Sargent 432RC Large Format Mortise Housing Installation Tool for Interchangeable Core Systems

Sargent 432RC Large Format Mortise Housing Installation Tool for Interchangeable Core Systems

(No reviews yet) Write a Review

Model: 432RC
From the Conventional Key System Collection

In Stock (leaves warehouse same day if ordered before 3pm ET)

$112.60
$101.76
Adding to cart… The item has been added
Free Shipping on orders over $199
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Sargent Large Format Mortise Housing Installation Tool for Interchangeable Core Systems

Professional Installation Tool for Large Format Mortise Cylinders

The Sargent Large Format Mortise Housing Installation Tool is specifically designed to assist in installing Sargent Large Format Interchangeable (Removable) Core mortise housings. This specialized tool simplifies the process of threading a cylinder body into a mortise lock and enables technicians to check cylinder function before installing the cylinder core, ensuring proper operation and reducing installation time.

Professional Features & Benefits

  • Large Format Compatibility: Specifically designed for Sargent Large Format Interchangeable (Removable) Core mortise housings for precise installation support.
  • Threading Assistance: Makes it easy to thread a cylinder body into a mortise lock, reducing installation effort and ensuring proper alignment.
  • Function Testing Capability: Allows technicians to check cylinder function in a lock before installing the cylinder core, preventing installation issues.
  • Professional Installation Support: Streamlines the mortise housing installation process for faster, more accurate results.
  • Specialized Design: Purpose-built tool engineered specifically for Sargent interchangeable core systems.
  • Quality Assurance: Enables pre-installation testing to verify proper cylinder operation before final assembly.

Technical Specifications

  • Refer to manufacturer documentation for complete technical specifications.

Installation & Operation

This installation tool is designed for use with compatible Sargent Large Format Interchangeable Core mortise systems. Refer to the parent device installation instructions and manufacturer documentation for proper integration. Ensure compatibility with existing hardware before installation.

Professional Applications

  • Commercial Locksmith Services
  • Security System Installation
  • Building Maintenance Operations
  • Educational Facility Hardware Service
  • Healthcare Institution Security Systems
  • Government Building Access Control
  • Multi-Tenant Property Management

Why Choose Sargent Quality?

Sargent installation tools deliver professional-grade reliability with specialized design engineered for demanding commercial applications where precise cylinder installation is essential. This purpose-built tool ensures proper mortise housing installation while enabling function verification before final assembly, reducing callbacks and ensuring dependable performance.

Product Specs

Product Type:
Tools
Product Group:
Mechanical Locks
Product Subgroup:
Parts and Accessories
Subcategory:
Parts and Accessories
Commercial/Residential:
Commercial
Collection:
Conventional Key System
Parts and Accessories Type:
Installation Accessories
Product Attribute:
Parts and Accessories
Product Model:
432RC
Product Category:
Mechanical Locks
Department:
Door Hardware

Sargent 432RC – Frequently Asked Questions

1) What does the Sargent 432RC installation tool actually do?
The 432RC is a locksmith's bench and field tool for Sargent Large Format Interchangeable (Removable) Core mortise housings. It grips the cylinder body so you can thread the housing into a mortise lock case by hand, and it lets you run the cylinder in the lock to confirm the cam is turning the lock correctly before the core ever goes in. It is not a part of the lock and nothing stays in the door.
2) Will the Sargent 432RC work on small format interchangeable core cylinders?
No. The 432RC is built for Sargent Large Format Interchangeable (Removable) Core mortise housings. Large format and small format (SFIC) housings differ in body diameter and core profile, so a large format tool will not engage an SFIC housing. If you are servicing SFIC, you need the small format equivalent, not this one.
3) Can I use the 432RC on a Sargent conventional (non-interchangeable core) mortise cylinder?
The 432RC is made for the removable core mortise housing, which is threaded into the lock without a core in place. A conventional mortise cylinder is a one piece unit with the plug already installed, so you thread it in by hand or with a standard cylinder wrench. The 432RC is the tool for the IC housing job specifically.
4) Why would a locksmith test the cylinder before dropping the core in?
Because a mortise housing threaded to the wrong depth turns the cam to the wrong position, and you find out only when the lock will not retract. The 432RC lets you rotate the housing in the installed lock and watch the lock respond, so you set thread depth and cam clock correctly first, then install the core. Catching it at that point saves pulling the trim back off after the core is seated.
5) Is the Sargent 432RC a consumable part or a reusable tool?
Reusable. It is a technician's tool, not hardware that installs in the opening, so one goes in the truck or the shop and services every large format IC mortise housing you set. Buyers standardizing a maintenance crew typically buy one per tech rather than one per door.
6) Is the 432RC meant for commercial door hardware or residential locks?
Commercial. Sargent large format IC mortise systems are what you find in schools, hospitals, government buildings and multi tenant properties, and the 432RC is a service tool for that class of hardware. Residential locksets do not use these housings.
