RAB 13W U-Bend T8 LED Tube – Hybrid Type A+B, Single/Double Ended, 8xx CCT Options

RAB 13W U-Bend T8 LED Tube - Hybrid Type A+B Single/Double Ended with DLC 5.1 Certification

(No reviews yet) Write a Review

Model: T8-13-U6G-835-SD-HYB

In Stock (leaves warehouse same day if ordered before 3pm ET)

$35.63
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

RAB 13W U-Bend T8 LED Tube - Hybrid Type A+B Single/Double Ended with DLC 5.1 Certification

Professional LED lighting solution with versatile installation options

The RAB 13W U-Bend T8 LED Tube delivers professional-grade lighting performance with hybrid Type A+B compatibility, allowing installation with existing ballasts or direct line voltage operation. This single/double ended LED tube provides 50,000 hours of reliable service with DLC 5.1 certification for energy efficiency programs and utility rebates.

Professional Features & Benefits

  • 13W Energy Efficient Operation: Reduces energy consumption while maintaining optimal light output for cost-effective operation
  • Hybrid Type A+B Compatibility: Works with existing ballasts (Type A) or direct 120-277V connection (Type B) for maximum installation flexibility
  • 50,000 Hour Rated Life: Extended operational lifespan reduces maintenance costs and replacement frequency
  • DLC 5.1 Certification: Qualifies for utility rebates and energy efficiency programs with verified performance standards
  • Single/Double Ended Design: Accommodates various fixture configurations and wiring requirements
  • U-Bend Configuration: Compact design fits standard T8 fixtures while providing uniform light distribution
  • White Finish: Professional appearance integrates seamlessly with existing lighting systems

Technical Specifications

  • Dlc Type: DLC
  • Dlc Version: 5.1
  • Input Voltage: Type A: Ballast dependent Type B: 120-277V
  • Input Watts: 13
  • Lamp Hours: 50000
  • Lamp Info: LED
  • Product Finish: White
  • Product Height: 1.18
  • Product Length: 23.23
  • Product Watts: 13
  • Product Weight: 0.49
  • Product Width: 7.09

Professional Applications

  • Commercial Office Buildings
  • Retail Establishments
  • Educational Facilities
  • Healthcare Facilities
  • Industrial Workspaces
  • Warehouse and Storage Areas
  • Government Buildings

Why Choose RAB Quality?

RAB delivers reliable LED lighting solutions with DLC 5.1 certification ensuring verified performance and energy efficiency. The 50,000-hour rated life and professional white finish provide long-term value and consistent performance for demanding commercial and industrial applications.

Manufacturer Resources

Product Specs

Dlc Type:
DLC
Dlc Version:
5.1
Input Voltage:
Type A: Ballast dependent Type B: 120-277V
Input Watts:
13
Lamp Hours:
50000
Product Finish:
White
Product Height:
1.18
Product Length:
23.23
Product Weight:
0.49
Product Width:
7.09
Department:
Electrical
Product Group:
Linear Tubes
Light Technology:
LED
Product Wattage:
13

RAB T8-13-U6G-835-SD-HYB – Frequently Asked Questions

1) Will the RAB 13W U-bend LED tube work in my existing fixture without rewiring it?
Yes. The RAB T8-13-U6G U-bend is a hybrid Type A+B lamp, so it runs off an existing fluorescent ballast (Type A) or off line voltage at 120-277V once the ballast is bypassed (Type B). That means a maintenance crew can drop it in today on the ballast, and when that ballast eventually fails, bypass it and keep the same lamp instead of buying a different one.
2) What size fixture does the RAB 13W U-bend T8 LED tube fit?
The U-bend measures 23.23 by 7.09 by 1.18 inches, which is the standard 2-foot U-shaped lamp footprint used in 2x2 troffers. The 7.09 inch dimension is the leg spacing, so confirm your existing lamp is the same U-bend leg spacing (6 inch nominal, as the U6G designation indicates) rather than the narrower 1-5/8 inch spacing before ordering.
3) Does the RAB U-bend T8 LED tube qualify for a utility rebate?
It is listed to DLC version 5.1, which is the qualification most commercial utility rebate programs reference for linear LED lamps. For an institutional or municipal retrofit, that DLC 5.1 listing is what the program administrator asks for when you submit the lamp for pre-approval.
4) Is single-ended or double-ended wiring required for the RAB 13W hybrid U-bend tube?
Either works. The lamp is built single/double ended, so when you bypass the ballast for Type B operation you can feed line and neutral to one end or split them across the two ends, whichever the fixture's existing sockets and wiring make easier. Single-ended bypass usually means changing only one lampholder; double-ended lets you keep shunted sockets on both ends.
5) What color temperature should I order for the RAB 13W U-bend LED tube?
Four color temperatures are offered, all at 80 CRI: 3000K, 3500K, 4000K, and 5000K. Warmer 3000K and 3500K suit hospitality and healthcare patient areas; 4000K is the usual neutral pick for offices, schools, and retail; 5000K reads cool and crisp for warehouse and industrial space. If you are relamping only part of a building, match the CCT already installed, because a 4000K and a 5000K lamp in adjacent troffers will look obviously mismatched.
6) How long will these RAB U-bend LED tubes last before a relamp?
Rated life is 50,000 hours. On a school or office running roughly 3,000 hours a year that is over 16 years of service; on a 24/7 hospital corridor at about 8,760 hours a year it works out closer to 5-1/2 years. For a facilities budget, that is the number to plan the next relamp cycle against.
7) Can I run the RAB 13W hybrid U-bend tube on 277 volts?
Yes, in Type B mode the lamp accepts anything from 120 to 277 volts, so the same part number works on 120V single-phase circuits in a small building and on 277V lighting branch circuits in a commercial or industrial panel. In Type A mode the input is whatever the existing ballast delivers, so the ballast's own voltage rating governs.
8) Are all four color temperatures of the RAB U-bend tube the same wattage and length?
Yes. The 3000K, 3500K, 4000K, and 5000K versions share the same 13 watt draw, the same 23.23 inch length, and the same hybrid single/double ended construction. Only the CCT changes, so you can mix them across a building without any change to the fixture wiring or the circuit load calculation.
9) What is the exact RAB part number for a 4000K U-bend LED tube?
T8-13-U6G-840-SD-HYB is the 4000K, 80 CRI version. The family runs T8-13-U6G-830-SD-HYB for 3000K, -835- for 3500K, -840- for 4000K, and -850- for 5000K. The 830/835/840/850 block is CRI and color temperature, SD is single/double ended, and HYB is the hybrid Type A+B driver.
10) How much does a RAB 13W U-bend LED tube weigh for a ceiling relamp?
Each lamp weighs 0.49 pounds, well under the fluorescent U-tube it replaces, so a two-lamp 2x2 troffer carries under a pound of lamp. There is no glass to break in handling, which matters when a crew is relamping hundreds of ceiling fixtures off a lift.
