markers hold up in a mechanical room with oil and washdown?
That is what the self-laminating construction is for. The legend is printed on the paper-backed portion, then a clear 6 mil polyester overlay wraps over the top of it, shielding the text from oils, grease, water, chemicals, and airborne debris. The adhesive is a strong one intended for maximum adhesion to the wire jacket. It is the same 6 mil polyester used in the WPR rolls.
5) Should I use sheet markers like the WTW-2214 or a wire marker book or roll?
Sheets make sense when you are labeling a panel or a pull box and you want to lay out all the circuit legends at once and print them in one pass, 12 markers to a sheet. A roll or book is the better call when you are marking in the field, one conductor at a time, and do not have a printer at hand. The WTW-2214 uses the same 6 mil polyester as the WPR rolls, so the finished label on the wire behaves the same way either route.
6) Are the Thomas & Betts WTW-2214 markers RoHS compliant for a spec job?
Yes, the WTW-2214 printable wire markers are RoHS compliant, which is the line most institutional and government submittals are looking for on consumables like this.
7) How much do these wire markers weigh for a shipment or a kit build?
Thomas & Betts rates the WTW-2214 at 2.86 lbs per 100, sold by the each. The shipping carton runs 10.5 by 10.5 by 7.5 inches.
