RAB SHARK2 Series 2-Foot Linear Washdown LED Fixture with 0-10V Dimming and Marine Listing

RAB SHARK2 Series 2-Foot Linear Washdown LED Fixture

Professional washdown lighting solution for demanding environments

The RAB SHARK2 Series delivers reliable linear LED lighting designed for washdown applications requiring superior protection and performance. This 2-foot fixture features 0-10V dimming capability, marine listing certification, and operates across 120-277V systems. Built with IK09 impact-resistant polycarbonate enclosure and IP66 ingress protection, it provides dependable illumination in challenging conditions while maintaining NSF certification for food service environments.

Professional Features & Benefits

• IP66 Ingress Protection: Complete dust and water protection ensures reliable operation in washdown and wet environments.
• Marine Listed Certification: Meets stringent marine standards for corrosion resistance and durability in harsh coastal conditions.
• 0-10V Dimming Control: Provides precise light level adjustment for energy savings and application-specific lighting requirements.
• IK09 Impact Resistance: Polycarbonate enclosure with 5VA flame rating withstands mechanical impact and maintains safety standards.
• NSF Certification: Approved for food service applications ensuring compliance with public health and safety requirements.
• 100,000 Hour LED Life: Long-life surface-mount LEDs reduce maintenance costs and provide consistent performance over extended periods.
• Wide Voltage Compatibility: 120-277V operation accommodates various electrical systems with constant current Class 2 driver technology.

Technical Specifications

• Cold Weather Starting: The minimum starting temperature is -30°C (-22°F)
• Color Accuracy: 84 CRI
• Color Uniformity: RAB's range of Correlated Color Temperature follows the guidelines of the American National Standar
• Dlc Listed: This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that
• Dlc Version: 5.1
• Driver: Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.20A, 208V: 0.12A, 240V: 0.11A, 277V: 0.10A
• Driver Info: Constant Current
• Enclosure: IK09 impact-resistant polycarbonate with 5VA flame rating*
• Gaskets: EVA
• Iesna Lm 79 Lm 80 Testing: RAB LED luminaires and LED components have been tested by an independent laboratory in accordance w
• Ip Rating: Ingress protection rating of IP66 for dust and water
• Lamp Hours: 100000
• Lamp Info: LED
• Leds: Long-life, high-efficacy, surface-mount LEDs
• Lens: Textured, diffuse polycarbonate lens for low glare and maximum protection
• Maximum Ambient Temperature: Suitable for use in up to 40°C (104°F)
• Mounting Method: Quick-mount, surface, stainless steel spring clips and V-Hook with bracket screws are supplied. 3 a
• Nema Rating: 4X, protected against corrosion
• Nsf: NSF Certified by Public Health and Safety
• Product Details: Constant Current
• Product Length: 2ft
• Reflector: Specular polycarbonate
• Surge Protection: 4kV
• Ul 94: 5VA flame classification
• f 120v: 0.20A
• f 208v: 0.12A
• f 240v: 0.11A
• f 277v: 0.10A

Installation & Operation

1. Mount the unit in a suitable location with appropriate clearance and access for connections and service.
2. Connect utility and load conductors following applicable guidelines and the manufacturer's instructions.
3. Wire generator or power input according to the provided voltage/phase specifications and compatible capacity.
4. Configure any available load management or control features as supported by the provided specifications.
5. Test automatic transfer or operational functionality and verify proper performance before placing into service.
6. Complete final inspection and follow ongoing maintenance practices appropriate to the product category.

Professional Applications

• Food Processing Facilities
• Commercial Kitchens
• Marine Environments
• Washdown Areas
• Industrial Facilities
• Healthcare Facilities
• Pharmaceutical Manufacturing

Why Choose RAB Quality?

RAB delivers proven reliability through rigorous testing standards including IESNA LM-79 and LM-80 compliance, DLC 5.1 listing, and comprehensive certifications. The SHARK2 Series combines marine-grade durability with NSF food safety approval, backed by 100,000-hour LED life and 4kV surge protection for dependable long-term performance in demanding applications.
