ROFU 10320HD
The model 10320HD PCB include the PC board
Manufacturer Resources
Product Specs
- Product Group:
- Electronic Access Controls
- Product Subgroup:
- Parts and Accessories
- Product Type:
- Door Coordinators
- Subcategory:
- Door Cord
- Commercial/Residential:
- Commercial
- Product Category:
- Door Controls
- Department:
- Door Hardware
ROFU 10320HD US28 – Frequently Asked Questions
1) What is a ROFU 10320HD door cord used for on an access-controlled opening?
A door cord carries low-voltage wiring from the frame across the hinge gap into the door leaf, so power and signal reach hardware mounted in the door itself: electric strikes and locks, request-to-exit devices, contacts. The 10320HD is the heavy duty stainless steel version, built for commercial openings, and it includes the PC board.
2) Does the ROFU 10320HD come with the PC board, or is that ordered separately?
The PC board is included with the 10320HD. That is what the HD model number covers, so there is no separate board to add to the order.
3) What finishes does the ROFU 10320HD door cord come in?
Two finishes: Satin Aluminum (US28) and Dark Anodized Bronze (US40). Since the cord sits on the hinge edge and is visible when the door swings, most people match it to the frame or the door closer rather than the lockset.
4) Is the ROFU 10320HD rated for commercial door traffic or is it a residential part?
Commercial. The 10320HD is a heavy duty stainless steel cord, which is the spec you want on an opening that cycles all day, where a light-gauge cord is the part that fatigues and breaks first at the hinge.
5) Should I use a door cord like the ROFU 10320HD or an electric hinge to get power into the door?
Both do the same job, and the choice is about the door. A surface-mounted cord such as the 10320HD installs on an existing opening with no door or frame prep, which is why it's the usual retrofit when you're adding an electric lock to doors already hung. An electric power transfer hinge or an electric door loop hides the wiring but needs the hinge replaced or the edge mortised, so it is a new-construction or full-rework choice. If the opening is finished and you don't want to pull the door, the cord is the one that goes in.
