Rockwood RM850 - 1-1/2" Height Floor Mounted Door Stop, Gray Bumper

The RM850 stands 1-1/2 inches high with a 1-1/4 inch base, so it catches the bottom rail of a door with roughly that much clearance under it. If you have a thick undercut for carpet or an air transfer gap, a low dome like this can pass under the door instead of stopping it, and you want a gooseneck style that reaches up to the door face instead.

Two fastener sets are supplied for the RM850: a #12 x 1-1/2 inch wood screw with a plastic anchor for wood subfloor, and a #12-24 x 1 inch flat head machine screw with anchor for masonry or concrete. A #8 x 1-1/4 inch truss head sheet metal screw and plastic toggle are also included. Mounting is concealed, so no exposed screw heads sit on top of the stop once it is set.

A low dome like the RM850 sits close to the floor and works when the door bottom is near the finish floor, which keeps it out of the traffic path and off the mop line. A gooseneck rises up to meet the door face and is what you want when the door has a large undercut or you need to hold the door open, since gooseneck models are commonly holders. ZenSupply carries both: the Orca 22HD Series gooseneck is listed as a door holder, and the Orca 23LP Series is a low rise dome stop.

For a like-for-like brass floor dome, the Ives FS13 and FS17 are both listed heavy duty brass dome stops, and the FS13 takes a replaceable rubber bumper if you expect to service the tip rather than swap the whole stop. Where you need something taller than the RM850's 1-1/2 inch dome, the Deltana UFBD3505 is a 3-1/2 inch round universal floor bumper. Ives also lists an FS18S/FS18L security floor stop for openings where the stop itself gets attacked.

No. The RM850 is a stop only, so it takes the impact and limits the door swing but releases as soon as you let go. To park a door open you need a holder: ZenSupply lists the Ives FS40/FS41/FS42/FS43 automatic floor stop and holder with adjustable door-to-floor clearance, the Orca 22HD gooseneck listed as a door holder, and the SOSS MDH magnetic door holder and stop at 3-5/16 x 1-3/4 inches.

The Ives FS13 is the nearest match. Both are floor-mounted stops with a low dome or flat-top profile and a rubber bumper, and the FS13 is a heavy-duty brass floor dome stop with a replaceable rubber bumper. The RM850 stands 1-1/2 inches tall on a 1-1/4 inch base, so it sits in the same low-rise range. If the bumper is the wear item on your doors, the FS13 lets you swap the rubber rather than the whole stop; the RM850 is ordered in 613 oil rubbed bronze or 630 satin stainless steel.

Step up to a gooseneck or tall riser stop. The Orca Hardware 22HD Series is a goose neck floor stop with a black tip built for 1-3/8 inch or 1-3/4 inch doors and functions as a door holder, and the Emtek 2253 Goose Style Door Stop and Delaney Gooseneck Floor Door Stop are the same tall-riser idea. A gooseneck reaches up the door face and catches it higher, where a 1-1/2 inch high stop like the RM850 only contacts the very bottom edge.

Commercial. The RM850 is built on a brass and stainless steel base with a back plate behind the mounting to keep the fastener from tearing out and damaging the substrate, which is what separates it from light residential dome stops. It is the kind of stop specified for office, school, and multi-family corridors.

Two: 613 oil rubbed bronze and 630 satin stainless steel. If you are matching existing hardware across a building, 630 is the usual pairing with satin stainless levers and hinges, and 613 with dark bronze trim. The bumper itself is gray on the standard RM850; Rockwood catalogs a black bumper version as the RM850BB.

The gray bumper is the standard build on the RM850. Rockwood assigns the black bumper version its own part number, RM850BB, with the same short flat top profile, same 1-1/4 inch base, same 1-1/2 inch projection, and the same fastener pack. Ordering the black tip means ordering the BB part, not adding an option to the gray one.

The RM850 has a 1-1/4 inch diameter base, so it covers a single anchor hole roughly centered under it and nothing wider. If the old stop had a larger footprint or a two-screw pattern, you will see the old holes. In that case a bigger base helps: the Deltana UFBD3505 is a 3-1/2 inch round decorative floor bumper and the UFBP4505 is a 1-5/8 inch pattern cap bumper, both solid brass.

Not handed. The RM850 is a symmetrical short flat top dome that mounts to the floor, so the same part serves left hand and right hand openings, in-swing or out-swing. Position is what matters: locate it under the door leaf at the swing angle you want to limit, not at a fixed dimension.

They are both 1-1/2 inch floor bumpers, but they are not the same part. The Deltana UFB4505 is a round universal floor door bumper in solid brass from the UFB Series. The RM850 is a commercial floor stop with concealed mounting and a back plate that prevents damage to the wall, supplied with a #8 x 1-1/4 inch TH SMS fastener and a plastic toggle. If the spec calls for a commercial stop with concealed fasteners, the two are not interchangeable on that basis.

Several dome stops cover the same low-rise position. The Orca Hardware 23LP Series is a low rise dome floor stop with a gray tip and carries a door stop function, the Emtek 2251 is a Half Dome Door Stop, and the Delaney Dome Door Stop is a dome series stop. The RM850 uses a short flat top on a 1-1/4 inch base with a 1-1/2 inch projection, so a dome takes the same footprint with a rounded cap instead.

Look at the Ives FS18S/FS18L Security Floor Stop, a heavy-duty security floor stop offered in short and long versions. It is built for openings where a standard stop can be attacked or torn out. The RM850 is a commercial floor stop with concealed mounting, which resists tampering at the fastener but is a general commercial part rather than a security-specific one.

Not dimensionally. The Emtek 2254 Floor Door Bumper measures 1-3/8 by 1-1/4 inches, and the Emtek 2257 is a 1-1/2 inch cylindrical floor bumper. The RM850 measures 1-1/4 by 1-1/2 inches with a 1-1/2 inch projection off the floor. If you are replacing an existing stop and the door has to clear the same height at the same swing point, check the projection before swapping - the 2254 sits lower than the RM850.

Indirectly, and that is the point of a floor stop. The RM850 arrests the door before the lever or the door face reaches the wall, and it carries a back plate under the mount so the stop itself does not chew up the substrate it is anchored to. Set it so the door stops short of the wall by a comfortable margin, allowing for the lever projection on the push side.

Both, depending on finish. The base materials are brass and stainless steel, which is why it is offered in 613 oil rubbed bronze and 630 satin stainless steel. For wet or corrosive areas, a washdown kitchen or a pool corridor, the 630 stainless finish is the one to spec.

Deltana carries dressier caps in the same floor-bumper family. The UFBD3505 is a 3-1/2 inch round universal floor bumper described as decorative in solid brass, the UFBP4505 is a 1-5/8 inch round universal floor door bumper with a pattern cap in solid brass, and the UFBS138 is a 1-3/8 inch square universal floor door bumper in solid brass if you want a squared footprint. The RM850 is a short flat top commercial stop finished in 613 oil rubbed bronze or 630 satin stainless steel.

Both Ives parts are heavy-duty brass floor dome stops. The FS13 is described with a replaceable rubber bumper, while the FS17 is described with a rubber bumper. For a fleet of doors where the tips take repeated impact, the replaceable-bumper version keeps the base in the floor on service calls. The RM850 comes with a gray bumper as standard and a black bumper on the RM850BB.
