Schlage Electronics 47260732-JDCO7 AD Series Exterior Baseplate Sub-Assembly for Cylindrical Lock with FSIC Corbin 7-Pin Prep

Schlage Electronics 47260732-JDCO7 AD Series Exterior Baseplate Sub-Assembly for Cylindrical Lock with FSIC Corbin 7-Pin Prep

(No reviews yet) Write a Review

Model: 47260732-JDCO7

In Stock (leaves warehouse same day if ordered before 3pm ET)

$1,305.00
$1,256.53
Adding to cart… The item has been added
Free Shipping on orders over $199.99
We price match and offer bulk discounts! Click Add to Quote. It's quick and easy.
✨
Earn points with this purchase! You can redeem points for giftcards, iPads, XBox's and more. View Rewards
Free Keying on all locks
You may also like

Schlage Electronics 47260732-JDCO7 AD Series Exterior Baseplate Sub-Assembly for Cylindrical Lock with FSIC Corbin 7-Pin Prep

The Schlage Electronics 47260732-JDCO7 is an AD Series Exterior Baseplate Sub-Assembly designed for cylindrical lock applications and configured with a Full-Size Interchangeable Core (FSIC) Corbin 7-Pin prep. Engineered as a precision installation accessory for the Schlage AD and CO Series platform, this sub-assembly provides the critical exterior baseplate interface needed for proper cylindrical lock function. Designed exclusively for commercial applications, this component ensures accurate alignment and secure integration within the AD Series lock chassis.

Key Features

  • AD and CO Series Compatibility: Specifically engineered for Schlage Electronics AD and CO Series locks, ensuring seamless integration with existing platform hardware.
  • Cylindrical Lock Configuration: Purpose-built as an exterior baseplate sub-assembly for cylindrical lock applications, supporting proper door hardware function and alignment.
  • FSIC Corbin 7-Pin Prep: Pre-configured for Full-Size Interchangeable Core (FSIC) with Corbin 7-Pin cylinder prep, enabling compatibility with FSIC keying systems in commercial installations.
  • Commercial-Grade Construction: Classified as a commercial product, this sub-assembly meets the demands of professional-grade door hardware deployments in high-use environments.
  • Precision Sub-Assembly: Supplied as a complete exterior baseplate sub-assembly, simplifying field installation and replacement within the AD Series lock system.
  • Installation Accessory Classification: Categorized as an installation accessory within the Schlage Electronics Parts and Accessories product group, ideal for new installations, retrofits, and service replacements.

Technical Specifications

  • Department: Door Hardware
  • Product Category: Mechanical Locks
  • Product Group: Parts and Accessories
  • Subcategory: Parts and Accessories
  • Product Subgroup: Parts and Accessories
  • Product Type: Electrical Accessories
  • Parts and Accessories Type: Installation Accessories
  • Commercial/Residential: Commercial
  • Product Model: 47260732-JDCO7
  • Features: Schlage Electronics AD and CO Series Parts

Typical Applications

  • Commercial Office Buildings
  • Educational Facilities
  • Healthcare Institutions
  • Government and Municipal Buildings
  • Multi-Tenant Residential Properties
  • Industrial and Warehouse Facilities
  • Retail Establishments

Why Schlage Electronics AD Series?

Schlage Electronics AD and CO Series components are purpose-built for demanding commercial environments, delivering precise fitment and reliable performance as verified installation accessories within the platform. This exterior baseplate sub-assembly reflects the same engineering standards applied across the full AD Series line, making it a dependable choice for installers and facilities teams managing commercial cylindrical lock systems.

Manufacturer Resources

Schlage Electronics EAC Catalog

Product Specs

Department:
Door Hardware
Product Category:
Mechanical Locks
Product Group:
Electronic Access Controls
Subcategory:
Parts and Accessories
Product Subgroup:
Mounting and Housings
Product Type:
Mounting Plate
Parts and Accessories Type:
Installation Accessories
Commercial/Residential:
Commercial
Product Model:
47260732-JDCO7
Features:
Schlage Electronics AD and CO Series Parts

Schlage Electronics 47260732-JDCO7 – Frequently Asked Questions

1) What exactly is the Schlage 47260732-JDCO7 part, and what does it do on an AD Series lock?
It's the exterior baseplate sub-assembly for a Schlage Electronics AD Series cylindrical lock. The baseplate is the mounting interface on the outside face of the door that the exterior escutcheon and lock chassis register to, and this one is prepped to take a full-size interchangeable core. It is a component, not a complete lock, so it is ordered for a new build-out, a retrofit of the exterior side, or a service replacement where the existing baseplate is damaged or the wrong cylinder prep.
2) Will the 47260732-JDCO7 baseplate accept my Schlage or Sargent interchangeable cores?
No. This baseplate is prepped specifically for a Corbin Russwin 7-pin full-size interchangeable core. Schlage FSIC cores are 6-pin and use a different core geometry, and Sargent uses its own LFIC/FSIC format, so neither drops into this prep. If your facility is keyed in Schlage or Sargent, order the AD Series baseplate sub-assembly with the matching cylinder prep instead of trying to adapt this one.
3) Can I use this baseplate on a Schlage AD mortise lock?
No. The prep on the 47260732-JDCO7 is for the cylindrical chassis version of the AD Series. Mortise and cylindrical AD locks use different exterior baseplate sub-assemblies because the chassis, spindle, and cylinder locations differ. Confirm your chassis is cylindrical before ordering this one.
4) I manage a campus keyed in Corbin Russwin 7-pin. Can I put Schlage electronic locks on those doors without rekeying?
Yes, that is the reason this prep exists. Ordering the AD or CO Series cylindrical lock with the Corbin 7-pin FSIC exterior baseplate lets you drop your existing Corbin Russwin 7-pin interchangeable cores straight into the new electronic locks, so the mechanical key override stays on your current master key system and no rekeying of the building is needed.
5) Does this part work on Schlage CO Series locks too, or AD only?
It is built for the Schlage Electronics AD and CO Series platform, so it covers both families where the lock is a cylindrical chassis with a Corbin 7-pin FSIC prep. That matters for facilities running a mix of the offline CO Series and networked AD Series on the same keyway, since one baseplate part number covers the exterior side on either.
6) Is the 47260732-JDCO7 a complete exterior assembly or do I still need to order a cylinder?
The baseplate arrives as a complete sub-assembly for the exterior side, but the interchangeable core is separate. You supply or order the Corbin Russwin 7-pin FSIC core, plus the control key to install it. The lock chassis, interior side, and credential reader are also separate items.
7) Is this baseplate rated for high-traffic commercial doors or is it a light-duty part?
It is a commercial component, built for professional door hardware deployments in high-use environments such as offices, schools, hospitals, government buildings, multi-tenant residential, warehouses, and retail. It is not offered as a residential part.
