Schlage Commercial 20-207 Sub-Assembled FSIC Core Only, S123 Keyway

Just the core. The 20-207 is a sub-assembled full size interchangeable core in the S123 keyway, and it ships with no keys and no pinning parts, so cut keys, pins and springs come from whoever maintains your key system. It is not a complete cylinder either, so there's no lockset, no IC housing and no mortise cylinder body in the box. The lock or cylinder it goes into has to already be prepped for a Schlage full size core.

No. It's a full size interchangeable core, what Schlage also calls large format, or LFIC. Small format cores are the figure-eight shaped ones used in SFIC housings, and the two form factors are not interchangeable in either direction. If the core you pulled out of the door is figure-eight shaped, the 20-207 is not the replacement for it.

Only if your system is already on the S123 keyway. The 20-207 is cut for Schlage S123, and a key on a different keyway section will not enter the plug, no matter how the core is pinned. Because the core arrives without keys or pinning parts, your locksmith or keying department pins it to your existing S123 bitting, and at that point it runs on the keys your staff already carry.

That's the whole point of an IC core. With the control key you pull the old core out of the housing and drop the new one in, with no disassembly of the lever or mortise lock and nothing coming off the door. A tenant turnover or a lost key becomes a one-minute job per opening instead of a rekey. One catch on the 20-207: it comes with no keys at all, control key included, so you need the control key from your existing S123 system to make the swap.

Yes, provided every opening is prepped for a Schlage full size core and the entire system runs on S123. Buying cores instead of complete locksets is how a master key system gets rolled out across a portfolio: the hardware stays on the door, the core carries the keying, and cylindrical levers, mortise locks and exit device cylinders all take the same core as long as each one is IC prepped. It's commercial-grade hardware, so it suits multi-family, institutional and MRO use rather than a residential Schlage lock, which is not built to take an interchangeable core.

No handing to specify. The core is non-handed, so the same part goes into a left or right hand opening, and it doesn't need changing if a door gets rehung the other way later. The only fit question that matters is whether the housing it's going into is prepped for a Schlage full size core.

626 satin chrome is the standard commercial finish on levers, exit devices and cylinders, so on a typical 626 opening the core face reads as part of the set. Worth knowing that only the exposed face of the core shows once it's seated in the housing, so a slight difference against 630 satin stainless is far less noticeable here than it would be on a rose or an escutcheon plate.
