ROFU 3400
Electric Strike Solenoid
Technical Specifications:
- Rated for continuous for duty, VDC only
- Specify RH solenoids for models 3401, 3430LH, 3440LH, 3460B/RH and 3470B/RH
- Specify LH solenoids for models 3430RH, 3440RH, 3460B/LH and 3470B/LH
Manufacturer Resources
Product Specs
- Product Group:
- Electronic Access Controls
- Product Subgroup:
- Sensors, Switches, Relays and Timers
- Product Type:
- Electric Strike Parts and Accessories
- Subcategory:
- Electric Strike Parts and Accessories
- Commercial/Residential:
- Commercial
- Electronic:
- Yes
- Product Category:
- Electronic Access Controls
- Department:
- Door Hardware
ROFU 3400-09 RH – Frequently Asked Questions
1) Which handing solenoid do I order for a ROFU 3440RH electric strike?
For a 3440RH strike you order the left hand solenoid. ROFU reverses the handing call-out on the replacement solenoid: LH solenoids go into models 3430RH, 3440RH, 3460B/LH and 3470B/LH, while RH solenoids go into 3401, 3430LH, 3440LH, 3460B/RH and 3470B/RH. Ordering by the strike's handing label instead of the solenoid's will get you the wrong part.
2) My ROFU electric strike won't pull in anymore - do I replace the solenoid or the whole strike body?
If the strike body, keeper and faceplate are sound and only the electrical actuation has failed, the ROFU 3400 solenoid is the replacement coil for ROFU strikes and is rated for continuous duty on VDC only, ordered by handing and by 12 VDC or 24 VDC. If the body itself is damaged or you want to change fail safe/fail secure behavior, you are into a complete strike instead - the Adams Rite 7400A Ultraline electric strike body kit is a full body kit with field selectable fail safe/fail secure operation, which is a strike replacement rather than a coil swap.
3) Can I use a ROFU 3400 solenoid in a Trine 4800 or 4850 series strike?
Plan on it being brand specific. The ROFU 3400 solenoid is specified by ROFU strike model - right hand solenoids for models 3401, 3430LH, 3440LH, 3460B/RH and 3470B/RH, and left hand solenoids for 3430RH, 3440RH, 3460B/LH and 3470B/LH. Trine 4800 and 4850 series openings are served by their own parts, such as the 4800-AK accessories kit and the 4850-ITL installation tool for 4850 series strikes. Match the solenoid to the ROFU model number stamped on the strike you are repairing.
4) What does continuous duty mean for a ROFU 3400 electric strike solenoid on a door held unlocked all day?
Continuous duty means the coil can stay energized indefinitely without overheating, so it suits a fail secure opening that is signaled unlocked for long periods, like a lobby door on a daytime schedule. It is DC only, so it has to be fed from a filtered DC supply at 12 or 24 volts.
5) I want to change a ROFU strike from 12 volt to 24 volt. Can I just swap the solenoid?
Voltage on these strikes is set by the coil, and the 3400 solenoid is offered in both 12 VDC and 24 VDC, so converting is a matter of fitting the coil that matches your power supply. Keep the handing the same as the original solenoid when you order.
6) Is the ROFU 3400 solenoid the same kind of part as a Trine 4800-AK accessories kit?
No. The ROFU 3400 is the electric solenoid itself - the coil that actuates a ROFU strike, supplied in left hand or right hand and in 12 VDC or 24 VDC. The Trine 4800-AK is an accessories kit for the Trine 4800 series, and items like the Trine 4800-SS 1/8 inch spacer plate and the Trine 4850-SS 1/4 inch spacer plate are mounting shims for that frame prep. Those address fit in the jamb; the 3400 addresses electrical operation.
7) Is the ROFU 3400 solenoid a commercial-grade part?
Yes, it is a commercial door hardware item, meant for ROFU electric strikes in access controlled openings rather than residential use.
