Rittal 1574000-2 KX Small Enclosure, Carbon Steel

The Rittal KX Small Enclosure is a compact carbon steel housing engineered for fast assembly and flexible lock selection, available in two footprints — 200 × 300 × 155 mm and 380 × 380 × 210 mm — to match the space and equipment on hand. Rated IP 66 to EN/IEC 60 529 and carrying NEMA 1, 3R, 4, 12 and UL 50E Type 1, 3R, 4, 12 ratings, this E-Box KX enclosure protects electrical components in demanding indoor and outdoor environments. Every unit ships complete with a mounting plate sized to the enclosure, a cam lock, a 180° hinge, and a door for fast, code-compliant installation.

Key Features

  • Two Size Options: Choose 200 × 300 × 155 mm or 380 × 380 × 210 mm (W × H × D) to match the application.
  • Durable Carbon Steel Construction: 1.25 mm carbon steel on both the enclosure and door for a rugged, long-lasting housing.
  • Flexible Cam Lock System: Fitted with a cam lock featuring a 3 mm double-bit insert, giving installers flexibility when selecting lock systems.
  • 180° Hinge Door: The housing's door and 180° hinge design allow a wide swing for easy access during installation and service.
  • IP 66 Ingress Protection: Protection category IP 66 to both EN 60 529 and IEC 60 529 guards internal components against dust and water.
  • NEMA and UL 50E Rated: Rated NEMA 1, 3R, 4, 12 and UL 50E Type 1, 3R, 4, 12 for suitability across indoor, outdoor, and washdown environments.
  • Impact Resistance: IK08 impact protection rating adds mechanical durability to the enclosure.
  • RAL 7035 Finish: Supplied in RAL 7035 color for a consistent, professional appearance.

Certifications & Compliance

  • IP 66 to EN/IEC 60 529
  • NEMA 1, 3R, 4, 12
  • UL 50E Type 1, 3R, 4, 12
  • IK08 Impact Rating

Technical Specifications

  • Base Material: Carbon Steel
  • Material Thickness – Enclosure & Door: 1.25 mm
  • Lock: Cam lock, 3 mm double-bit insert
  • Protection Category IP (EN/IEC 60 529): IP 66
  • Protection Category NEMA: NEMA 1, 3R, 4, 12
  • Type Rating per UL 50E: Type 1, 3R, 4, 12
  • IK Code: IK08
  • Color: RAL 7035
  • Available Sizes (W × H × D): 200 × 300 × 155 mm; 380 × 380 × 210 mm

Typical Applications

  • Industrial and Commercial Electrical Installations
  • Control Panel and Component Housing
  • Outdoor and Wet-Location Equipment Enclosures
  • Panelboard and Switchgear Protection
  • Renovation and New Construction Projects

Why Rittal?

Rittal builds the KX small enclosure from durable 1.25 mm carbon steel with an IP 66, NEMA 1, 3R, 4, 12, and UL 50E Type 1, 3R, 4, 12 rating, giving electrical professionals a housing built for demanding environments in either the 200 × 300 × 155 mm or 380 × 380 × 210 mm size. The included mounting plate, flexible cam lock, and 180° hinge door make assembly straightforward without sacrificing code-compliant protection.

Manufacturer Resources

Rittal Product Catalog

Product Specs

Product Type:
Enclosure
Product Material:
Carbon Steel
Product Color:
RAL 7035
Department:
Electrical
Product Group:
Boxes & Enclosures
Product Size:
200 × 300 × 155 mm - 380 × 380 × 210 mm
Standards:
NEMA 1, 3R, 4, 12
Listing:
UL 50E
Product Subgroup:
Enclosures

Rittal 1576000 – Frequently Asked Questions

1) Can the Rittal KX small enclosure be mounted outdoors in a wet location?
Yes. The KX small enclosure is rated IP 66 to EN/IEC 60 529 and carries NEMA 1, 3R, 4, 12 with UL 50E Type 1, 3R, 4, 12. The Type 4 and 3R portions cover rain, sleet, hosedown and splashing water, so it works outdoors and in washdown areas as well as general indoor and dusty locations. Carbon steel body in RAL 7035.
2) What sizes does the Rittal KX E-Box come in, and which part number is which?
Two footprints. The 200 x 300 x 155 mm (W x H x D) box is Rittal part 1574000, and the 380 x 380 x 210 mm box is part 1576000. Pick by the component footprint and the depth your gear and wiring bends need, since 155 mm of depth is tight for anything deep-mounted.
3) Does the Rittal KX enclosure include a mounting plate, or do I have to buy it separately?
A mounting plate sized to the enclosure is included, along with the door, a 180 degree hinge, and a cam lock. So for a basic panel build you only need to add your own gland plate cutouts, fittings, and components.
4) What kind of lock is on the Rittal KX small enclosure, and can I key it to match my other panels?
It ships with a cam lock using a 3 mm double-bit insert, which is the common European panel key standard. The insert design is what lets you swap in a different lock system if your facility standardizes on something else.
5) How thick is the steel on the Rittal KX enclosure, and will it hold up to knocks in a plant?
Both the enclosure body and the door are 1.25 mm carbon steel, and the unit carries an IK08 impact rating. That is adequate for industrial walls and machine-side mounting where carts and tools make contact.
6) Is a carbon steel enclosure like the Rittal KX the right choice, or should I use stainless or non-metallic?
Carbon steel with the RAL 7035 painted finish suits indoor industrial and general outdoor use, and the KX is rated NEMA 4 and 12 for that. Where you have chemical washdown, salt air, or food-processing sanitation requirements, a painted carbon steel shell is the wrong pick and you want a stainless or non-metallic enclosure instead.
7) What else does ZenSupply carry if I need a NEMA 3R enclosure instead of the Rittal KX?
Two other options we hold are the ABB Q-Line NEMA 3R 225A Enclosure, which is a rainproof load-center style housing, and the ABB Formula A2ENCL250 Series surface-mount electrical enclosure. The Rittal KX differs in that it is a general-purpose component box with an included mounting plate and a broader NEMA 1, 3R, 4, 12 rating rather than a breaker-specific housing.
