Schaub 5110 10" Center to Center Pub House Cabinet Pull
Style: Contemporary
Collection: Pub House
Function: Cabinet Pull
Projection: 1-1/4
Base Material: Solid Brass
CA Residents: Proposition 65 Warning
Base Dimensions: 1/2
Overall: 10-1/2
Center to Center: 10"
Thread / Screw Size: #8-32 x 1
Manufacturer Resources
Schaub Product Catalog
Product Specs
- Subcategory:
- Cabinet Pulls
- Collection:
- Pub House
- Product Type:
- Cabinet Pulls
- Product Group:
- Cabinet Hardware
- Product Subgroup:
- Cabinet Pulls
- MAP Policy:
- Yes
- Thread / Screw Size::
- #8-32 x 1
- Overall:
- 10-1/2"
- Product Function:
- Cabinet Pull
- Product Dimension:
- 1/2"
- Product Projection:
- 1-1/4"
- Product Style:
- Contemporary
- Product Material:
- Solid Brass
- Product Category:
- Cabinet Hardware
- (CTC) Center-to-Center:
- 10"
- Department:
- Door Hardware
Schaub 5110-SSB – Frequently Asked Questions
1) What screws come with the Schaub 5110 and will they work on a 3/4 inch drawer front?
Mounting is #8-32 machine screws, 1 inch long. That length suits a standard 3/4 inch cabinet door or drawer front with room for the post. On a thicker front, a slab door, or a drawer box with an applied face, you'll need longer #8-32 screws.
2) Is a 10 inch pull the right size for an appliance panel or a tall pantry door?
A 10 inch center-to-center pull like the 5110 is in appliance-pull territory, common on refrigerator and dishwasher panels, wide pot drawers, and full-height pantry doors. For standard 3 to 4 inch drawer fronts it's oversized; something like the Trimco 553 Series at 3 inch centers or the Omnia 1968/102 at 4 inch centers is the proportional choice there.
3) What is a close alternative to the Schaub 5110 Pub House pull if I want the same solid brass construction and 1-1/4 inch projection in a different series?
The Omnia 1970 modern cabinet pull is built from forged solid brass and carries a 1-1/4 inch projection, matching the Schaub 5110's solid brass base material and 1-1/4 inch projection. The Omnia 1969 and Omnia 1971 are also forged solid brass but project 1-3/16 inch, so they sit slightly closer to the door face. The Schaub 5110 stays in the Pub House collection with a contemporary styling, while the Omnia pulls are described as modern.
4) The Schaub 5110 is too long for my 12 inch drawer fronts. What shorter pulls should I look at?
The 5110 is a 10 inch center-to-center pull with a 10-1/2 inch overall length, which needs a wide drawer face. For short runs, the Deltana SBP35 modern square bar pull is a 3-1/2 inch pull in solid brass, the Trimco 553 series drawer pulls are 3 inch center-to-center, and the Trimco 562 series offers 3-1/2 inch, 4 inch, and 96mm center-to-center options. The Omnia 1968/102 is a forged solid brass pull with 4 inch center-to-center spacing if you want to stay in brass at a mid-length size.
5) What finishes does the Schaub 5110 come in, and can I match it across a whole kitchen?
Five finishes: Polished Chrome (PC), Brushed Nickel (BN), Matte Black (MB), Polished Nickel (PN), and Signature Satin Brass (SSB). Since the Pub House collection runs across multiple sizes, a property manager or builder standardizing a unit can keep one finish code on every door and drawer in the room.
6) Can I use an Orca Hardware cabinet knob in place of the Schaub 5110 pull?
They are different mounting types. The 5110 is a cabinet pull with two mounting posts on 10 inch centers using #8-32 x 1 screws. Orca Hardware's CK-15030 round knob and CK-16030 round ring knob are 1-1/4 inch diameter cabinet knobs, and the CK-17025 Blackcomb square knob is 25mm diameter - all single-point knobs, so they will not cover the existing two-hole boring from a 10 inch pull. Orca's CK-12001 is a T-pull bar in steel with a 2 inch bar width, a pull rather than a knob, but it is steel where the Schaub 5110 is solid brass.
7) For a high-traffic multi-family kitchen package, how does the Schaub 5110 compare to a steel pull like the Orca CK-12001?
The Schaub 5110 is solid brass with #8-32 x 1 mounting screws and a 1/2 inch base dimension, offered in Polished Chrome, Brushed Nickel, Matte Black, Polished Nickel, and Signature Satin Brass. The Orca Hardware CK-12001 is a steel T-pull bar with a 2 inch bar width in satin nickel. The Deltana SBP35 is another heavy-duty option in solid brass at 3-1/2 inch. Choosing between them comes down to whether you want brass or steel and the hole spacing already in your doors.
8) Does the Schaub 5110 need any backing or a special bore?
No special prep. It's a two-hole surface-mounted pull using #8-32 posts on 10 inch centers, so you drill two clearance holes through the front and thread the machine screws in from behind. Because the span is 10 inches, take care that both holes are level and dimensioned off a common reference line; an error at one end shows badly on a pull this long.
