Sargent 25-P3A 1-3/4" Offset Bracket for Auxiliary Stop/Holder Parallel Arm Door Closer

Professional Door Closer Mounting Solution

The Sargent 25-P3A is a precision-engineered 1-3/4" offset bracket designed specifically for auxiliary stop/holder parallel arm installations with Sargent 351, 281, and 1431 Series door closers. This heavy-duty, commercial-grade bracket provides extended clearance for deep frame and narrow soffit conditions where standard brackets won't fit, ensuring proper door closer operation in challenging architectural configurations.

Professional Features & Benefits

  • Extended Offset Design: 1-3/4" offset provides necessary clearance for deep frame and narrow soffit applications where standard mounting won't accommodate proper installation.
  • Series Compatibility: Engineered for Sargent 351, 281, and 1431 Series door closers, ensuring precise fit and optimal performance across multiple product lines.
  • Heavy-Duty Construction: Commercial-grade materials provide exceptional durability for high-traffic environments including schools, healthcare facilities, and office buildings.
  • Non-Handed Design: Universal configuration works with both left- and right-hand door applications for installation flexibility and reduced inventory requirements.
  • Auxiliary Stop/Holder Ready: Specifically designed to work seamlessly with parallel arm door closer setups using surface-mounted stop or holder components.
  • OEM Precision Fit: Maintains smooth door closer function and proper alignment while ensuring secure auxiliary stop/holder attachment for reliable operation.

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Installation & Operation

This mounting bracket is designed for use with compatible Sargent door closer systems. Refer to the parent device installation instructions and manufacturer documentation for proper integration. Ensure compatibility with existing hardware before installation.

Professional Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Retail Establishments
  • Industrial and Warehouse Facilities
  • Multi-Tenant Residential Properties
  • Government and Municipal Buildings

Why Choose Sargent Quality?

Sargent door closer accessories deliver professional-grade reliability with heavy-duty, commercial-grade materials engineered for demanding applications. OEM precision ensures perfect fit and maintains smooth door operation in high-traffic commercial environments where dependable performance is essential.

Product Specs

Grade:
Grade 1
Product Type:
Door Closer Arms
Duty Level:
Standard
Product Group:
Door Controls
Product Subgroup:
Parts and Accessories
Subcategory:
Parts and Accessories
Commercial/Residential:
Commercial
Product Category:
Door Controls
Department:
Door Hardware

Parts & Accessories

    Sargent 25P3A EAB – Frequently Asked Questions

    1) When do I need the 1-3/4 inch offset bracket instead of a standard parallel arm bracket?
    Reach for the offset version when the head frame is deep or the soffit is too narrow for the arm to clear on a flush-mounted bracket. The 1-3/4 inch offset pushes the arm shoe out far enough that the auxiliary stop or holder still functions through the full swing. If the soffit gives you normal clearance, the standard bracket that ships with the closer is what you want, and the offset just costs you projection into the opening.
    2) My Sargent closer is going on the pull side with no soffit to mount to. Is this the bracket I need?
    No, the 25-P3A is a parallel arm part and parallel arm mounting lives on the push side, fastened to the frame soffit. With no soffit to land on you are looking at top jamb mounting instead, which uses a plate such as the Sargent 351A top jamb mounting plate, or a regular arm mounted to the pull side of the door. The offset bracket only solves clearance problems on a parallel arm installation, not the absence of a mounting surface.
    3) What is the LCN equivalent of a Sargent 25-P3A offset bracket for a parallel arm closer?
    The Sargent 25-P3A is a 1-3/4 inch offset bracket for auxiliary stop/holder parallel arm installations on Sargent 351, 281 and 1431 Series closers. On the LCN side, the closest counterpart is the LCN 1260-3077 Regular Arm with Parallel Arm Bracket, which supplies the parallel arm bracket as part of a 1260 Series arm assembly rather than as a standalone offset shoe. The practical difference is scope: the 25-P3A is a bracket alone, added to a Sargent closer already carrying its arm, while the 1260-3077 arrives as arm plus bracket for a 1260 Series body.
    4) I need the door to hold open, not just stop. Is an offset bracket the right part?
    No. The Sargent 25-P3A is an offset bracket for an auxiliary stop/holder parallel arm setup, which uses a surface-mounted stop or holder component to arrest the door. If the requirement is an arm assembly with hold-open built into the arm itself, that is a different part: the LCN 1250-3049/PA Hold Open Arm Assembly with Parallel Arm Shoe is non-handed with an adjustable hold open, the LCN 4010-3049 Hold Open Arm carries an adjustable elbow function, and the Falcon SC70A-3049/PA Hold Open Arm ships with its PA bracket for SC70A Series closers. Match the arm to the closer series you have.
    5) What do I use instead of a 25-P3A if the closer is a Falcon SC60A?
    The 25-P3A offset bracket is engineered for Sargent 351, 281 and 1431 Series closers, so it is not the part for a Falcon body. For an SC60A Series closer needing a parallel arm with the door arrested at a set point, the Falcon SC60A-3049DS Hold-Open Dead Stop Parallel Arm Assembly is the series-matched assembly. It combines the parallel arm and the dead stop function in one part rather than adding a stop bracket to an existing arm.
    6) Do I need to order a left hand and a right hand version of the 25-P3A?
    No. The bracket is non-handed, so one part number covers both left and right hand openings. For a property manager stocking spares across a building, that means a single line item on the shelf rather than a handed pair.
    7) Is the Sargent 25-P3A rated for a high traffic commercial opening?
    It is a Grade 1 commercial part, which is the heaviest ANSI/BHMA duty tier and the one specified for school corridors, hospitals and other high cycle openings. Nothing about it is intended for residential use.
    8) Does the Sargent 25-P3A come with the closer or the stop/holder arm?
    Bracket only. Order the 351, 281 or 1431 Series closer and its auxiliary stop or holder parallel arm separately, then use the 25-P3A as the mounting piece between the arm shoe and the frame. If you are replacing a damaged bracket on an existing installation, that is the one part you need.
    9) Is a standard arm part like the LCN 4000T-3077T a substitute for the Sargent 25-P3A?
    They solve different problems. The LCN 4000T-3077T is a standard arm replacement component for the 4000T Series, and the Falcon 8230-3077PLCM is a standard arm with track for 8230 Series automatic door operators. The Sargent 25-P3A is not an arm at all: it is the 1-3/4 inch offset bracket that gives clearance for deep frame and narrow soffit conditions where a standard parallel arm mounting will not fit. If the arm itself is bent or worn, replace the arm; if the arm is sound but the soffit is too shallow to land the shoe, the offset bracket is the part.
    10) The door is center hung on a floor pivot. Does the 25-P3A work there?
    The 25-P3A is a surface parallel arm accessory, offsetting the stop/holder shoe 1-3/4 inches for deep frame and narrow soffit openings on Sargent 351, 281 and 1431 Series closers. A center hung door running on a floor pivot is a different mounting arrangement entirely, and the part that addresses it is the Falcon OHC100A-DP Center Hung Floor Pivot with End Load Arm for OHC100 Series closers. Confirm whether the opening is surface parallel arm or center hung before ordering either.
    11) What finishes does the Sargent 25-P3A bracket come in?
    Five sprayed enamel finishes: EAB sprayed brass, EN sprayed aluminum, EP sprayed bronze to match satin bronze, EB sprayed bronze to match dark satin bronze, and ED sprayed bronze to match dark statuary bronze. These are painted enamels meant to match the closer cover and arm, so pick the same code you specified on the closer rather than matching the lockset finish.
    12) Can I standardize the same offset bracket across all the Sargent closers in my building?
    Across openings running 351, 281 or 1431 Series closers on parallel arm with an auxiliary stop or holder, yes, one bracket covers all of them, and because it is non-handed you do not split the stock by hand of door. What you do split by is finish, so match the enamel code to the closers already installed.
    13) Do I have to order the offset bracket handed for left and right doors like I do some arms?
    No. The Sargent 25-P3A is non-handed, so one part number covers both left- and right-hand openings, which keeps a single line item on the shelf for a mixed building. Among comparable parallel arm parts, the LCN 1250-3049/PA hold open arm assembly is likewise described as a non-handed design. Ordering for the 25-P3A comes down to finish, offered in sprayed brass enamel, sprayed aluminum enamel, and sprayed bronze enamels to match satin bronze, dark satin bronze, and dark statuary bronze.
